Semiconductor
SAM2333
Dual Chip LED Lamp
Features
•
•
•
•
Compact type
Radiation size 1.3mm
×2.9mm
Radiation color (Red, Green)
Surface mount lead configuration
Outline Dimensions
unit :
mm
1.3±
0.2
2.9±
0.2
1.9±
0.2
0.4±
0.1
3
1.0±
0.2
1
0.2 Min
PIN Connections
1.Anode
2.Anode
3.Cathode
2
KLD-0001-000
1
SAM2333
Absolute maximum ratings
Characteristic
Power Dissipation
Forward Current
*
1
Peak Forward Current
Reverse Voltage
Operating Temperature
Storage Temperature
*
2
Soldering Temperature
Symbol
P
D
I
F
I
FP
V
R
T
opr
T
stg
T
sol
Ratings
55
30
50
4
-25½85
-30½100
240℃ for 5 seconds
Unit
mW
mA
mA
V
℃
℃
*1.Duty ratio = 1/16, Pulse width = 0.1ms
*2.Recommended soldering condition
⇒
Attached
Electrical Characteristics
Characteristic
Forward Voltage
Luminous Intensity
Peak Wavelength
Spectrum Bandwidth
Reverse Current
V
F
I
V
Symbol
Red
Y-Green
Red
Y-Green
Red
Y-Green
Red
Y-Green
Test Condition
I
F
= 20mA
I
F
= 20mA
I
F
= 20mA
I
F
= 20mA
V
R
=4V
I
F
= 20mA
Min. Typ. Max.
-
-
-
-
-
-
-
-
2.0
2.1
6
10
630
570
35
30
-
±80
2.7
2.8
-
-
-
-
10
-
Unit
V
mcd
nm
nm
uA
deg
λ
P
Δ
λ
I
R
θ
1/2
*
3
Half angle
*3.
θ
1/2 is the off-axis angle where the luminous intensity is 1/2 the peak intensity
KLD-0001-000
2
Characteristic Diagrams
Fig. 1 I
F
- V
F
Fig. 2 I
V
- I
F
SAM2333
Forward
Voltage V
F
[V]
Luminous Intensity I
v
[mcd]
Forward
Current I
F
[mA]
Forward
Current I
F
[mA]
Fig. 3 I
F
– Ta
Fig.4 Spectrum Distribution
Current I
F
[mA]
Forward
Ambient Temperature Ta [℃]
Relative Intensity [%]
Wavelength
λ
[nm]
Fig. 5 Radiation Diagram
Relative Luminous Intensity Iv [%]
KLD-0001-000
3
