PROFESSIONAL LED INDICATORS Ø5.0mm Mounting
FEATURES
Bright nickel plated brass housing
603 SERIES
PACK QUANTITY = 10 PIECES
Sealed to IP67
Excellent wide viewing angle characteristics
Suitable for high vibration applications
Internal reverse protection diode fitted as standard in all
voltage models.
SPECIFICATION
Ordering Information & Typical T
echnical Characteristics (T
a = 25°C)
Mean Time Between Failure = 100,000 Hours.
PART NUMBER
COLOUR
Luminous intensity figures refer to the unmodified discrete LED.
VOLTAGE
CURRENT
LUMINOUS
WAVE
OPERATING
STORAGE
LENS
DC (Vdc)
Vopr
DC (mA)
lopr
INTENSITY
lv@20mA (mcd)
LENGTH
λp
(nm)
TEMP
T
opr
TEMP
T
stg
HIGH INTENSITY
603-301-04
603-325-04
603-324-04
603-934-04
603-998-04
603-301-23
603-325-23
603-324-23
603-934-23
603-998-23
UNITS
Red
Yellow
Green
Blue
Cool White
Red
Yellow
Green
Blue
Cool White
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
Colour Diffused
2.1
2.2
2.2
2.2
2.2
24-28
24-28
24-28
24-28
24-28
Vdc
20
20
20
20
20
20
20
20
20
20
mA
900
4300
7800
2300
4600
900
4300
7800
2300
4600
mcd
660
590
525
470
*see below
660
590
525
470
*see below
nm
-40 ~ +85^
-30 ~ +85^
-30 ~ +85^
-30 ~ +85^
-30 ~ +85^
-40 ~ +85^
-30 ~ +85^
-30 ~ +85^
-30 ~ +85^
-30 ~ +85^
°C
-40 ~ +85
-40 ~ +120
-40 ~ +100
-40 ~ +100
-40 ~ +100
-40 ~ +85
-40 ~ +120
-40 ~ +100
-40 ~ +100
-40 ~ +100
°C
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Yes
Other voltages AC/DC available. Please contact our Technical sales.
^ = Products must be derated according to the derating information. Each derating graph refers to specific LEDs.
998
*Typical
emission colour cool white
0.283
0.330
0.330
Refer to page 3.
Intensities (lv) and colour shades of white (x,y co-ordinates) may vary between LEDs within a batch.
x
0.296
y
0.276
0.305
0.339
0.318
How to Order:
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
BS EN ISO 9001:2000
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
© MARL INTERNATIONAL LTD 2008 : DS 004/08
Issue 1
SAMPLES AVAILABLE
Page 1 of
3
603 Series
MOUNTING HOLE
Dimensions in mm (Typical)
Not to scale
Anode termination indicated by red lead.
Mounting hole to be clean and burr free
MATERIALS
Body
Nut
Panel Seal
Fresnel lens
Encapsulation
Lock Washer
Bright Nickel Plated Brass
Bright Nickel Plated Brass
Viton
Polycarbonate
Epoxy
Beryllium Copper
TECHNICAL CHARACTERISTICS
SERIES
MAXIMUM
DISSIPATION
603
425
mW
* = Current Version
POWER
MAXIMUM
VOLTAGE
3* / 75•
Vdc
• = Voltage Version
REVERSE
PANEL
NUT
MINIMUM
MIN/MAX.
THICKNESS
1.5-8.0
mm
PANEL
CUTOUT
TORQUE
0.35
Nm
MOUNTING
CENTRES
x,y =10.0
mm
MOUNTING
5.0
mm
OPTIONAL FLYING LEAD TERMINATIONS
ORDER
SUFFIX
CODE
SUPPLY
WIRE
WIRE
NO/DIAMETER
CONDUCTORS
OF
DIAMETER
INSULATION
Customised
lengths
available
OVER
COMMENTS
VOLTAGE
COLOUR
LENGTH
19
DC Products
Red-anode / Black-cathode
1000mm
19/0.15mm
1.2mm
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
BS EN ISO 9001:2000
© MARL INTERNATIONAL LTD 2008 : DS 004/08
Issue 1
SAMPLES AVAILABLE
Page 2 of
3
DERATING INFORMATION
301
325
324, 934, 998
ALSO AVAILABLE
Part numbers also available in the 603 Series:
PART NO.
COLOUR
VOLTAGE DC
(Vdc) Vopr
603-301-21
603-301-22
603-301-42
603-303-04
603-303-20
603-303-21
603-309-04
603-309-20
603-309-22
603-312-04
603-312-04-15
603-312-20
603-312-21
603-312-22
603-324-21
603-324-22
603-998-20
UNITS
Red
Red
Red
Red
Red
Red
Yellow
Yellow
Yellow
Green
Green
Green
Green
Green
Green
Green
Warm White
12 VDC
24 VDC
15 VDC
20mA
5/6 VDC
12 VDC
20mA
5/6 VDC
24 VDC
20mA
20mA
5/6 VDC
12 VDC
24 VDC
12 VDC
24 VDC
5/6 VDC
The products listed above illustrate all of the options available to order. These products may have custom modifications that alter
their operation beyond the generic information contained within this datasheet. Please contact sales for further information.
website: www.marl.co.uk • email: sales@marl.co.uk •
•
T
elephone +44 (0)1229 582430
•
Fax: +44 (0)1229 585155
BS EN ISO 9001:2000
relating to either products or service.
for products or service.
The information contained in this datasheet does not constitute part of any order or contract and should not be regarded as a representation
Marl International reserve the right to alter without notice the specification or any conditions of supply
Approved Manufacturer
© MARL INTERNATIONAL LTD 2008 : DS 004/08
Issue 1
SAMPLES AVAILABLE
Page 3 of 3
