V846ME08
9939 Via Pasar • San Diego, CA 92126
TEL (858) 621-2700 FAX (858) 621-2722
VOLTAGE CONTROLLED OSCILLATOR
Rev A1
PHASE NOISE (1 Hz BW, typical)
-40
-50
£(f) (dBc/Hz)
-60
-70
-80
-90
-100
-110
-120
-130
1 E+3
10 E+3
100 E+3
FEATURES
• Frequency Range: 3450 - 4200 MHz
• Tuning Voltage:
0.5-14 Vdc
• MINI-14S-L - Style Package
APPLICATIONS
• Direct Broadcast
• Satellite Up/Down Conversion
• Microwave Radios
PERFORMANCE SPECIFICATIONS
Oscillation Frequency Range
Phase Noise @ 10 kHz offset (1 Hz BW, typ.)
Harmonic Suppression (2nd, typ.)
Tuning Voltage
Tuning Sensitivity (avg.)
Power Output
Load Impedance
Input Capacitance (max.)
Pushing
Pulling (14 dB Return Loss, Any Phase)
OFFSET (Hz)
VALUE
3450
-
4200
-82
-15
0.5-14
62
6±3
50
50
<2
<12
-20 to 70
MINI-14S-L
10
27
APPLICATION NOTES
Vdc
mA
UNITS
MHz
dBc/Hz
dBc
Vdc
MHz/V
dBm
Ω
pF
MHz/V
MHz
°C
Operating Temperature Range
Package Style
POWER SUPPLY REQUIREMENTS
Supply Voltage (Vcc, nom.)
Supply Current (Icc, typ.)
All specifications are typical unless otherwise noted and subject to change without notice.
•
AN-100/1 : Mounting and Grounding of VCOs
•
AN-102 : Proper Output Loading of VCOs
•
AN-107 : How to Solder Z-COMM VCOs
NOTES:
© Z-Communications, Inc.
Page 1
All rights reserved
