ZXMN3A03E6
30V N-CHANNEL ENHANCEMENT MODE MOSFET
SUMMARY
V
(BR)DSS
= 30V; R
DS(ON)
= 0.050
I
D
= 4.6A
DESCRIPTION
This new generation of TRENCH MOSFETs from Zetex utilizes a unique structure
that combines the benefits of low on-resistance with fast switching speed. This
makes them ideal for high efficiency, low voltage, power management
applications.
SOT23-6
FEATURES
•
Low on-resistance
•
Fast switching speed
•
Low threshold
•
Low gate drive
•
SOT23-6 package
APPLICATIONS
•
DC - DC Converters
•
Power Management Functions
•
Disconnect switches
•
Motor control
ORDERING INFORMATION
DEVICE
ZXMN3A03E6TA
ZXMN3A03E6TC
REEL
SIZE
7”
13”
TAPE
WIDTH
8mm
8mm
QUANTITY
PER REEL
3000 units
10000 units
DEVICE MARKING
•
3A3
Top View
ISSUE 1 - MARCH 2002
1
ZXMN3A03E6
PACKAGE DIMENSIONS
b
e
L 2
PAD LAYOUT DETAILS
E
E1
e1
D
a
DATUM A
C
A
A2
A1
DIM Millimetres
Min
A
A1
A2
b
C
D
E
E1
L
e
e1
L
0.90
0.00
0.90
0.35
0.09
2.80
2.60
1.50
0.10
0.95 REF
1.90 REF
0°
Inches
Min
0.35
0
0.035
0.014
0.0035
0.110
0.102
0.059
0.004
0.037 REF
0.074 REF
Max
0.057
0.006
0.051
0.019
0.008
0.118
0.118
0.069
0.002
Max
1.45
0.15
1.30
0.50
0.20
3.00
3.00
1.75
0.60
10°
0°
10°
© Zetex plc 2001
Zetex plc
Fields New Road
Chadderton
Oldham, OL9 8NP
United Kingdom
Telephone (44) 161 622 4422
Fax: (44) 161 622 4420
Zetex GmbH
Streitfeldstraße 19
D-81673 München
Germany
Telefon: (49) 89 45 49 49 0
Fax: (49) 89 45 49 49 49
Zetex Inc
700 Veterans Memorial Hwy
Hauppauge, NY11788
USA
Telephone: (631) 360 2222
Fax: (631) 360 8222
Zetex (Asia) Ltd
3701-04 Metroplaza, Tower 1
Hing Fong Road
Kwai Fong
Hong Kong
Telephone: (852) 26100 611
Fax: (852) 24250 494
These offices are supported by agents and distributors in major countries world-wide.
This publication is issued to provide outline information only which (unless agreed by the Company in writing) may not be used, applied or reproduced
for any purpose or form part of any order or contract or be regarded as a representation relating to the products or services concerned. The Company
reserves the right to alter without notice the specification, design, price or conditions of supply of any product or service.
For the latest product information, log on to
www.zetex.com
ISSUE 1 - MARCH 2002
7
