FM4001-M thru FM4007-M
SURFACE MOUNT STANDARD RECOVERY RECTIFIER
VOLTAGE - 50 TO 1000 VOLTS
CURRENT - 1.0 AMPERES
SOD-123
0.154(3.9)
0.138(3.5)
0.012(0.3) Typ .
0.071(1.8)
0.055(1.4)
0.126(3.2)
0.110(2.8 )
0.067(1.7)
0.051(1.3)
0.035(0.9) Typ .
0.035(0.9) Typ .
Dimensions in inches and (millimeters)
FEATURES
Plastic package has Underwriters Laboratory
Flammability Classification 94V-0 Ufizing Flame
Retardant Epoxy Molding Compound.
For surface mounted applications.
Exceeds environmental standards of ML-S-19500/228
Low leakage current
MECHANICAL DATA
Case JEDEC SOD-123/MINI-SMA molded plastic
Terminals Solder plated, solderable per
MIL-STD-750, Method 2026
Polarity Indicated by cathode band
Mounting Position Any
Weight 0.04gram
MAXIMUM RATINGS
(at T
A
=25 C unless otherwise noted)
o
PARAMETER
Forward rectified current
Forward surge current
See Fig.2
CONDITIONS
SYMBOL
I
O
I
FSM
Min.
Typ.
Max.
UNITS
A
A
A
A
0
1.0
30
5.0
50
60
30
15
-55
+150
8.3ms Single Half Sine-Wave Superimposed
on Rated Load (JEDEC Method)
V
R
=V
RRM
TA=25 C
V
R
=V
RRM
TA=100
0
C
Junction to ambient
Junction to case
0
Reverse current
I
R
R
thJA
R
thJC
C
J
T
STG
Thermal resistance
C/W
pF
0
Diode junction capacitance F=1MHz and applied 4vDC reverse voltage
Storage temperature
C
SYMBOLS
FM4001-M
FM4002-M
FM4003-M
FM4004-M
FM4005-M
FM4006-M
FM4007-M
MARKING CODE
A1
A2
A3
A4
A5
A6
A7
V
RRM
(V)
50
*1
V
RMS
(V)
35
70
*2
V
R
(V)
50
*3
V
F
(V)
*4
Operating Temperature
(
0
C)
100
200
400
600
800
1000
100
200
400
600
800
1000
1.1
-55 to + 125
140
280
420
560
700
*1 Repetitive peak reverse peak reverse
*2 RMS voltage
*3 Continuous reverse voltage
*4 Maximum forward voltage
