DSPI_FIFO

Serial Peripheral Interface

Master/Slave with FIFO

ver 1.07

OVERVIEW

The DSPI_FIFO is a fully configurable SPI

master/slave device, which allows user to

configure polarity and phase of serial clock

signal SCK.

The DSPI_FIFO allows the microcontroller

to communicate with serial peripheral devices.

It is also capable of interprocessor communi-

cations in a multi-master system. A serial

clock line (SCK) synchronizes shifting and

sampling of the information on the two inde-

pendent serial data lines. DSPI_FIFO data are

simultaneously transmitted and received.

The DSPI_FIFO is a technology independ-

ent design that can be implemented in a vari-

ety of process technologies.

The DSPI_FIFO system is flexible enough

to interface directly with numerous standard

product peripherals from several manufactur-

ers. The system can be configured as a mas-

ter or a slave device. Data rates as high as

CLK/8. Clock control logic allows a selection

of clock polarity and a choice of two funda-

mentally different clocking protocols to ac-

commodate most available synchronous serial

peripheral devices. When the SPI is config-

ured as a master, software selects one of

eight different bit rates for the serial clock.

The DSPI_FIFO automatically drive se-

lected by SSCR (Slave Select Control Regis-

ter) slave select outputs (SS7O – SS0O), and

address SPI slave device to exchange serially

shifted data. Error-detection logic is included

All trademarks mentioned in this document

are trademarks of their respective owners.

to support interprocessor communications. A

write-collision detector indicates when an at-

tempt is made to write data to the serial shift

tiple-master mode-fault detector automatically

disables DSPI_FIFO output drivers if more

than one SPI devices simultaneously attempts

to become bus master.

The DSPI_FIFO supports two DMA

modes: single transfer and multi-transfer.

These modes allow DSPI_FIFO to inter-

face to higher performance DMA units,

which can interleave their transfers be-

tween CPU cycles or execute multiple

byte transfers.

DSPI_FIFO is

fully customizable,

which

means it is delivered in the exact configuration

to meet users’ requirements.

There is no need

to pay extra for not used features and wasted

silicon.

It includes

fully automated testbench

with

complete set of tests

allowing easy

package validation at each stage of SoC de-

sign flow.

APPLICATIONS

●

Embedded microprocessor boards

Consumer and professional audio/video

Home and automotive radio

Digital multimeters

http://www.DigitalCoreDesign.com

http://www.dcd.pl
