TN3724: Description2000 mA, 80 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-237AA; CategoryDiscrete semiconductor The transistor; File Size197KB，5 Pages; ManufacturerCentral Semiconductor

Download Datasheet Parametric View All

TN3724 Overview

2000 mA, 80 V, NPN, Si, SMALL SIGNAL TRANSISTOR, TO-237AA

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Central Semiconductor
Parts packaging code	TO-237
package instruction	TO-237, 3 PIN
Contacts	3
Reach Compliance Code	unknow
ECCN code	EAR99
Maximum collector current (IC)	0.5 A
Collector-based maximum capacity	12 pF
Collector-emitter maximum voltage	30 V
Configuration	SINGLE
Minimum DC current gain (hFE)	30
JEDEC-95 code	TO-237AA
JESD-30 code	O-PBCY-W3
JESD-609 code	e0
Number of components	1
Number of terminals	3
Maximum operating temperature	150 °C
Minimum operating temperature	-65 °C
Package body material	PLASTIC/EPOXY
Package shape	ROUND
Package form	CYLINDRICAL
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
Polarity/channel type	NPN
Maximum power consumption environment	0.85 W
Maximum power dissipation(Abs)	2 W
Certification status	Not Qualified
surface mount	NO
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	WIRE
Terminal location	BOTTOM
Maximum time at peak reflow temperature	NOT SPECIFIED
transistor applications	SWITCHING
Transistor component materials	SILICON
Nominal transition frequency (fT)	300 MHz
Maximum off time (toff)	60 ns
Maximum opening time (tons)	35 ns
VCEsat-Max	0.75 V

145 Adams Avenue, Hauppauge, NY 11788 USA

Tel: (631) 435-1110 • Fax: (631) 435-1824
