LCG-12A01

Description
lcd graphic module 12 x 1
File Size146KB,2 Pages
ManufacturerDELTA
Websitehttp://www.deltaww.com/
Download Datasheet View All

LCG-12A01 Overview

lcd graphic module 12 x 1

LCG-12A01, LCD Graphic Module 12 x 1
FEATURES
BUILT-IN CONTROLLER ( HD66730 OR EQUIVALENT)
+5 V POWER SUPPLY
1/16 DUTY CYCLE
8-BIT PARALLEL INTERFACE
4.2 V LED FORWARD VOLTAGE
MECHANICAL DATA
ITEM
Module Size (W x H x T)
Viewing Area ( W x H )
Active Area ( W x H )
Dot Size ( W x H )
Dot Pitch ( W x H )
DIMENSIONS
84.0 x 36.0 x 8. 8(12.7L E D)
65.0 x 1 6.0
62.79 x 7.64
0.40 x 0. 60
0.43 x 0. 64
UNIT
mm
mm
mm
mm
mm
INTERFACE PIN CONNECTIONS
NO.
1
2
3
4
5
6
7~14
15
16
ABSOLUTE MAXIMUM RATINGS
ITEM
Supply Voltage For Logic
Supply Voltage For LCD Drive
Input Voltage
SYMBOL
V
SS
V
DD
V
O
RS
R/W
E
DB0~DB7
A
K
LEVEL
0V
5V
FUNCTION
Power Supply Ground
Power Supply Voltage
Contrast Adj.
Register Select
Read/Write
Enable Signal
Data Bus Line
LED Power (+)
LED Power (-)
SYMBOL
V
DD
-V
SS
V
DD
-V
o
V
I
MIN.
0
0
Vss
TYP.
-
-
-
MAX.
7
12
V
DD
UNIT
V
V
V
-
H/L
H
H
H/L
4.2V
0V
ELECTRICAL CHARACTERISTICS
ITEM
Supply Voltage For Logic
Supply Voltage For LCD
Supply Current
Input
Voltage
Output
Voltage
"HIGH" Level
"LOW" Level
"HIGH" Level
"LOW" Level
SYMBOL
V
DD
-V
SS
V
DD
-V
o
I
DD
V
IH
V
IL
V
OH
V
OL
CONDITION
-
V
DD
=5V Ta=25 C
V
DD
=5V
o
MIN.
4.5
4.4
-
2.2
-
2.4
-
TYP.
5
4.8
2.5
-
-
-
-
MAX.
5.5
5.2
4.5
VDD
0.6
-
0.4
UNIT
V
V
mA
V
V
V
V
-
-
-
-
EXTERNAL DIMENSIONS
DELTA COMPONENTS Auweg 27 D-79761 Waldshut-Tiengen Tel: +49/7751/8399-0 Fax: +49/7751/8399-99 Mail: info@delta-components.de www.delta-components.de
