China Electronics Technology Group Corporation
No.26 Research Institute
140MHz SAW Filter
9.7MHz Bandwidth
Part Number:
LBT14075
www.sipatsaw.com
SIPAT Co., Ltd.
Specifications
Parameter
Center Frequency
Insertion Loss
1dB Bandwidth
20 dB Bandwidth
30 dB Bandwidth
40 dB Bandwidth
Passband Variation
Absolute Delay
Ultimate Rejection
Material Temperature coefficient
Ambient Temperature
Package Size
Unit
MHz
dB
MHz
MHz
MHz
MHz
dB
usec
Minimum
139.9
-
9.7
-
-
-
-
-
48
Typical
140
32
9.76
10.5
10.66
10.73
0.7
3.6
52
-2.52
25
Maximum
140.1
33
-
10.6
11
11.8
1
-
-
dB
KHz/°C
°C
DIP2712 (27.2x12.7x5.2
3
)
Notes:
1. All specifications are based on the test circuit shown
2. In production, devices will be tested at room temperature to a guardbanded specification to ensure
electrical compliance over temperature
3. Electrical margin has been built into the design to account for the variations due to temperature drift
and manufacturing tolerances
4. This is the optimum impedance in order to achieve the performance show
Matching Configuration
L1=27nH
C1=82pF
Source/Load Impedance=50 ohm
Notes - Component values may change depending
on board layout.
SIPAT Co., Ltd.
( CETC No. 26 Research Institute )
Nanping Huayuan Road No. 14
Chongqing, China, 400060
Part Number
Rev. Date
Rev.
LBT14075
2005-8-8
1.0
Page
1/3
Phone: +86-23-62920684
Fax: +86-23-62805284
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
140MHz SAW Filter
9.7MHz Bandwidth
Part Number:
LBT14075
www.sipatsaw.com
SIPAT Co., Ltd.
Package Dimension
3
6
2
1
SIPAT Co., Ltd.
( CETC No. 26 Research Institute )
Nanping Huayuan Road No. 14
Chongqing, China, 400060
Part Number
Rev. Date
Rev.
4
5
Input:1
Output:5
LBT14075
2005-8-8
1.0
Page
2/3
Phone: +86-23-62920684
Fax: +86-23-62805284
www.sipatsaw.com / sawmkt@sipat.com
China Electronics Technology Group Corporation
No.26 Research Institute
140MHz SAW Filter
9.7MHz Bandwidth
Part Number:
LBT14075
www.sipatsaw.com
SIPAT Co., Ltd.
Typical Performance
Frequency Respond
Passband Respond
-31
-42.0166
-32
-52.0166
-33
-62.0166
Magnitude(dB)
-34
-72.0166
-35
-82.0166
-36
-92.0166
-37
-102.0166
-38
-112.0166
-39
124
128
132
136
140
144
148
152
156
136
137
138
139
140
141
142
143
144
Group Delay Variation(f0±4.8MHz)
Phase Linearity(f0±4.8MHz)
Simth Chart
S11
Simth Chart
S22
SIPAT Co., Ltd.
( CETC No. 26 Research Institute )
Nanping Huayuan Road No. 14
Chongqing, China, 400060
Part Number
Rev. Date
Rev.
LBT14075
2005-8-8
1.0
Page
3/3
Phone: +86-23-62920684
Fax: +86-23-62805284
www.sipatsaw.com / sawmkt@sipat.com
