NTE30053 thru NTE30059

Super Bright LED Indicators, 8mm

Features:

RoHS Compliant

All Plastic Mold Type

/Water Clear Lens:

NTE30053 (Yellow Green, AIInGaP/GaAs)

NTE30054 (Light Green, InGaN/GaN)

NTE30055 (Orange, AllnGaP/GaAs)

NTE30056 (Light Red, AllnGaP/GaAs)

NTE30057 (Deep Red, GaAlAs/GaAlAs)

NTE30058 (Blue, INGaN/GaN)

NTE30059 (White)

Absolute Maximum Ratings:

= +25°C unless otherwise specified)

Reverse Voltage, V

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 4V

NTE30053, NTE30055, NTE30056, NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 5V

Continuous Forward Current, I

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 25mA

Peak Forward Current (1.10 Duty Cycle, 0.1ms Pulse Width), I

NTE30053, NTE30055, NTE30056, NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 50mA

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mA

Power Dissipation, P

NTE30053, NTE30055, NTE30056 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 100mW

NTE30057 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 110mW

NTE30054, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 120mW

LED Junction Temperature, T

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . +100°C

Operating Temperature Range, T

opr

. . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +85°C

Storage Temperature Range, T

stg

NTE30053, NTE30055, NTE30056 . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . .

−25°C

to +100°C

NTE30054, NTE30057, NTE30058, NTE30059 . . . . . . . . . . . . . . . . . . . . . .

−40°C

to +100°C

Lead Temperature (During Soldering, .063 (1.6mm) from body, 5sec max), T

. . . . . . . . . . . +260°C

Electro−Optical Characteristics:

= +25°C unless otherwise specified)

Parameter

Forward Voltage

NTE30053

NTE30054

NTE30055

NTE30056

NTE30057

NTE30058

NTE30059

Symbol

Test Conditions

= 20mA

Min

−

Typ

2.2

3.5

2.0

1.86

3.5

Max

2.5

4.0

2.5

2.4

2.5

4.0

4.1

Unit

NTE30053 Related Products

	NTE30053	NTE30057	NTE30058
Description	Replacement of photoelectric components super yellow green 1600mcd 100mw pkg(3)	Replacement of photoelectric components super deep red 2200mcd 110mw pkg(3)	Replacement of photoelectric components super blue 1500mcd 120mw pkg(2)
Is it Rohs certified?	conform to	conform to	conform to
Reach Compliance Code	unknown	unknown	unknown
Base Number Matches	-	1	1
