LANC2415RD datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Power/power management> The power supply circuit> LANC2415RD

LANC2415RD: DescriptionPower Supply Module, Hybrid; CategoryPower/power management The power supply circuit; File Size72KB，3 Pages; ManufacturerWall Industries,Inc.; Websitehttps://www.wallindustries.com/

Download Datasheet Parametric View All

LANC2415RD Overview

Power Supply Module, Hybrid

LANC2415RD Parametric

Parameter Name	Attribute value
Objectid	1154943672
package instruction	DIP, DIP12/24,.6
Reach Compliance Code	compliant
ECCN code	EAR99
Maximum input voltage	26.4 V
Minimum input voltage	21.6 V
JESD-30 code	R-PDIP-T12
Number of terminals	12
Maximum operating temperature	70 °C
Minimum operating temperature	-25 °C
Nominal output voltage	15 V
Package body material	PLASTIC/EPOXY
encapsulated code	DIP
Encapsulate equivalent code	DIP12/24,.6
Package shape	RECTANGULAR
Package form	IN-LINE
Certification status	Not Qualified
surface mount	NO
technology	HYBRID
Temperature level	OTHER
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL

Preview

Download Datasheet

View All

Rev B

LAN C SERIES

TO 3 WATTS - LAN C SERIES

Single and Dual Output DIP Package

TO 3 WATTS

FEATURES

• Miniature Dual In-Line Package

• Two Levels of Isolation Available

• Low Reflected Ripple Current

• Regulated

• Ripple/Noise: 50mV p-p typical

• 3KV isolation option

THE LAN C SERIES FROM WALL INDUSTRIES

Offering alternate combinations from four different input volt-

age ranges; nine different output voltages; two levels of iso-

lation and three tiers of power, the LAN C Series of DC/DC

converters can be tailor-made to fit most any low power con-

version requirement.

SPECIFICATIONS: LAN C SERIES

All specifications apply @ +25 C ambient unless otherwise

noted.

INPUT SPECIFICATIONS

Input Voltage Range ....5, 12, 15, 24,48VDC ±10%

Input Filtering ........................................Pi Network

GENERAL SPECIFICATIONS

Efficiency (typical) ..................................55 to 65%

Isolation Voltage (input to output)500VDC or 3000VDC

Switching Frequency ..........................40kHz (min.)

OUTPUT SPECIFICATIONS

Output Current ........................................see table

Voltage Tolerance ..........±5 (nom. line, 100% load)

Line Regulation: Regulated ..........................±1.0%

Load Regulation: Regulated(H option L & L = .5%)±1.0%

Ripple/Noise (20MHz BW) ......................50mV p-p

Short Circuit Protection ........................continuous

ENVIRONMENTAL SPECIFICATIONS

Operating Temperature ......................-25° to 71°C

Storage Temperature ......................-40° to +125°C

Cooling ....................................Free air convection

PHYSICAL SPECIFICATIONS

Dimensions: ......................................1.25 x 0.8 x 0.4”

Case Material.................Non-conductive black plastic

Due to advances in technology, specifications subject to change without

notice.

6/13/08

603 778 2300

WWW

WALLINDUSTRIES

COM
