LANC2406UW5: Descriptionsingle and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage; File Size227KB，3 Pages; ManufacturerWall Industries,Inc.; Websitehttps://www.wallindustries.com/

Download Datasheet Compare View All

LANC2406UW5 Overview

single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage

Preview

Download Datasheet

View All

LANCW5 Series

Rev. B

APPLICATIONS

Single and Dual Output

5 Watt DC/DC Converter

2:1 and 4:1 Wide Input Voltage

FEATURES

●

Wireless Network

●

Five-Sided Shielding

●

Telecom/Datacom

●

5 Watts Output power

●

Industry Control System

●

High Efficiency up to 84%

●

Measurement Equipment

●

Standard 1.25 x 0.8 x 0.4 Inches

●

Semiconductor Equipment

●

Fixed Switching Frequency (300KHz)

●

2:1 and 4:1 Ultra Wide Input Voltage Range

●

Compliant to RoHS EU Directive 2002/95/EC

●

UL60950-1, EN60950-1, and IEC60950-1 Licensed

●

Standard 24 Pin DIP Package and SMT Type Package

●

CE Mark meets 2006/95/EC, 93/68/EEC, and 2004/108/EC

SPECIFICATIONS:

LANCW5 Series

All specifications apply @ 25°C ambient unless otherwise noted

INPUT SPECIFICATIONS

Input Voltage Range

LANCW5 ........................ 12V nominal input ............................9-18Vdc

24V nominal input .........................18-36VDC

48V nominal input ........................ 36-75VDC

LANCUW5...................... 24V nominal input ...........................9-36VDC

48V nominal input .........................18-75VDC

Input Filter ....................................................................................... Pi Type

Input Surge Voltage (100ms max) ...... 12V input ...........................36VDC

24V input ...........................50VDC

48V input .........................100VDC

Input Reflected Ripple Current (nominal Vin and full load) ...........20mAp-p

Start Up Time (nominal Vin and constant resistive load) ...........450ms typ.

GENERAL SPECIFICATIONS (CONTINUED)

Isolation Resistance ...............................................................10 ohms min.

Isolation Capacitance ................................................................ 300pF max.

ENVIRONMENTAL SPECIFICATIONS

Operating Temperature

Standard .................................................. -25°C to +85°C (w/ derating)

“I” (See notes 6 & 9) ............................. -40°C to +85°C (w/o derating)

“I” (UW Series)......................................... -40°C to +85°C (w/ derating)

Storage Temperature .......................................................... -55°C ~ +105°C

Maximum Case Temperature ................. Standard ......................... +100°C

“I” suffix ............................ +105°C

Relative Humidity (non-condensing) .....................................5% to 95% RH

Thermal Impedance (Natural Convection) ................................. 20°C / Watt

Thermal Shock ..................................................................... MIL-STD-810F

Vibration ................................10~55Hz, 10G, 30 minutes along X, Y, and Z

MTBF (See Note 1) ........BELLCORE TR-NWT-000332...... 3.165 x 10 hrs

MIL-HDBK-217F........................... 1.631 x 10 hrs

OUTPUT SPECIFICATIONS

Output Voltage ..............................................................................see table

Voltage Accuracy (nominal Vin and full load) ...................................... ±1%

Output Current ..............................................................................see table

Output Power .......................................................................... 5 watts max.

Line Regulation (LL to HL at FL)....................................................... ±0.2%

Load Regulation (no load to full load) ...... Single Output................. ±0.5%

Dual Output ....................... ±1%

Cross Regulation (Dual) (Asymmetrical load 25% / 100% FL) ............ ±5%

Minimum Load ....................................................................................... 0%

Ripple/Noise (20 MHz BW) .......................................................... 50mVp-p

Temperature Coefficient ................................................. ±0.02% / °C max.

Transient Response Recovery Time (25% load step) ...................... 200us

PHYSICAL SPECIFICATIONS

Weight ....................................DIP .......................................... 16g (0.55 oz)

SMT......................................... 18g (0.63 oz)

Dimensions................... 1.25 x 0.80 x 0.40 inches (31.8 x 20.3 x 10.2 mm)

Case Material ..............................................................Nickel-coated copper

Base Material...................................................Non-conductive black plastic

Potting material..................................................................Epoxy (UL94-V0)

Shielding..................................................................................... five – sided

PROTECTION SPECIFICATIONS

Over Load Protection (% of full load at nominal input)................ 170% typ.

Short Circuit Protection .............................Continuous, automatic recovery

SAFETY & EMC

Approvals and Standards .................. IEC60950-1, UL60950-1, EN60950-1

EMI .....................................EN55022 .............................................. Class A

ESD ..... EN61000-4-2……….

Air

± 8KV

………………Perf. Criteria A

Contact ± 6KV

GENERAL SPECIFICATIONS

Efficiency.......................................................................................see table

Switching Frequency................................................................300KHz typ.

Isolation Voltage

Input to Output ............................................................. 1600VDC min.

Input (Output) to Case (DIP) ........................................ 1600VDC min.

Input (Output) to Case (SMT)....................................... 1000VDC min.

Radiated Immunity..............EN61000-4-3............... 10V/m Perf. Criteria A

Fast Transient.....................EN61000-4-4................. ±2KV Perf. Criteria B

Surge (See Note 7).............EN61000-4-5................ .±1KV Perf. Criteria B

Conducted Immunity...........EN61000-4-6............ 10 Vrms Perf. Criteria A

Due to advances in technology, specifications subject to change without notice

Wall Industries, Inc. 5 Watson Brook Road Exeter, NH 03833

603-778-2300 www.wallindustries.com Fax 603-778-9797

LANC2406UW5 Related Products

	LANC2406UW5	LANC2412DW5	LANC24833W5	LANC2405W5	LANC2433W5	LANC2412W5	LANC2415W5	LANC2405DW5	LANC2415DW5	LANC4815DW5
Description	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage	single and dual output 5 watt DC/DC converter 2:1 and 4:1 wide input voltage
package instruction	-	DIP, DIP10/24,.6	-	DIP, DIP10/24,.6	-	DIP, DIP10/24,.6	DIP, DIP10/24,.6	DIP, DIP10/24,.6	DIP, DIP10/24,.6	DIP, DIP10/24,.6
Reach Compliance Code	-	compliant	-	compliant	-	compliant	compliant	compliant	compliant	compliant
ECCN code	-	EAR99	-	EAR99	-	EAR99	EAR99	EAR99	EAR99	EAR99
Maximum input voltage	-	36 V	-	36 V	-	36 V	36 V	36 V	36 V	75 V
Minimum input voltage	-	18 V	-	18 V	-	18 V	18 V	18 V	18 V	36 V
JESD-30 code	-	R-MDIP-T10	-	R-MDIP-T10	-	R-MDIP-T10	R-MDIP-T10	R-MDIP-T10	R-MDIP-T10	R-MDIP-T10
Number of terminals	-	10	-	10	-	10	10	10	10	10
Maximum operating temperature	-	70 °C	-	70 °C	-	70 °C	70 °C	70 °C	70 °C	70 °C
Minimum operating temperature	-	-25 °C	-	-25 °C	-	-25 °C	-25 °C	-25 °C	-25 °C	-25 °C
Maximum output current	-	0.23 A	-	1 A	-	0.47 A	0.4 A	0.5 A	0.19 A	0.19 A
Nominal output voltage	-	12 V	-	5 V	-	12 V	15 V	5 V	15 V	15 V
Package body material	-	METAL	-	METAL	-	METAL	METAL	METAL	METAL	METAL
encapsulated code	-	DIP	-	DIP	-	DIP	DIP	DIP	DIP	DIP
Encapsulate equivalent code	-	DIP10/24,.6	-	DIP10/24,.6	-	DIP10/24,.6	DIP10/24,.6	DIP10/24,.6	DIP10/24,.6	DIP10/24,.6
Package shape	-	RECTANGULAR	-	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR	RECTANGULAR
Package form	-	IN-LINE	-	IN-LINE	-	IN-LINE	IN-LINE	IN-LINE	IN-LINE	IN-LINE
Certification status	-	Not Qualified	-	Not Qualified	-	Not Qualified	Not Qualified	Not Qualified	Not Qualified	Not Qualified
surface mount	-	NO	-	NO	-	NO	NO	NO	NO	NO
technology	-	HYBRID	-	HYBRID	-	HYBRID	HYBRID	HYBRID	HYBRID	HYBRID
Temperature level	-	OTHER	-	OTHER	-	OTHER	OTHER	OTHER	OTHER	OTHER
Terminal form	-	THROUGH-HOLE	-	THROUGH-HOLE	-	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE	THROUGH-HOLE
Terminal pitch	-	2.54 mm	-	2.54 mm	-	2.54 mm	2.54 mm	2.54 mm	2.54 mm	2.54 mm
Terminal location	-	DUAL	-	DUAL	-	DUAL	DUAL	DUAL	DUAL	DUAL
Base Number Matches	-	-	-	1	-	1	1	1	1	1
