DRAWING NO.
1
19-1702-CUST
REVISIONS
Description:
RCA Female Inline Adaptor
19-1702
Adapter
N/A
N/A
01
OFFICIAL RELEASE
08-05-09
W
Y
U
T
H
2009.09.1
6 14:08:50
+08'00'
D
Part No:
Application:
Crimp Tool:
Impedance:
D
Frequency Range: N/A
Material:
Body
Shell
Brass
PVC
Nickel Plated
Black
C
Insulation Bakelite Yellow
RoHS Compliance: Yes
Technical Detail:
N/A
C
CONTROLLED DOCUMENT
P/N
19-1702-CUST
Rev
01
Rel'd Date
SEP 19,09
B
O
8
.327 in
10.6
.417 in
18.8
.740 in
7
.257 in
B
2-
O
3.2
.126 in
CUSTOMER COPY
TOLERANCE UNLESS DRAWN BY
OTHERWISE SPECIFIED
IVON.W
DECIMALS
X
X.X
X.XX
ANGLES
mm
CHECKED BY
DATE
08-05-09
DATE
08-05-09
08-05-09
A
31.8
1.254 in
Connectivity
Solutions
TITLE
A
DIM OUTLINE
+
0.5
-
+
0.3
-
+
0.1
-
+
0.5
-
BETTY.YU
THOMAS
U/M
mm
APPROVED BY DATE
v
RCA FEMALE INLINE ADAPTOR
SHEET
1 OF 1
DRAWING NO.
SIZE
THIS DRAWING WAS PRODUCED BY COMPUTER,
DO NOT SCALE DRAWING OR UPDATE MANUALLY.
19-1702-CUST
A
5
4
3
2
1
