SSR
Futures
120/240V 40A
(RMS)
Zero crossing Models
D2W140CD D2W240CD
D2W140CF D2W240CF
D2W140CG D2W240CG
* Large capacity(40Arms) in spite of the standard
package.
* Low Noise Switching and Rush Current
Function
* Single Pole, Single Throw Normally Open
* With Zero Crossing Voltage Switching Circuit
Characteristics and Ratings
Characteristics / Ratings
D2W140CD D2W140CF D2W140CG D2W240CD D2W240CF D2W240CG
Parameter
Symbol
Unit
Output
Rated Voltage
A.C. Line Voltage Range
Operating Frequency
Maximum Load Current
Non-repetitive One Cycle Surge Current
Minimum Operating Current
Maximum off-state Leakage Current
Maximum on-sate Voltage Drop
Response Time
V
(RMS)
V
(RMS)
f
I
T(RMS)
I
TSM
I
op(RMS)
I
leak(RMS)
V
T(RMS)
T
(rps)
I
IN(DC)
R
(IN)
PUV
DOV
3 to 6
260
3.0
2.0 (@120Vrms)
1.6
1/2 Cycle + 1mS
10 to 18 18 to 28
860
10.0
1360
18.0
1.0
3 to 6
260
3.0
10 to 18 18 to 28
860
10.0
1360
18.0
120
60 to 140
47 to 63
40
400
120
4.0 (@240Vrms)
240
60 to 280
V
V
HZ
A
A
mA
mA
V
-
V
ohm
V
V
Input
Control Signal Voltage Range
Input Impedance
Pick-up Voltage
Drop-out Voltage
Input/Output
AC Isolation Voltage (
Between
Input ,
Output Terminals and Base)
Capacitance (Between input and output
Operating Temperature Range
Storage Temperature Range
V
iso(RMS)
C
(i-o)
T
op
T
stg
1500
100
-20 to
+80
-25 to +85
V
pF
°C
°C
