RECTRON
SEMICONDUCTOR
TECHNICAL SPECIFICATION
FR301G
THRU
FR307G
FAST RECOVERY GLASS PASSIVATED RECTIFIER
VOLTAGE RANGE 50 to 1000 Volts CURRENT 3.0 Amperes
FEATURES
*
*
*
*
*
*
High reliability
Low leakage
Low forward voltage drop
High current capability
Glass passivated junction
High switching capability
DO-201AD
MECHANICAL DATA
*
*
*
*
*
Case: Molded plastic
Epoxy: UL 94V-O rate flame retardant
Lead: MIL-STD-202E method 208C guaranteed
Mounting position: Any
Weight: 1.18 grams
MAXIMUM RATINGS AND ELECTRICAL CHARACTERISTICS
Ratings at 25
o
C ambient temperature unless otherwise specified.
Single phase, half wave, 60 Hz, resistive or inductive load.
For capacitive load, derate current by 20%.
Dimensions in inches and (millimeters)
MAXIMUM RATINGS
(At T
A
= 25
o
C unless otherwise noted)
RATINGS
Maximum Recurrent Peak Reverse Voltage
Maximum RMS Voltage
Maximum DC Blocking Voltage
Maximum Average Forward Rectified Current
o
at T
A
= 55 C
Peak Forward Surge Current 8.3 ms single half sine-wave
superimposed on rated load (JEDEC method)
Typical Junction Capacitance (Note 2)
Operating and Storage Temperature Range
SYMBOL
V
RRM
V
RMS
V
DC
I
O
I
FSM
C
J
T
J
, T
STG
FR301G FR302G FR303G FR304G FR305G FR306G FR307G UNITS
50
35
50
100
70
100
200
140
200
400
280
400
3.0
125
50
-65 to + 150
600
420
600
800
560
800
1000
700
1000
Volts
Volts
Volts
Amps
Amps
pF
0
C
ELECTRICAL CHARACTERISTICS
(At T
A
= 25 C unless otherwise noted)
CHARACTERISTICS
Maximum Instantaneous Forward Voltage at 3.0A DC
Maximum DC Reverse Current
at Rated DC Blocking Voltage T
A
= 25
o
C
Maximum Full Load Reverse Current Average,
Full Cycle .375” (9.5mm) lead length at T
L
= 55
o
C
Maximum Reverse Recovery Time (Note 1)
NOTES : 1. Test Conditions: I
F
= 0.5A, I
R
= 1.0A, I
RR
= 0.25A
2. Measured at 1 MH
Z
and applied reverse voltage of 4.0 volts
SYMBOL
V
F
FR301G FR302G FR303G FR304G FR305G FR306G FR307G UNITS
1.3
Volts
5.0
I
R
100
trr
150
250
500
uAmps
nSec
1998-8
uAmps
