CXA1101M Overview

dolby B type noise reduction system

CXA1101M Parametric

Parameter Name	Attribute value
Is it Rohs certified?	incompatible
Maker	SONY
Parts packaging code	SOIC
package instruction	SOP, SOP16,.3
Contacts	16
Reach Compliance Code	unknown
Commercial integrated circuit types	DOLBY NOISE REDUCTION IC
Dolby Level Specification	245 mV
Dolby type	B
harmonic distortion	0.04%
JESD-30 code	R-PDSO-G16
JESD-609 code	e0
length	9.9 mm
Number of channels	2
Number of functions	1
Number of terminals	16
Maximum operating temperature	85 °C
Minimum operating temperature	-30 °C
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP16,.3
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Play/record mode	PLAYBACK AND RECORD
power supply	12 V
Certification status	Not Qualified
Maximum seat height	2.25 mm
Maximum slew rate	7.5 mA
Maximum supply voltage (Vsup)	16 V
Minimum supply voltage (Vsup)	8.5 V
surface mount	YES
technology	BIPOLAR
Temperature level	OTHER
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
width	5.3 mm

Preview

Download Datasheet

View All

CXA1100P, CXA1101P/M, CXA1102P/M, CXA1163P/M

Dolby

∗

B Type Noise Reduction System

For the availability of this product, please contact the sales office.

Description

CXA1100, CXA1101, CXA1102 and CXA1163 are

ICs including two separate Dolby B type noise

reduction processors. Seven devices with four Dolby

levels and two types of package are provided for

various applications. These devices feature very few

external

components,

which

achieved

integrated filter circuits using integrated thin film

capacitors with high capacitance.

Features

•

Minimum number of external components

•

NR ON/OFF and REC/PB switchs included

•

Small package (DIP16, SOP16)

•

Small supply current (—5.5mA, Typ.)

•

Dual channel processors in one chip

Absolute Maximum Ratings

(Ta = 25°C)

•

Supply voltage

•

Operating temperature

Topr –30 to +85 °C

•

Storage temperature

Tstg –55 to +150 °C

•

Allowable power dissipation P

DIP16 (A1100P/A1101P/A1102P/A1163P)900 mW

SOP16 (A1101M/A1102M/A1163M)

500 mW

Note 1)

These ICs are available only to the

licensees of Dolby Laboratories Licensing

Corporation from whom licensing and

application information may be obtaind.

Note 2)

"Dolby" and double D symbols are trade

marks of Dolby Laboratories Licensing

Corporation.

16 pin DIP (Plastic)

16 pin SOP (Plastic)

Sony reserves the right to change products and specifications without prior notice. This information does not convey any license by

any implication or otherwise under any patents or other right. Application circuits shown, if any, are typical examples illustrating the

operation of the devices. Sony cannot assume responsibility for any problems arising out of the use of these circuits.

–1–

E90302A13-PP

CXA1101M Related Products

	CXA1101M	CXA1101	CXA1102P	CXA1101P	CXA1102	CXA1100P
Description	dolby B type noise reduction system	dolby B type noise reduction system	dolby B type noise reduction system	dolby B type noise reduction system	dolby B type noise reduction system	dolby B type noise reduction system
Is it Rohs certified?	incompatible	-	incompatible	incompatible	-	incompatible
Maker	SONY	-	SONY	SONY	-	SONY
Parts packaging code	SOIC	-	DIP	DIP	-	DIP
package instruction	SOP, SOP16,.3	-	DIP, DIP16,.3	DIP, DIP16,.3	-	DIP, DIP16,.3
Contacts	16	-	16	16	-	16
Reach Compliance Code	unknown	-	unknown	unknown	-	unknown
Commercial integrated circuit types	DOLBY NOISE REDUCTION IC	-	DOLBY NOISE REDUCTION IC	DOLBY NOISE REDUCTION IC	-	DOLBY NOISE REDUCTION IC
Dolby Level Specification	245 mV	-	245 mV	245 mV	-	245 mV
Dolby type	B	-	B	B	-	B
harmonic distortion	0.04%	-	0.06%	0.04%	-	0.03%
JESD-30 code	R-PDSO-G16	-	R-PDIP-T16	R-PDIP-T16	-	R-PDIP-T16
JESD-609 code	e0	-	e0	e0	-	e0
length	9.9 mm	-	19.35 mm	19.35 mm	-	19.35 mm
Number of channels	2	-	2	2	-	2
Number of functions	1	-	1	1	-	1
Number of terminals	16	-	16	16	-	16
Maximum operating temperature	85 °C	-	85 °C	85 °C	-	85 °C
Minimum operating temperature	-30 °C	-	-30 °C	-30 °C	-	-30 °C
Package body material	PLASTIC/EPOXY	-	PLASTIC/EPOXY	PLASTIC/EPOXY	-	PLASTIC/EPOXY
encapsulated code	SOP	-	DIP	DIP	-	DIP
Encapsulate equivalent code	SOP16,.3	-	DIP16,.3	DIP16,.3	-	DIP16,.3
Package shape	RECTANGULAR	-	RECTANGULAR	RECTANGULAR	-	RECTANGULAR
Package form	SMALL OUTLINE	-	IN-LINE	IN-LINE	-	IN-LINE
Play/record mode	PLAYBACK AND RECORD	-	PLAYBACK AND RECORD	PLAYBACK AND RECORD	-	PLAYBACK AND RECORD
power supply	12 V	-	9 V	12 V	-	15 V
Certification status	Not Qualified	-	Not Qualified	Not Qualified	-	Not Qualified
Maximum seat height	2.25 mm	-	5.08 mm	5.08 mm	-	5.08 mm
Maximum slew rate	7.5 mA	-	7.5 mA	7.5 mA	-	7.5 mA
Maximum supply voltage (Vsup)	16 V	-	16 V	16 V	-	16 V
Minimum supply voltage (Vsup)	8.5 V	-	6.5 V	8.5 V	-	11.5 V
surface mount	YES	-	NO	NO	-	NO
technology	BIPOLAR	-	BIPOLAR	BIPOLAR	-	BIPOLAR
Temperature level	OTHER	-	OTHER	OTHER	-	OTHER
Terminal surface	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)	Tin/Lead (Sn/Pb)	-	Tin/Lead (Sn/Pb)
Terminal form	GULL WING	-	THROUGH-HOLE	THROUGH-HOLE	-	THROUGH-HOLE
Terminal pitch	1.27 mm	-	2.54 mm	2.54 mm	-	2.54 mm
Terminal location	DUAL	-	DUAL	DUAL	-	DUAL
width	5.3 mm	-	7.62 mm	7.62 mm	-	7.62 mm
