BO LYMIN
BL1602A
Feature
1. OLED Display
2. COB with metal frame
3. 5x7 dots with cursor
4. Software command same as KS0066
5. + 5V single power supply
6. 1/16 duty cycle
7. Color: yellow green
Mechanical Data
Item
Standard Value
Module Dimension
80.0 x 36.0
Viewing Area
56.0 x 13.8
Dot Size
0.51 x 0.63
Character Size
2.67 x 5.01
Pin Assignment
Pin
Symbol
1
Vss
2
3
4
5
6
7 ~ 14
15
16
Vdd
VBT
RS
R/W
E
DB0 ~ 7
NC
NC
Unit
mm
mm
mm
mm
Electronic Characteristics
Function
GND
+5V
+2.5V(typical)
H/L register select signal
H/L read/write signal
H --> L enable signal
H/L data bus line
Symbol Condition
Typical
Unit
Value
Input Voltage
Vdd
Vdd = +5V
5.0
V
Supply Current
Idd
mA
Vdd = +5V 15
Pixel Brightness
lu
Vbt = +3V 35 cd/m
2
Item
Dimension
80.0
±
0.5
71.2
66.0
50.67(AA)
2.0
13.8(VA)
P2.54*15=38.1
1.8
16-Ø1.0 PTH
9.4
4.8
4.95
7.55
12.45
8.0
3.2
2.67
0.54
0.51
0.53
5.7
10.3
12.55
2.5
18.3
16
36.0
±
0.5
25.2
16.0
10.36(AA)
31.0
56.0(VA)
2.5
75.0
4-Ø2.5 PTH
4-Ø5.0 PAD
1.6
0.34
5.35
5.01
0.63
0.6
DOT SIZE
SCALE 5/1
