SMV1205C-LF: Descriptionvoltage-controlled oscillator surface mount module; File Size65KB，2 Pages; ManufacturerZ-Communications, Inc.; Websitehttps://www.zcomm.com/

Download Datasheet View All

SMV1205C-LF Overview

voltage-controlled oscillator surface mount module

Preview

Download Datasheet

View All

SMV1205C-LF

PHASE NOISE (1 Hz BW, typical)

9939 Via Pasar | San Diego, CA 92126

TEL: (858) 621-2700 | FAX: (858) 621-2722

URL: www.zcomm.com

EMAIL: applications@zcomm.com

Rev A1

Applications

•

Digital Cellular

•

GPS

•

Test Equipment

Application Notes

• AN-101: Mounting and Grounding

• AN-102: Output Loading

• AN-107: Manual Soldering

£(f) (dBc/Hz)

Voltage-Controlled Oscillator

Surface Mount Module

OFFSET (Hz)

Performance Specifications

Oscillation Frequency Range

Phase Noise @ 10 kHz offset (1 Hz BW)

Harmonic Suppression (2nd)

Tuning Voltage

Tuning Sensitivity (avg.)

Power Output

Load Impedance

Input Capacitance

Pushing

Pulling (20. dB Return Loss, Any Phase)

Operating Temperature Range

Package Style

Power Supply Requirements

Supply Voltage (Vcc, nom.)

Supply Current (Icc)

Additional Notes

Min

1185

Typ

-103

-17

Max

1225

-11

2.8

Units

MHz

dBc/Hz

dBc

Vdc

MHz/V

dBm

MHz/V

MHz

°C

0.5

-3.5

.75

-40

SUB-L

Min

Typ

3.3

Max

Units

Vdc

LFSuffix = RoHS Compliant. All specifications are subject to change without notice.

Page 1 of 2

FRM-S-002 B
