SE2576L
2.4 GHz High Power Wireless LAN Power Amplifier
Preliminary
Applications
IEEE802.11b DSSS WLAN
IEEE802.11g,n OFDM WLAN
Access Points
Product Description
The SE2576L is a high power 802.11bgn WLAN
power amplifier module providing the functionality of
the power amplifier, power detector, reference voltage
generator and input match.
The SE2576L is designed for ease of use and
maximum flexibility, with an integrated input match,
and external output match to adjust the load line for
5V, 26dBm operation.
The SE2576L includes a temperature compensated
transmit power detector with over 20 dB of dynamic
range and <1.2dB variation under 3:1 mismatch at the
antenna.
The SE2576L includes a digital enable control due to
an integrated reference voltage generator. The power
ramp rise/fall time is 0.5
μs
typical.
Features
Dual Mode IEEE802.11b, IEEE802.11g,
IEEE802.11n
26 dBm, EVM = 3%, 802.11g, OFDM 54 Mbps
29 dBm, ACPR < -32 dBc, 802.11b
Integrated PA, Input Match, 2.8V reference
voltage generator
Integrated Temperature Compensated, Positive
Slope Power Detector
Pb-free, RoHS compliant and Halogen-free
3 mm x 3 mm x 0.9 mm, MSL 3
Ordering Information
Part No.
SE2576L
SE2576L-R
SE2576L-EK1
Package
16 pin QFN
16 pin QFN
N/A
Remark
Samples
Tape & Reel
Evaluation kit
Functional Block Diagram
EN
VCC
VCC2
Bias & Control
RFOUT
DET
DET
RFIN
50Ω
Figure 1: Functional Block Diagram
DST-00260
Rev 1.4
Sep-24-2009
1 of 2
SE2576L
2.4 GHz High Power Wireless LAN Power Amplifier
Preliminary
http://www.sige.com
Email: sales@sige.com
Customer Service Locations:
North America:
1050 Morrison Drive, Suite 100
Ottawa ON K2H 8K7 Canada
Phone: +1 613 820 9244
Fax: +1 613 820 4933
Hong Kong
Phone: +852 3428 7222
Fax: +852 3579 5450
San Diego
Phone: +1 858 668 3541 (ext. 226)
Fax: +1 858 668 3546
United Kingdom
Phone: +44 1279 464217
Fax: +44 1279 464201
Product Preview
The datasheet contains information from the product concept specification. SiGe Semiconductor, Inc. reserves the right to change
information at any time without notification.
Preliminary Information
The datasheet contains information from the design target specification. SiGe Semiconductor, Inc. reserves the right to change
information at any time without notification.
Production testing may not include testing of all parameters.
Information furnished is believed to be accurate and reliable and is provided on an “as is” basis. SiGe Semiconductor, Inc. assumes
no responsibility or liability for the direct or indirect consequences of use of such information nor for any infringement of patents or
other rights of third parties, which may result from its use. No license or indemnity is granted by implication or otherwise under any
patent or other intellectual property rights of SiGe Semiconductor, Inc. or third parties. Specifications mentioned in this publication
are subject to change without notice. This publication supersedes and replaces all information previously supplied. SiGe
Semiconductor, Inc. products are NOT authorized for use in implantation or life support applications or systems without express
written approval from SiGe Semiconductor, Inc.
Copyright 2009 SiGe Semiconductor, Inc.
All Rights Reserved
DST-00260
Rev 1.4
Sep-24-2009
2 of 2
