Low On-Resistance Wideband/Video Quad 2-Channel Mux/DeMux

PT2328

DESCRIPTION

The PT2328 is a true bidirectional Quad 2-channel multiplexer/ de-multiplexer utilizing CMOS

Technology. It is recommended for both RGB and composite video switching applications. The video

switch can be driven from a video DAC or a composite video source.

The very low ON-resistance and wide bandwidth make it ideal for video and other applications.

High output current which is far greater than most analog switches offered today, only need a single 5V

supply for operation. The PT2328 is a good choice to replacing the “switches + buffer amplifier”

solution in both cost and performance reasons.

FEATURES

•

Video signal switch

Wide bandwidth: 240MHz

Low On-Resistance: 5Ω, Low signal loss

Low crosstalk: 10MHz/-58dB

Extremely low power consumption

Single supply: +5V

Switching speed: 5nS

Output driver current: >100mA

16 pins, Multi-package mode

APPLICATIONS

•

LCD monitor, TV

DVD player with recorder

A/V power amplifier

A/V switching

CATV Tuner, Set-Top Box, Satellite Receiver

PT2328 V1.3

-1-

August, 2005
