HMC935LP5E

v00.0211

180° AnAlog PhAse shifter,

2 - 20 ghz

features

Wide Bandwidth: 2 - 20 Ghz

180° Phase shift

Low insertion Loss: 4 dB

Low Phase error: +20/-8 deg typ.

single Positive Voltage Control

typical Applications

the hMC935LP5e is ideal for:

• EW Receivers

• Military Radar

• Test Equipment

• Satellite Communications

• Beam Forming Modules

functional Diagram

general Description

Phase shifters - aNaLOG - sMt

electrical specifications,

= +25 °C, 50 ohm system

Parameter

Min.

180

0.5

±1

+28 / -15

+20 / -8

0.07

typ.

Max.

Units

Ghz

deg

dBm

deg/V

deg

Mhz

deg/°C

13 - 1

Phase shift range

insertion Loss

return Loss (input and output)

Control Voltage range

Control Current range

input iP3

input Power @ -5° shift in insertion Phase (Vctl = 0.5V)

input Power @ -3° shift in insertion Phase (Vctl = 3.0V)

Phase Voltage sensitivity

Phase error (peak)

[1]

frequency range

Phase error (average)

[1]

Modulation Bandwidth

insertion Phase temperature sensitivity

[1] Up to a phase shift of 180 degrees.

Information furnished by Analog Devices is believed to be accurate and reliable. However, no

For price,

20 Alpha

to place orders: Analog Devices, Inc.,

For price, delivery and to place

nor for any

Hittite Microwave Corporation,

delivery, and

Road, Chelmsford, MA 01824

responsibility is assumed by Analog Devices for its use,

orders:

infringements of patents or other

One Technology Way, P.O. Box 9106, Norwood, MA 02062-9106

rights of third parties that may result from its use. Specifications subject to change without notice. No

Phone: 978-250-3343

Fax: 978-250-3373

Phone: 781-329-4700

www.hittite.com

Order On-line at

• Order online at www.analog.com

license is granted by implication or otherwise under any patent or patent rights of Analog Devices.

Application Support: Phone: 1-800-ANALOG-D

Trademarks and registered trademarks are the property of their respective owners.

Application Support: Phone: 978-250-3343 or apps@hittite.com

the hMC935LP5e is an analog Phase shifter which

is controlled via an analog control voltage from 0.5

to +11V. the hMC935LP5e provides a continuously

variable phase shift of 0 to 180 degrees from 2 to

20 Ghz, with extremely consistent low insertion loss

versus phase shift and frequency. the high accuracy

hMC935LP5e is monotonic with respect to control

voltage and features a typical low phase error of

+20/-8 degrees. the hMC935LP5e is housed in an

rohs compliant 5 x 5 mm QfN leadless package.

32 Lead 5 x 5 mm QfN Package: 25 mm²
