Engineer’s Kit : EK-1008F-X
2.80 max
2.10 max
2.5
1008 F
0.50
2.90 max
1.0
1.43
2.43
1.3
Chip Inductors for RF Applications
(Wire wound -open)
0.50
0.23 ~ 0.50
1.20 ref
1.0
recommended layout for
solder pads
2.00
120
100
Percentage of rated Irms
80
60
40
20
0
Irms derating
Part No
Inductance
L (µH)
1.0
1.2
1.5
1.8
2.2
2.7
3.3
3.9
4.7
5.6
6.8
8.2
10
12
15
18
22
24
27
33
39
47
82
100
f
L
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
2.5
Tol
± (%)
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
min
15
25
25
25
25
25
25
25
25
25
25
25
25
24
23
23
22
22
23
22
20
21
13
8
f
Q
(MHz)
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
7.9
SRF
(MHz)
190 min
210 min
190 min
170 min
150 min
135 min
120 min
105 typ
90 typ
80 typ
70 typ
65 typ
60 typ
40 typ
35 typ
35 typ
30 typ
30 typ
30 typ
27 typ
20 typ
20 typ
14 typ
20 typ
DCR
max
(Ω)
0.32
0.68
0.76
0.84
1.10
1.28
1.46
1.56
1.68
1.82
2.00
2.65
2.95
4.80
5.00
5.80
6.80
6.80
7.70
8.90
9.20
11.0
22.0
25.0
Rated DC
Current
(mA)
500
650
630
600
520
490
450
420
400
380
360
330
300
280
260
220
200
200
190
180
190
150
60
55
0
40
60
80 100 120 140
Ambient temperature (°C)
Current carrying capacity dependent on
the ambient temperature
20
Typical Ls vs Frequency (ƒ)
60
Inductance (µH)
50
40
30
20
10
0
15.0
µH
4.7
µH
2.2
µH
1.0
µH
100
47.0
µH
1008F-1R0K-YY
1008F-1R2K-YY
1008F-1R5K-YY
1008F-1R8K-YY
1008F-2R2K-YY
1008F-2R7K-YY
1008F-3R3K-YY
1008F-3R9K-YY
*
* 1008F-4R7K-YY
* 1008F-5R6K-YY
* 1008F-6R8K-YY
* 1008F-8R2K-YY
* 1008F-100K-YY
* 1008F-120K-YY
* 1008F-150K-YY
* 1008F-180K-YY
* 1008F-220K-YY
* 1008F-240K-YY
* 1008F-270K-YY
* 1008F-330K-YY
* 1008F-390K-YY
* 1008F-470K-YY
* 1008F-820K-YY
* 1008F-101K-YY
1
10
1000
Frequency (MHz)
Material :
Ferrite
SPQ :
Reel 2000 [-01]
7500 [-04]
Revision date : 21 Sept 2012
Typical Q vs Frequency (ƒ)
40
Q Factor
30
4.7
µH
20
1.0
µH
10
47.0
µH
2.2
µH
15
µH
Remarks:
- For not listed inductance values please check availability with us.
- 2% and 5% tolerance available on request.
- All are AEC-Q200 Standard approved EXCEPT *.
0
1
10
100
1000
Frequency (MHz)
•
All dimensions in mm
