IO
SOCKETS
SERIES 898 • UNIVERSAL SERIAL BUS 3.1 TYPE C • MID-MOUNT RECEPTACLE
Ø.118
AVAILABLE
VACUUM PICK UP AREA
•
USB 3.1 Mid-Mount, Hybrid Layout
•
Full metal housing with enhanced EMI/RFI
prevention
(.393)
(.427)
•
Reversible USB Type C Connector
•
10Gbps Data rate
•
2X faster than USB 3.0 with more efficient
(.043)
Coplanarity
.004 max.
(.344)
(.362)
PIN A1
data transfer, higher through-put & improved
I/O power efficiency
Docking, Automotive & Home Entertainment
.328
PIN A12
•
For Storage, Smartphone, Tablet, Notebook,
.092
CH=.033
.047
.043
.039
.007
(X12)
.283
.324
.482
.051
.118
.049
.305
ORDERING INFORMATION
Mid-Mount Type C Receptacle, Hybrid Layout
PIN B12
PIN B1
.101
FIG. 1
RECOMMENDED
PCB THICKNESS
PITCH
898-43-024-90-310000
.244
.035
.018
.035”
(Tape & Reel Packaged, 900 parts per 13” reel)
Ø.024
.0157
TYP.
.008
(X12)
.0197
.2165
PITCH
.0315
Technical Specifications
Materials:
2011/65/EU
Terminals: Copper Alloy, Tin-Plated
Contacts: Copper Alloy, 30
μ”
Gold-Plated
Casing and Shield: Stainless Steel
Insulator material: High temperature thermoplastic rated UL94V-0
General Specifications:
Temperature Range:
Operating: -55°C to +85°C
Nominal: +20°C
Electrical:
Voltage: 50VAC (rms)
LLCR: 40mW (initial),
D10mW (after)
Dielectric Strength: 100VAC
Insulation resistance: 100MW min.
Current Rating: VBUS and GND contacts rated @ 1.25A each,
paralleled for a total of 5A
Mechanical:
Durability: 10,000 cycles
Insertion force: 20 Newtons max.
Extraction force: 8 Newtons min., 20 Newtons max.
RoHS - 2
.2165
.0335
.0197
.0492
.0354
.0177
.0276
.001(X12)
.012
.001(X4)
.002
A B C
.0984
.0837
.012
.001(X12)
.002
A B C
.002
A B C
.0197
.001(X4)
.002
A B C
A1
A12
.026
B12
B1
C
.0374
.002(X2)
.002
A B C
.244
.002
A B C
B
Ø.0157
.001(X12)
.244
Ø.0256
.001(X12)
.001
A B C
.0315
.063
.083
+.004
(X2)
-0
THROUGH HOLE
.0315
.067
.002(X2)
7
LAND
.0157
.047
+.004
(X2)
-0
THROUGH HOLE
R
.0374
.001
(.0787)
PAGE 149.1 | IO SOCKETS
P.C.B EDGE
.021
.0996
(X
2)
.110
.283
.325
.364
.482
.110
.0197
.002(X4)
THROUGH HOLE
.002
A B C
.0354
+.004
(X4)
-0
LAND
RECOMMENDED PCB LAYOUT
THICKNESS IS .035”
TOLERANCE
.002”
FIG. 1
Mill-Max Mfg. Corp. • 190 Pine Hollow Road, P.O. Box 300, Oyster Bay, NY 11771 • 516-922-6000 • Fax: 516-922-9253 • www.mill-max.com
