1. PHYSICAL DIMENSIONS
Ø0.188(2X)
REVISION
REV.
B
DESCRIPTION
RoHS Compliancy
DATE
06-01-06
APPROVED
LY
ELECTRICAL CHARACTERISTICS:
1-1.
VOLTAGE RATING...................................115/250VAC
1-2.
CURRENT RATING
A. @ 115 VAC........................................3 A RMS MAX
B. @ 250 VAC........................................3 A RMS MAX
OPERATING FREQUENCY......................50/60Hz
LEAKAGE CURRENT: EACH LINE TO GROUND
A. @ 115 VAC 60Hz............................0.25 mA MAX
B. @ 250 VAC 50Hz.............................0.45 mA MAX
HIPOT RATING (FOR ONE MINUTE)
A. LINE TO GROUND...........................2250 VDC
B. LINE TO LINE.....................................1450 VDC
MINIMUM INSERTION LOSS IN dB: (AT 50 OHM SYSTEM)
.01
/
/
.05
/
/
.10
/
/
.15
22
10
.50
30
46
1.0
38
48
5.0
47
50
10
50
50
30
40
45
1-3.
BLUE
2.38 ± 0.02
2.04MAX
G/Y
BROWN
BLUE
2.79MAX
1-4.
BROWN
1-5.
1-6.
FREQ. MHz
4.0MIN
1.83MAX
1.16MAX
COM. MODE dB
DIF. MODE dB
1-7.
1-8.
1-9.
OPERATING TEMPERATURE.................-25° TO +100° C
SAFETY:
RoHS COMPLIANT
2. ELECTRICAL SCHEMATIC
Dim
range
(mm)
Tolerance
+/-
(mm)
0.15
0.20
0.30
0.50
0.70
0.90
1.20
CONTROLLED
Qualtek Electronics Corp.
Part Number:
Description:
L: 3.2mH
C1: 0.22uF
C2: 3300pF
R: 2.2MΩ
PPC DIVISION
853-03/004
EMI FILTER
UNIT: in
0-1
1-6
6-18
18-50
50-120
120-250
250-500
REV. B
Approved / Date
JJH / 07-09-03
Drawn / Date
B.Zhang
07-09-03
Checked / Date
07-09-03
