Chip Inductors – 0603HP Series (1608)
•
•
•
•
Higher Q and lower DCR than other 0603 inductors
Highest SRF values – as high as 16 GHz
Excellent current handling capability – up to 2100 mA
54 inductance values from 1.8 to 390 nH
Core material
Ceramic
Environmental
RoHS compliant, halogen free
Terminations
Silver-palladium-platinum-glass frit. Other terminations
available at additional cost.
Weight
2.0 – 3.2 mg
Ambient temperature
–40°C to +125°C with
Irms
current
Maximum part temperature
+140°C (ambient + temp rise).
Storage temperature
Component: –40°C to +140°C.
Tape and reel packaging: –40°C to +80°C
Resistance to soldering heat
Max three 40 second reflows at
+260°C, parts cooled to room temperature between cycles
Temperature Coefficient of Inductance (TCL)
+25 to +125 ppm/°C
Moisture Sensitivity Level (MSL)
1 (unlimited floor life at <30°C /
85% relative humidity)
Failures in Time (FIT) / Mean Time Between Failures (MTBF)
One per billion hours / one billion hours, calculated per Telcordia SR-332
Packaging
2000 per 7″ reel. Paper tape: 8 mm wide, 1 mm thick,
4 mm pocket spacing
PCB washing
Tested to MIL-STD-202 Method 215 plus an additional
aqueous wash. See
Doc787_PCB_Washing.pdf.
C
D
Pick and
place
material
Typical Q vs Frequency
160
140
120
100
24 nH
80
60
40
20
0
10
100
1000
10000
330 nH
51 nH
82 nH
150 nH
10 nH
Q Factor
B
overall
H
I
J
I
F
A
G
F
E
terminal
Terminal wraparound:
approx 0.01/0,24 both ends
Frequency (MHz)
Typical L vs Frequency
1000
330 nH
150 nH
82 nH
Recommended
Land Pattern
H
I
J
A
max
1,75
B
C
(min
–
max) max
0,86 – 1,09
0,94
D
E
F
G
0.069 0.034 – 0.043 0.037 0.015 0.029 0.013 0.038 0.040 0.027 0.028 inches
0,38 0,74 0,33
0,96 1,02 0,69 0,71 mm
Note:
Height dimension (C) is before optional solder application. For maximum
height dimension including solder, add 0.006 in / 0,152 mm.
Inductance (nH)
100
51 nH
24 nH
10
10 nH
1
10
100
1000
10000
Frequency (MHz)
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 537-1
Revised 10/12/15
© Coilcraft Inc. 2017
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
Document 537-2
0603HP Series (1608)
Inductance
2
Percent
1
Part number
(nH)
tol
0603HP-1N8XJE_
1.8
5
0603HP-2N2XJE_
2.2
5
0603HP-3N3X_E_
3.3
5,3,2
0603HP-3N6X_E_
3.6
5,3,2
0603HP-3N9X_E_
3.9
5,3,2
0603HP-4N3X_E_
4.3
5,3,2
0603HP-4N7X_E_
4.7
5,3,2
0603HP-5N1X_E_
5.1
5,3,2
0603HP-5N6X_E_
5.6
5,3,2
0603HP-6N0X_E_
6.0
5,3,2
0603HP-6N8X_E_
6.8
5,3,2
0603HP-7N2X_E_
7.2
5,3,2
0603HP-7N5X_E_
7.5
5,3,2
0603HP-8N2X_E_
8.2
5,3,2
0603HP-8N7X_E_
8.7
5,3,2
0603HP-9N1X_E_
9.1
5,3,2
0603HP-9N5X_E_
9.5
5,3,2
0603HP-10NX_E_
10
5,3,2
0603HP-11NX_E_
11
5,3,2
0603HP-12NX_E_
12
5,3,2
0603HP-15NX_E_
15
5,3,2
0603HP-16NX_E_
16
5,3,2
0603HP-18NX_E_
18
5,3,2
0603HP-22NX_E_
22
5,3,2
0603HP-23NX_E_
23
5,3,2
0603HP-24NX_E_
24
5,3,2
0603HP-27NX_E_
27
5,3,2
0603HP-30NX_E_
30
5,3,2
0603HP-33NX_E_
33
5,3,2
0603HP-36NX_E_
36
5,3,2
0603HP-39NX_E_
39
5,3,2
0603HP-43NX_E_
43
5,3,2
0603HP-47NX_E_
47
5,3,2
0603HP-51NX_E_
51
5,3,2
0603HP-56NX_E_
56
5,3,2
0603HP-68NX_E_
68
5,3,2
0603HP-72NX_E_
72
5,3,2
0603HP-75NX_E_
75
5,3,2
0603HP-82NX_E_
82
5,3,2
0603HP-91NX_E_
91
5,3,2
0603HP-R10X_E_ 100
5,3,2
0603HP-R11X_E_ 110
5,3,2
0603HP-R12X_E_ 120
5,3,2
0603HP-R15X_E_ 150
5,3,2
0603HP-R18X_E_ 180
5,3,2
0603HP-R20X_E_ 200
5,3,2
0603HP-R21X_E_ 210
5,3,2
0603HP-R22X_E_ 220
5,3,2
0603HP-R25X_E_ 250
5,3,2
0603HP-R27X_E_ 270
5,3,2
0603HP-R30X_E_ 300
5,3,2
0603HP-R33X_E_ 330
5,3,2
0603HP-R36X_E_ 360
5,3,2
0603HP-R39X_E_ 390
5,3,2
L test
Q typ
freq
at
(MHz) 250 MHz
250
23
250
13
250
32
250
40
250
35
250
30
250
26
250
40
250
48
250
49
250
42
250
48
250
41
250
46
250
46
250
40
250
49
250
49
250
41
250
37
250
48
250
45
250
41
250
44
250
40
250
42
250
44
250
49
250
45
250
44
250
48
250
45
200
47
200
49
200
50
200
46
150
46
150
46
150
45
150
45
150
49
150
47
150
47
150
47
100
48
100
47
100
48
100
47
100
45
100
46
100
47
100
46
100
47
100
47
Designer’s Kits C406A
and
B
contain 10 each of all 5% values
Designer’s Kits C406A-2
and
B-2
contain 10 each of all 2% values
900 MHz
L typ Q typ
3
1.77
40
2.14
25
3.28
67
3.59
70
3.88
68
4.29
58
4.65
48
5.08
84
5.60
87
5.92
94
6.83
88
7.25
96
7.55
81
8.21
96
8.73
97
9.18
76
9.56
98
10.16
90
11.06
78
12.26
69
15.41
83
16.37
77
18.56
76
22.7
77
24.0
69
24.9
77
28.4
74
31.5
82
34.9
76
38.5
69
41.5
78
45.7
83
50.6
77
54.6
73
60.3
74
75.5
73
80.8
69
84.6
71
94.0
62
103.0
64
114.0
69
126.2
63
142.4
61
188.8
57
232.2
50
265.0
47
288.0
45
315.0
41
—
—
—
—
—
—
—
—
—
—
—
—
1.7 GHz
L typ Q typ
3
1.77
65
2.12
35
3.32
104
3.62
116
3.95
108
4.31
91
4.71
75
5.12
140
5.73
145
6.12
154
7.05
143
7.38
139
7.85
112
8.39
148
9.00
149
9.64
109
9.99
149
10.64
142
11.82
108
13.20
91
17.20
124
18.70
116
20.90
100
25.90
88
29.53
80
28.90
91
34.00
84
37.90
82
42.90
80
50.00
64
51.90
74
58.10
76
66.90
72
71.30
62
79.90
56
113.3
49
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
—
SRF
typ
4
(GHz)
16.0
15.0
9.60
9.70
7.50
7.50
7.90
8.90
6.60
6.00
5.80
5.40
5.30
5.90
5.50
5.10
4.90
4.30
4.10
4.10
3.60
3.50
3.30
3.15
3.00
2.95
2.80
2.80
2.70
2.50
2.45
2.45
2.30
2.30
2.20
2.00
1.90
1.90
1.80
1.65
1.70
1.60
1.55
1.35
1.30
1.25
1.20
1.10
1.05
1.05
0.99
0.93
0.93
0.88
DCR
max
5
(Ohms)
0.033
0.180
0.024
0.031
0.039
0.080
0.100
0.036
0.036
0.036
0.042
0.052
0.080
0.054
0.054
0.037
0.053
0.048
0.058
0.088
0.078
0.085
0.066
0.140
0.183
0.074
0.150
0.130
0.170
0.225
0.19
0.17
0.24
0.28
0.30
0.33
0.42
0.52
0.46
0.58
0.54
0.58
0.72
0.82
1.50
2.00
2.00
2.00
3.00
2.25
2.80
3.60
4.00
4.00
Irms
6
(mA)
2100
900
1900
1900
1600
1300
1100
1700
1700
1700
1400
1400
1300
1400
1400
1400
1400
1400
1400
1100
1200
1100
1200
850
850
1100
780
920
680
720
680
810
680
660
610
600
550
500
510
440
470
440
420
390
310
280
280
280
240
260
220
180
170
170
Color
code
7
Black
Yellow
Blue
Red
Brown
Orange
Violet
Green
Black
White
Red
Green
Brown
Orange
Yellow
Black
Blue
Orange
Gray
Yellow
Green
White
Blue
Violet
Orange
Black
Gray
Brown
White
Red
Black
Orange
Brown
Blue
Red
Orange
Yellow
Violet
Green
White
Blue
Violet
Gray
White
Black
Green
Gray
Brown
Violet
Red
Green
Blue
Gray
Yellow
1. When ordering, please specify
tolerance, termination
and
packaging
codes:
0603HP-R39XJEW
G
= 2%
H
= 3%
J
= 5%
(Table shows stock tolerances in bold.)
Termination: E
= Halogen free component. RoHS compliant silver-palla-
dium-platinum-glass frit terminations.
L
= RoHS compliant, not halogen-free. Silver-palladium-
platinum-glass frit terminations.
Special order:
T
= RoHS tin-silver-copper (95.5/4/0.5) or
S
= non-RoHS tin-lead (63/37).
Packaging: W
= 7″ machine-ready reel. EIA-481 punched paper tape
(2000 parts per full reel).
U
= Less than full reel. In tape, but not machine ready. To
have a leader and trailer added ($25 charge), use code
letter W instead.
Tolerance:
2. Inductance tested at listed frequency using an Agilent/HP 4286A impedance
analyzer with a Coilcraft SMD-A fixture and Coilcraft-provided correlation
pieces.
3. Q measured using an Agilent/HP 16197 test fixture in an Agilent/HP 4291
impedance analyzer.
4. SRF measured using an Agilent/HP 8722ES network analyzer and a Coil-
craft SMD-D test fixture.
5. DCR measured on a micro-ohmmeter and a Coilcraft CCF858 test fixture.
6. Current that causes a 15°C temperature rise from 25°C ambient. This
information is for reference only and does not represent absolute maximum
ratings.
7. Each part is marked with a single dot. The color dots are not unique identi-
fiers and correspond to multiple inductance values.
8. Electrical specifications at 25°C.
Refer to Doc 362 “Soldering Surface Mount Components” before soldering.
US
+1-847-639-6400 sales@coilcraft.com
UK
+44-1236-730595 sales@coilcraft-europe.com
Taiwan
+886-2-2264 3646 sales@coilcraft.com.tw
China
+86-21-6218 8074 sales@coilcraft.com.cn
Singapore
+ 65-6484 8412 sales@coilcraft.com.sg
Document 537-2
Revised 10/12/15
© Coilcraft Inc. 2017
This product may not be used in medical or high
risk applications without prior Coilcraft approval.
Specification subject to change without notice.
Please check web site for latest information.
