CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
SL
Low Profile
(φ6.3)
series
Low ESR, High Capacitance, High ripple current.
Low Profile(Height 4.2mm).
Load life of 2000 hours at 105°C.
SMD type : Lead free reflow soldering condition at
260°C peak correspondence.
Compliant to the RoHS directive (2011/65/EU).
SA
Lower Profile
SL
Specifications
Item
Category Temperature Range
Rated Voltage Range
Rated Capacitance Range
Capacitance Tolerance
Tangent of loss angle (tan
δ)
ESR ( 1)
Leakage Current ( 2)
–55 to
+105°C
2.5 to 25V
15 to 330µF
±20% at 120Hz, 20°C
Less than or equal to the specified value at 120Hz, 20°C
Less than or equal to the specified value at 100kHz, 20°C
Less than or equal to the specified value.
Test condition
Capacitance change
Endurance
tan
δ
ESR( 1)
Leakage current ( 2)
After 2 minutes' application of rated voltage at 20°C
Performance Characteristics
105°C, rated voltage 2000Hrs.
Within ±20% of initial value before test
150% or less than the initial specified value
150% or less than the initial specified value
Less than or equal to the initial specified value
1 ESR should be measured at both of the terminal ends closest where the terminals protrude through the plastic platform.
2 Conditioning : If any doubt arises, measure the leakage current after the voltage treatment of applying DC rated voltage continuously to the capacitor for 120
minutes at 105°C.
Size List (ESR)
Cap [µF]
15
100
150
220
330
R.V.(V)
S.V.(
V)
[Upper value :
φD
×
L(mm),
Lower value : ESR(mΩ)]
2.5
2.8
6.3
7.2
16
18.4
6.3×4.2
(45)
25
28.7
6.3×4.2
(55)
6.3×4.2
(16)
6.3×4.2
(16)
6.3×4.2
(16)
6.3×4.2
(18)
6.3×4.2
(18)
6.3×4.2
(18)
(mm)
φD×L
6.3×4.2
W
6.5
H
6.5
C
7.2
R
0.5
to
0.9
P
2.1
Dimension table in next page.
CAT.8100D
CONDUCTIVE POLYMER ALUMINUM SOLID ELECTROLYTIC CAPACITORS
SL
series
Standard Ratings
Rated Voltage Surge
Voltage
(V)
(V)
(code)
Rated
Capacitance
(µF)
Case Size
φD
×L
(mm)
tan
δ
Leakage
Current
(µA, 2min.)
ESR
(mΩ, 100kHz)
Rated Ripple
Current
(mArms)
NICHICON
FPCAP
100
2.5
(0E)
2.8
220
330
100
6.3
(0J)
7.2
150
220
16
(1C)
25
(1E)
18.4
28.7
15
15
6.3×4.2
6.3×4.2
6.3×4.2
6.3×4.2
6.3×4.2
6.3×4.2
6.3×4.2
6.3×4.2
0.12
0.12
0.12
0.12
0.12
0.12
0.12
0.12
300
300
413
315
473
693
300
100
16
16
16
18
18
18
45
55
3500
3500
3500
3200
3200
3200
1900
1700
RSL0E101MCN1GB
RSL0E221MCN1GB
RSL0E331MCN1GB
RSL0J101MCN1GB
RSL0J151MCN1GB
RSL0J221MCN1GB
RSL1C150MCN1GB
RSL1E150MCN1GB
FP-2R5ME101M-SLR
FP-2R5ME221M-SLR
FP-2R5ME331M-SLR
FP-6R3ME101M-SLR
FP-6R3ME151M-SLR
FP-6R3ME221M-SLR
FP-016ME150M-SLR
FP-025ME150M-SLR
Frequency Characteristics
(The frequency characteristics are typical and not a guaranteed value.)
6.3V 220 µF
6.3V 220µF
Impedance
Frequency (kHz)
Frequency (kHz)
Taping specifications are given in page 28.
Recommended land size, soldering by reflow are given in page 25.
Please refer to page 3 for the minimum order quantity.
CAT.8100D
