BT830 Series

Bluetooth v4.0 Class 1 UART HCI Modules

The BT830 series of UART HCI modules are a complement to Laird’s original

dual-mode Bluetooth v4.0 offerings (BT800 series), bringing support for

Classic Bluetooth and Bluetooth Low Energy (BLE) in a tiny footprint.

Leveraging the market-leading CSR 8811 chipset, the BT830 series

provides exceptionally low power consumption with outstanding range.

Supporting the latest Bluetooth v4.0 Specification with EDR (Enhanced

Data Rate), the Laird BT830 series enables OEMs to accelerate their

development time for leveraging either Classic Bluetooth or Bluetooth

Low Energy (BLE) into their operating system-based devices.

BT830-ST

The BT830 has a footprint as small as 8.5 x 13 mm, yet output power at 7

dBm. This makes these modules ideal for applications where designers

need both performance and minimum size. For maximum flexibility in

systems integration, the modules are designed to support a UART

interface plus GPIO and additionally I

S and PCM audio interfaces.

These modules present an HCI interface and have native support for

Windows CE/Mobile and Linux Bluetooth software stacks. All BT830 series

devices are fully qualified by the Bluetooth SIG as a Hardware Controller

Subsystem. This also allows designers to integrate their existing pre-

approved Bluetooth Host and Profile subsystem stacks to gain a Bluetooth

END product approval for their products.

The BT830 series is engineered to provide excellent RF performance with

options for an integrated antenna or for an external antenna via a trace

pin. Additionally, the modules have on-board band pass filters to further

reduce the regulatory and testing requirements for OEMs, ensuring a

hassle-free development cycle.

A fully featured, low-cost developer’s kit is available for prototyping,

debug, and integration testing of the BT830 series modules and further

reduces risk and time in development cycles.

BT830-SA

Features & Benefits



Application Areas



Bluetooth v4.0 - Dual Mode

Classic Bluetooth

Bluetooth Low Energy

Compact Footprint

Class 1 output 7 dBm

UART, GPIO, I2S, and PCM

Industrial Temperature Range

Bluetooth SIG approvals

FCC, IC, and CE approvals

AIDC products

Medical devices

ePOS terminals

Barcode Scanners

Industrial Cable

Replacement

M2M Connectivity

Automotive Diagnostic

Equipment

USA: +1.800.492.2320

Europe: +44.1628.858.940

Asia: +852.2923.0610

wirelessinfo@lairdtech.com

www.lairdtech.com/bluetooth

Support Portal:

http://ews-support.lairdtech.com

The details contained within this document are subject to change.

Download the product specification from

www.lairdtech.com/bluetooth

for the most current specification.
