High Temperature (+200°C), High Voltage
Radial Ceramic Cased Capacitors (C3)
VCR/VRR Series
Ceramic cased capacitors, with a new, unique design concept which eliminates potential problems associated with conven-
tional epoxy cased epoxy potted capacitors.
Major application is high voltage power supplies. High voltage capacitors are also utilized on high voltage meter multiplier and
RF circuits.
INSTALLATION:
Parts should be soldered using a heat sink between the soldering point and the part using a soldering iron rated 18-30 watts.
Remove all traces of flux or other contamination resulting from the soldering operation. An intermittent conducting path
between the leads, at high voltage, could cause breakdown. Soldering temperature should not exceed +300°C.
PART NUMBER AND ORDERING INFORMATION
V
PRODUCT FAMILY
V = High Voltage Radial
Capacitors
C
R
40
M 102
K
W A
TEST LEVEL
S = KEMET standard screening
A = MIL-PRF-20, Group A Test
X = Special
TEMP. CHARACTERISTIC
C = C0G (NP0)/BP
R = X7R (BX)
LEAD MATERIALS
G = Gold plated Copper clad steel
W = Solder coated Copper clad steel
LEAD CONFIGURATION
R = Radial
CAPACITANCE TOLERANCES
J = ±5%
M = ±20%
K = ±10%
Other tolerances available upon request
STYLE
Case Size.
See data sheet for detail dimensions
VOLTAGE RATING
L = 500vdc
M = 1000vdc
T = 2000vdc
V = 3000vdc
W = 4000vdc
X = 5000vdc
CAPACITANCE CODE
3 Digit code system expressed in
picofarads (pF)
103 = 10,000pF
151 = 150pF
MARKING
Manufacturer’s ID
Capacitance
Voltage
Date Code
EXAMPLE
KEC
106J
500V
123
© KEMET Electronics Corporation • PO Box 5928 • Greenville, SC 29606 • www.kemet.com
23
High Temperature (+200°C), High Voltage
Radial Ceramic Cased Capacitors (C3)
VCR Series
S
RADIAL
All Dimensions
in Inches (mm)
C0G DIELECTRIC
STYLE
LMAX
W MAX
TMAX
S
d
Cap
Code
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
393
473
563
07
.300 (7.62)
.300 (7.62)
.150 (3.81)
.200 ± .015
(5.08 ± .38)
.025 ± .002
(.635 ±.051)
WVDC
500
1k
2k
500
1k
40
.350 (8.89)
.400 (10.16)
.275 (6.98)
.300 ± .015
(7.62 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
3k
4k
500
1k
50
.450 (11.43)
.500 (12.70)
.300 (7.62)
.400 ± .015
(10.16 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
3k
4k
5k
500
1k
60
.550 (13.97)
.600 (15.24)
.375 (9.52)
.500 ± .015
(12.70 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
3k
4k
5k
500
1k
70
.650 (16.51)
.700 (17.78)
.375 (9.52)
.600 ± .015
(15.24 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
3k
4k
5k
500
1k
80
.750 (19.05)
.800 (20.32)
.375 ( 9.52)
.600 ± .015
(15.24 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
3k
4k
5k
Cap
10 pF
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
0.01
μF
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
24
© KEMET Electronics Corporation • PO Box 5928 • Greenville, SC 29606 • www.kemet.com
High Temperature (+200ºC), High Voltage
Axial and Radial Ceramic Cased Capacitors (C3)
VRR Series
S
RADIAL
All Dimensions
in Inches (mm)
X7R DIELECTRIC
STYLE
LMAX
W MAX
TMAX
S
d
Cap
Code
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
123
153
183
223
273
333
393
473
563
683
823
104
124
154
184
224
274
334
394
474
564
684
824
105
125
07
.300 (7.62)
.300 (7.62)
.150 (3.81)
.200 ± .015
(5.08 ± .38)
.025 ± .002
(.635 ±.051)
WVDC
500 1k
40
.350 (8.89)
.400 (10.16)
.275 (6.98)
.300 ± .015
(7.62 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k 500 1k
2k 3k
4k
500 1k
50
.450 (11.43)
.500 (12.70)
.300 (7.62)
.400 ± .015
(10.16 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
2k
60
.550 (13.97)
.600 (15.24)
.375 (9.52)
.500 ± .015
(12.70 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
70
.650 (16.51)
.700 (17.78)
.375 (9.52)
.600 ± .015
(15.24 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
80
.750 (19.05)
.800 (20.32)
.375 ( 9.52)
.600 ± .015
(15.24 ± .38)
.032 ± .004
(.813 ± .102)
WVDC
Cap
330pF
390
470
560
680
820
1000
1200
1500
1800
2200
2700
3300
3900
4700
5600
6800
8200
0.01
μF
0.012
0.015
0.018
0.022
0.027
0.033
0.039
0.047
0.056
0.068
0.082
0.10
0.12
0.15
0.18
0.22
0.27
0.33
0.39
0.47
0.56
0.68
0.82
1.0
1.2
3k 4k 5k 500 1k 2k 3k 4k 5k 500 1k 2k 3k 4k 5k 500 1k 2k 3k 4k 5k
© KEMET Electronics Corporation • PO Box 5928 • Greenville, SC 29606 • www.kemet.com
25
