MULTILAYER CERAMIC CHIP CAPACITORS
CGA3EA Series
Automotive Grade
ESD Protection
Case size:
1608 [EIA CC0603]
lssue date:
Dec 2014
20141219 / mlcc_automotive_esd_en
MULTILAYER CERAMIC CHIP CAPACITORS
REMINDERS
Please read before using this product
SAFETY REMINDERS
REMINDERS
1.
2.
3.
If you intend to use a product listed in this catalog for a purpose that may cause loss of life or other damage,
you must contact our company’s sales window.
We may modify products or discontinue production of a product listed in this catalog without prior notification.
We provide “Delivery Specification” that explain precautions for the specifications and safety of each product
listed in this catalog. We strongly recommend that you exchange these delivery specifications with customers
that use one of these products.
If you plan to export a product listed in this catalog, keep in mind that it may be a restricted item according
to the “Foreign Exchange and Foreign Trade Control Law”. In such cases, it is necessary to acquire export
permission in harmony with this law.
Any reproduction or transferring of the contents of this catalog is prohibited without prior permission from our
company.
We are not responsible for problems that occur related to the intellectual property rights or other rights of our
company or a third party when you use a product listed in this catalog. We do not grant license of these rights.
This catalog only applies to products purchased through our company or one of our company’s official agencies.
This catalog does not apply to products that are purchased through other third parties.
4.
5.
6.
7.
Notice: Effective January 2013, TDK will use a new catalog number which adds product thickness and packaging
specification detail. This new catalog number should be referenced on all catalog orders going forward, and
is not applicable for OEM part number orders. Please be aware the last five digits of the catalog number will
differ from the item description (internal control number) on the product label. Contact your local TDK Sales
representative for more information.
(Example)
Catalog Issued date
Prior to January 2013
January 2013 and Later
Catalog Number
C1608C0G1E103J
C1608C0G1E103J080AA
Item Description (On Delivery Label)
C1608C0G1E103JT000N
C1608C0G1E103JT000N
Page 1
20141219 / mlcc_automotive_esd_en
MULTILAYER CERAMIC CHIP CAPACITORS
CGA3EA
Series
ESD Protection
Case size: 1608 [EIA CC0603]
Features
• The amount of static electricity that is charged and
generated from the human body is generally thousands of
volts or more. This series consists of in-vehicle products
that protect electronic components from static electricity.
• The series has passed the most rigorous level (level 4-
8000V) of ESD tests for contact discharge described under
the IEC61000-4-2 international standard.
• Available in both C0G (125°C max) and NP0 (150°C max)
temperature characteristics, and can be used in applica-
tions that require high reliability, even in cars.
• AEC-Q200 compliant.
Applications
• Input-output sections of various in-vehicle
applications such as ECUs (run, turn and
stop), keyless entry systems, and car
navigation systems.
Shape &
Dimensions
L
W
T
B
G
Body Length
Body Width
Body Height
Terminal Width
Terminal Spacing
Catalog Number
Construction
Series Name
Dimensions L x W (mm)
Code
3
Length
1.60 ± 0.10
CGA
•
3
•
E
•
A
•
NP0
•
2A
•
103
•
J
•
080
•
A
•
C
Width
0.80 ± 0.10
Terminal
0.20 min.
Thickness T Code (mm)
Code
E
Thickness
0.80 mm
Function identification code
Code
A
Description
ESD Protection
Temperature Characteristics
Temperature
Temperature Coefficient or
Characteristics
Capacitance Change
C0G
0 ± 30 ppm/°C
NP0
0 ± 30 ppm/°C
Temperature
Range
-55 to +125°C
-55 to +150°C
Rated Voltage (DC)
Code
Voltage (DC)
2A
100V
Nominal Capacitance (pF)
The capacitance is expressed in three digit codes and in units of pico Farads (pF).
The first and second digits identify the first and second significant figures of the
capacitance. The third digit identifies the multiplier.
Ex.
472 = 4,700pH = 4.7nF ; 103 = 10,000pF = 10nF
Capacitance Tolerance
Code
J
Tolerance
± 5%
Nominal Thickness
Code
Thickness
Packaging Style
Code
A
Style
178 mm Reel, 4 mm Pitch
080
0.80 mm
Special Reserved Code
Code
Description
TDK Internal Code
A, C
Page 2
• All specifications are subject to change without notice.
20141219 / mlcc_automotive_esd_en
MULTILAYER CERAMIC CHIP CAPACITORS
Capacitance
Range Chart
Capacitance Range Chart
Temperature
Characteristics:
C0G (0 ± 30ppm/°C)、NP0 (0 ± 30ppm/°C)
Rated
Voltage:
100V(2A)
Capacitance
(pF)
1,000
1,500
2,200
3,300
4,700
6,800
10,000
C0G
Code
102
152
222
332
472
682
103
Tolerance
J : ± 5%
NP0
ESD Resistance
(V)
8,000
10,000
12,000
16,000
16,000
22,000
30,000
2A
2A
(100V) (100V)
EIA CC0603 [1608]
Standard Thickness
0.80 mm
Capacitance
Range Table
Class 1 (Temperature Compensating)
Temperature Characteristics: C0G (-55 to +125°C, 0±30 ppm/°C)
Capacitance
1nF
1.5nF
2.2nF
3.3nF
4.7nF
6.8nF
10nF
Size
1608
1608
1608
1608
1608
1608
1608
Thickness
(mm)
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
Capacitance
Tolerance
±5%
±5%
±5%
±5%
±5%
±5%
±5%
ESD Resistance
(V)
8,000
10,000
12,000
16,000
16,000
22,000
30,000
Catalog Number
Rated Voltage Edc: 100V
CGA3EAC0G2A102J080AA
CGA3EAC0G2A152J080AC
CGA3EAC0G2A222J080AC
CGA3EAC0G2A332J080AC
CGA3EAC0G2A472J080AC
CGA3EAC0G2A682J080AC
CGA3EAC0G2A103J080AC
Class 1 (Temperature Compensating)
Temperature Characteristics: NP0 (-55 to +150°C, 0±30 ppm/°C)
Capacitance
1nF
1.5nF
2.2nF
3.3nF
4.7nF
6.8nF
10nF
Size
1608
1608
1608
1608
1608
1608
1608
Thickness
(mm)
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
0.80 ± 0.10
Capacitance
Tolerance
±5%
±5%
±5%
±5%
±5%
±5%
±5%
ESD Resistance
(V)
8,000
10,000
12,000
16,000
16,000
22,000
30,000
Catalog Number
Rated Voltage Edc: 100V
CGA3EANP02A102J080AA
CGA3EANP02A152J080AC
CGA3EANP02A222J080AC
CGA3EANP02A332J080AC
CGA3EANP02A472J080AC
CGA3EANP02A682J080AC
CGA3EANP02A103J080AC
Page 3
• All specifications are subject to change without notice.
