SCRH105
SMD POWER INDUCTORS
XXX
MARKING
●
Features
1. Magnetically shielded construction
2 Excellent Power Density
3 Engineered to Provide High Efficiency
CHARACTERISTICS
Part Number
Inductance
Test
(uH)
Frequency
(1)
DC Resistance
(Ω
MAX)
(2)
Saturation Temperature
(3)
(4)
Current
Current
(A)
(A)
BCRH105 I nduct ance
decrease by current
SCRH105 Inductance
decr ease by cur r ent
1000
SCRH105-1R2
SCRH105-2R5
SCRH105-3R3
SCRH105-4R7
SCRH105-5R6
SCRH105-6R8
SCRH105-8R2
SCRH105-100
SCRH105-120
SCRH105-150
SCRH105-180
SCRH105-220
SCRH105-270
SCRH105-330
SCRH105-390
SCRH105-470
SCRH105-560
SCRH105-680
SCRH105-820
SCRH105-101
SCRH105-121
SCRH105-151
SCRH105-181
SCRH105-221
SCRH105-271
SCRH105-331
SCRH105-391
SCRH105-471
1.2
2.5
3.3
4.7
5.6
6.8
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
100KHZ
17m
20m
25m
27m
45m
54m
56m
69m
78m
84m
100m
125m
156m
180m
220m
240m
270m
320m
380m
470m
560m
780m
1.05
1.32
1.50
1.92
2.20
2.60
9.0
7.5
7.2
7.0
6.5
6.0
5.4
4.8
4.2
3.7
3.4
2.8
2.6
2.4
2.3
2.1
1.82
1.65
1.50
1.40
1.23
1.15
1.00
0.80
0.70
0.62
0.58
0.55
7.00
5.90
4.70
4.21
3.59
3.23
2.90
2.75
2.61
2.32
2.22
2.10
1.90
1.80
1.53
1.37
1.23
1.16
1.10
1.04
0.98
0.88
0.70
0.63
0.60
0.57
0.50
0.45
Inductance (µH)
uH
I nduct ance( )
471
100
390
10
1
1R2
0. 1
10
100
DC cur r ent ( m
A)
DC current (mA)
1000
10000
100000
BC 105 Tem
Temperature
cur ent
RH
SCRH105
per at ur e r i se by
rise
r
by current
Temperature
r se
Tem at ur e
rise
i
°C
℃
per
80
70
60
50
40
30
20
10
0
1000
2000
3000
4000
5000
6000
7000
8000
9000 10000
471
390
1R
2
DC cur r ent (
(mA)
A)
DC current
m
(1). Inductance tolerance for 1.2uH~8.2uH:
±30%,
for 10uH~470uH:
±20%.
Tested at 0.25V, 0ADC and 25℃
(2). DCR measured at 25℃.
(3). The DC current at which the inductance decreases by 25% from its initial value.
(4). The DC current that results in a 40℃ temperature rise from 25℃ambient.
Click here for
QUANTITY PER REEL & PACKING INFORMATION
Custom versions available upon request.
