SH01D0505A

Description
Pluggable Terminal Blocks PTSM 0,5/ 4-P-2,5
Categorysemiconductor    Power management
File Size201KB,5 Pages
ManufacturerDELTA
Websitehttp://www.deltaww.com/
Download Datasheet Parametric View All

SH01D0505A Online Shopping

Suppliers Part Number Price MOQ In stock
SH01D0505A - - View Buy Now

SH01D0505A Overview

Pluggable Terminal Blocks PTSM 0,5/ 4-P-2,5

SH01D0505A Parametric

Parameter NameAttribute value
Product CategoryIsolated DC/DC Converters
ManufacturerDELTA
RoHSDetails
Number of Outputs2 Output
Output Power1 W
Input Voltage4.5 V to 5.5 V
Output Voltage-Channel 15 V
Output Current-Channel 1100 mA
Output Voltage-Channel 2- 5 V
Output Current-Channel 2100 mA
Isolation Voltage1.5 kV
Mounting StyleSMD/SMT
Length0.64 in
Width0.31 in
Height0.26 in
Operating Temperature Range- 40 C to + 85 C
PackagingTube
ProductIsolated
Factory Pack Quantity100
Unit Weight0.070548 oz
SH01S/D Series
1W DC/DC CONVERTER, SMD-Package
FEATURES
Efficiecny up to 80%
SMD Package with Industry Standard Pinout
Operating Temperature Range –40°C to +85°C
Moisture sensitivity level (MSL) 2
Isolation Voltage 1500 VDC
High Accuracy of Pin Planarity
Lead free, RoHs Compliant
3 Years Product Warranty
The SH01S/D series is miniature, SMD Package, isolated 1W DC/DC converters with 1,500VDC isolation. It allows a wide operating
temperature range of –40°C to +85°C. These isolated DC/DC converters are the latest offering from a world leader in power systems
technology and manufacturing
Delta Electronics, In
Model List
Model
Number
Input
Voltage
(Range)
VDC
SH01S0503A
SH01S0505A
SH01S0509A
SH01S0512A
SH01S0515A
SH01D0505A
SH01D0512A
SH01D0515A
SH01S1203A
SH01S1205A
SH01S1209A
SH01S1212A
SH01S1215A
SH01D1205A
SH01D1212A
SH01D1215A
SH01S1512A
SH01S1515A
SH01S2403A
SH01S2405A
SH01S2409A
SH01S2412A
SH01S2415A
SH01D2405A
SH01D2412A
SH01D2415A
Output
Voltage
VDC
3.3
5
9
12
15
±5
±12
±15
3.3
5
9
12
15
±5
±12
±15
12
15
3.3
5
9
12
15
±5
±12
±15
Output Current
Max.
mA
300
200
110
84
67
±100
±42
±33
300
200
110
84
67
±100
±42
±33
84
67
300
200
110
84
67
±100
±42
±33
Min.
mA
6
4
2
1.5
1
±2
±0.8
±0.7
6
4
2
1.5
1
±2
±0.8
±0.7
1.5
1
6
4
2
1.5
1
±2
±0.8
±0.7
Input Current
@Max. Load
mA(typ.)
271
256
254
259
254
270
259
254
112
109
106
106
105
113
108
104
86
86
58
54
54
55
53
57
54
53
@No Load
mA(typ.)
% (max.)
10
10
10
8
7
10
8
7
8
8
8
5
5
8
5
5
5
5
8
8
8
5
5
8
5
5
uF
Load
Max. capacitive
Regulation
Load
Efficiency
(typ.)
@Max. Load
%
73
78
78
78
79
74
78
78
74
76
78
79
80
74
78
79
78
78
72
78
77
77
79
73
78
78
* For each output
33
5
(4.5 ~ 5.5)
30
33*
33
12
(10.8 ~ 13.2)
15
33*
33
15
(13.5 ~ 16.5)
14
8
33
24
(21.6 ~ 26.4)
9
33*
DS_SH01S/D_02182013
E-mail: DCDC@delta.com.tw
http:// www.deltaww.com/dcdc
P1
