PW117RA0503F01: DescriptionDesktop AC Adapters Desktop/C14 Grounded 5Vdc, 10W; CategoryPower/power management; File Size677KB，2 Pages; ManufacturerSL Power

Download Datasheet Parametric Compare View All

PW117RA0503F01 Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	PW117RA0503F01	-	-	View	Buy Now

PW117RA0503F01 Overview

Desktop AC Adapters Desktop/C14 Grounded 5Vdc, 10W

PW117RA0503F01 Parametric

Parameter Name	Attribute value
Product Category	Desktop AC Adapters
Manufacturer	SL Power
RoHS	Details
Region	Universal
Input Voltage	100 VAC to 240 VAC
Number of Outputs	1 Output
Output Power	10 W
Output Voltage-Channel 1	5 V
Output Current-Channel 1	2 A
Commercial/Medical	Commercial
DC Output Connector	2.5 mm Barrel Plug
DC Output Cord Length	6 ft
Efficiency	65 %
AC Plug included/required	Included
Cooling Method	Convection
Height	1.3 in
Input Voltage, Max	240 VAC
Input Voltage, Min	100 VAC
Length	3.35 in
Load Regulation	Regulated
Mechanical Style	External
Mounting Style	Desktop
Operating Temperature Range	0 C to + 40 C
Output Voltage V1, Nominal	5 VDC
Factory Pack Quantity	48
Width	1.81 in

Preview

Download Datasheet

View All

PW117

ITE 6-12 WATT SERIES

PW117 SWITCH-MODE

P O W E R S U P P LY

•

PW117

Ault Part No.

Voltage

DC

Max

Amps

Max

Watts

100-240 VAC Universal Input

Desktop Style

Single Output to 6-12W

Regulated Output With Low Ripple

Meets Safety Agency Requirements

Complies With EMI/RFI Regulations

CE Compliant

Impact Resistant Polycarbonate Enclosure

Private Label Marking Available

3 Year Warranty

Modified and Custom Designs

Also Available

PW117XA0303_01

PW117XA0503_01

PW117XA0803_01

PW117XA0903_01

PW117XA1203_01

PW117XA1503_01

PW117XA1803_01

PW117XA2403_01

PW117XA4803_01

3V

5V

7.8V

9V

12V

15V

18V

24V

48V

2.00

1.28

1.10

0.85

0.70

0.60

0.45

0.25

6.0

10.0

10.2

10.5

10.8

12.0

Ault Part No. Key

PW117 X

Product

Family

Name

Manufacturing

Location

(volume

dependent)

A

Design

Revision

Changes

05

Voltage

DC

03

Connector

__

Input

Configuration/

Model Type

(see pg. 2)

01

Standard (no

modifications,

special artwork

or special

packaging)

A U LT I N C O R P O R AT E D

7105 Northland Terrace

|

Minneapolis, Minnesota 55428

|

USATEL (1) 763-592-1900

FAX (1) 763-592-1911

|

E-MAIL info@aultinc.com

|

WEB www.aultinc.com
