65W Single Output Medical Type
RPS-65
series
EN 60601-1
IEC 60601-1
8
Features
3"×2" miniature size
Universal AC input / Full range
Class
Ⅱ
(without FG) installations
Medical safety approved
(2 x MOPP between primary to secondary)
Suitable for BF application with appropriate system consideration
Low leakage current <100μA
No load power consumption<0.1W
High efficiency up to 91%
For 1U applications
Protections: Short circuit / Overload / Over voltage
Cooling by free air convection
-30~70
℃
wide range of operating temperature
Operating altitude up to 4000 meters(Note 6.)
LED indicator for power on
3 years warranty
Applications
Oral irrigator
Hemodialysis machine
Medical monitors
Sleep apnea devices
Description
RPS-65 is a 65W highly reliable green PCB type medical power supply with a high power density on the 3”
by 2” footprint. It accepts 80~264VAC input and offers various output voltages between 3.3V and 48V. The
working efficiency is up to 91% and the extremely low no load power consumption is down below 0.1W.
RPS-65 is able to be used for Class
Ⅱ
(no FG) system design. The extremely low leakage current is less
than 100 μ A. In addition, it conforms to international medical regulations (2*MOPP) and EMC EN55011,
perfectly fitting all kinds of BF rated “patient contact” medical system equipment.y
Model Encoding
RPS - 65 - 3.3
Output voltage
Output wattage
Series name
File Name: RPS
- 65
-SPEC 2015-11-04
65W Single Output Medical Type
SPECIFICATION
ORDER NO.
DC VOLTAGE
RATED CURRENT
CURRENT RANGE
RATED POWER
OUTPUT
RPS
-
65
-
3
.
3
3.3V
10A
0 ~ 11A
33W
RPS
-
65
-5
5V
10A
0 ~ 11A
50W
55W
80mVp-p
RPS
-
65
-
7
.
5
7.5V
8A
0 ~ 8.8A
60W
66W
80mVp-p
RPS
-
65
-12
12V
5.42A
0 ~ 5.96A
65W
71.5W
120mVp-p
RPS
-
65
-15
15V
4.34A
0 ~ 4.77A
65.1W
71.6W
150mVp-p
RPS-65
series
RPS
-
65
-24
24V
2.71A
0 ~ 2.98A
65W
71.5W
240mVp-p
RPS
-
65
-48
48V
1.36A
0 ~ 1.49A
65.3W
71.5W
300mVp-p
36
.
3W
PEAK LOAD(10sec.)
RIPPLE & NOISE (max.)
Note.2
80mVp-p
VOLTAGE ADJ.RANGE
VOLTAGE TOLERANCE
LINE REGULATION
LOAD REGULATION
SETUP, RISE TIME
HOLD UP TIME (Typ.)
VOLTAGE RANGE
FREQUENCY RANGE
INPUT
EFFICIENCY (Typ.)
Note.3
2.9~3.6V
±
2.0%
±
0.5%
±
2.0%
4.7~5.5V
±
2.0%
±
0.5%
±
2.0%
7.12~8.3V
±
2.0%
±
0.5%
±
2.0%
11.4~13.2V
±
2.0%
±
0.5%
±
2.0%
13.5~16.5V
±
1.0%
±
0.5%
±
1.0%
22.8~27.6V
±
1.0%
±
0.5%
±
1.0%
45.6~52.8V
±
1.0%
±
0.5%
±
1.0%
500ms, 30ms / 230VAC
30ms / 230VAC
Note.
4
80 ~ 264VAC
47 ~ 63Hz
80%
1.5A / 115VAC
84%
500ms, 30ms / 115VAC at full load
12ms / 115VAC at full load
85%
88%
89%
90%
91%
AC CURRENT (Typ.)
INRUSH CURRENT (Typ.)
LEAKAGE CURRENT
OVERLOAD
PROTECTION
OVER VOLTAGE
WORKING TEMP.
WORKING HUMIDITY
1A / 230VAC
СOLD STAR 30A/115VAC 50A/230VAC
Note.
5
Touch current< 100 A/264VAC
115 ~ 150% rated output power
Protection type : Hiccup mode, recovers automatically after fault condition is removed
3.8~4.46V
5.75~6.75V
8.62~11.3V
13.8~16.2V
17.25~20.25V
27.6~32.4V
55.2~64.8V
Protection type :
Shut down o/p voltage, re-power on to recover
-30 ~ +70
℃
(Refer to "Derating Curve")
20% ~ 90% RH non-condensing
ENVIRONMENT STORAGE TEMP., HUMIDITY
-40 ~ +85
℃
, 10 ~ 95% RH
TEMP. COEFFICIENT
±
0.03% /
℃
(0 ~ 50
℃
)
VIBRATION
10 ~ 500Hz, 2G 10min./1cycle, period for 60min. each along X, Y, Z axes
ANSI/AAMI ES60601-1 , TUV EN60601-1 , I EС60601-1 approved
SAFETY STANDARDS
Primary-Secondary: 2xMOPP
SAFETY & ISOLATION LEVEL
WITHSTAND VOLTAGE
I/P-O/P: 4KVAC
EMC
(Note. 6) ISOLATION RESISTANCE
I/P-O/P:100M Ohms / 500VDC / 25
℃
/ 70% RH
EMC EMISSION
EMC IMMUNITY
OTHERS
MTBF
DIMENSION
PACKING
NOTE
Compliance to EN55011(CISPR11) class B, EN61000-3-2,3
Compliance to EN61000-4-2,3,4,5,6,8,11, EN55024, EN60601-1-2 medical level, criteria A
959.1Khrs min. MIL-HDBK-217(25
℃
)
76.2*50.8*24mm or 3" * 2" *0.945" inch (L*W*H)
0.11Kg; 120pcs/14.2Kg/0.97CUFT
1. All parameters NOT specially mentioned are measured at 230VAC input, rated load and 25
℃
of ambient temperature.
2. Ripple & noise are measured at 20MHz of bandwidth by using a 12" twisted pair-wire terminated with a 0.1uf & 47uf parallel capacitor.
3. Tolerance : includes set up tolerance, line regulation and load regulation.
4. Derating may be needed under low input voltages. Please check the derating curve for more details.
5. Touch current was measured from primary input to DC output.
6.
The ambient temperature derating of 5
℃
/1000m is needed for operating altitude greater than 2000m (6500ft).
7. The power supply is considered a component which will be installed into a final equipment. The final equipment must be re-confirmed that
it still meets EMC directives. For guidance on how to perform these EMC tests, please refer to “EMI testing of component power supplies.”
(as available on http://www.meanwell.com)
