PMC 8818T S
Contents
Product Program . . . . . . . . . . . . . . . . . . . . . . 2
Mechanical Data . . . . . . . . . . . . . . . . . . . . . . 2
Connections . . . . . . . . . . . . . . . . . . . . . . . . . 2
Absolute Maximum Ratings . . . . . . . . . . . . . 3
Input . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . . 3
Product Qualification Specification . . . . . . . . 4
Safety Specification . . . . . . . . . . . . . . . . . . . 5
Adjusted to 1.0 Vout - Data . . . . . . . . . . . . . . 6
Adjusted to 1.2 Vout - Data . . . . . . . . . . . . . . 9
Adjusted to 1.5 Vout - Data . . . . . . . . . . . . . 12
Adjusted to 1.8 Vout - Data . . . . . . . . . . . . . 15
Adjusted to 2.5 Vout - Data . . . . . . . . . . . . . 18
Adjusted to 3.3 Vout - Data . . . . . . . . . . . . . 21
Adjusted to 5.0 Vout - Data . . . . . . . . . . . . . 24
EMC Specification . . . . . . . . . . . . . . . . . . . 27
.
Operating Information . . . . . . . . . . . . . . . . . 28
Thermal Considerations . . . . . . . . . . . . . . . 30
Soldering Information . . . . . . . . . . . . . . . . . 31
Delivery Package Information . . . . . . . . . . . 32
Compatibility with RoHS requirements . . . . 32
Reliability . . . . . . . . . . . . . . . . . . . . . . . . . . . 32
Sales Offices and Contact Information . . . . 33
DC/DC regulator
Input 8.3 - 16 V
Output 16 A
Key Features
• Wide input, 8.3 - 16 Vdc
• Programmable output, 0.75 - 5.5 Vdc
• Monotonic start up into pre-biased output
• Under voltage protection
• Short circuit protection
• Remote sense
• Remote On/Off
• Design for Environment (DfE)
• European Commission Directive 2002/95/EC
(RoHs) compliant
The PMC series of surface mount DC/DC regulators
(POL) are intended to be used as local distributed power
sources in distributed power architecture. The high ef-
ficiency and high reliability of the PMC series makes them
particularly suited for the communications equipment of
today and tomorrow.
These products are manufactured using the most ad-
vanced technologies and materials to comply with en-
vironmental requirements. Designed to meet high reliability
requirements of systems manufacturers, the PMC responds
to world-class specifications.
Ericsson Power Modules is an ISO 9001/14001 certified
supplier.
E
Datasheet
Absolute Maximum Ratings
Characteristics
T
ref
T
S
V
I
V
tr
V
RC
min
-45
-55
-0.3
-0.3
Negative logic
Positive logic
-0.3
-0.3
typ
max
+115
+125
16
40
16
16
Unit
˚C
˚C
Vdc
Vdc
Vdc
Vdc
Maximum Operating Temperature, see thermal considerations
Storage temperature
Input voltage
Input voltage transient
Remote control voltage
Stress in excess of Absolute Maximum Ratings may cause permanent damage. Absolute Maximum Ratings, sometimes referred to as no destruction limits, are
normally tested with one parameter at a time exceeding the limits of Output data or Electrical Characteristics. If exposed to stress above these limits, function
and performance may degrade in an unspecified manner.
Input
T
ref
= -30 ... +90 ˚C, V
I
= 8.3...16.0 V unless otherwise specified
Typ values specified at: T
ref
= +25 ˚C, V
I
nom, I
o
max = 16 A
Characteristics
VI
V
loff
V
Ion
Conditions
min
8.3
typ
12
7.8
8.0
30
max
16
Unit
V
V
V
µF
Input voltage range
Turn-off input voltage
Turn-on input voltage
Input capacitance
V
o
= 1.00 V
V
o
= 1.20 V
V
o
= 1.50 V
V
o
= 1.80 V
V
o
= 2.50 V
V
o
= 3.30 V
V
o
= 5.00 V
I
o
max
I
o
max
C
I
470
500
550
605
750
910
1150
35
170
180
190
210
310
350
540
560
600
660
725
900
1090
1410
mW
mW
mW
mW
mW
mW
mW
mW
mV
p-p
mV
p-p
mV
p-p
mV
p-p
mV
p-p
mV
p-p
mV
p-p
P
Ii
Input idling power
I
o
= 0 A, V
I
= 12 V
P
RC
Input stand-by power
V
I
= 12 V, RC activated
V
o
= 1.00 V
V
o
= 1.20 V
V
o
= 1.50 V
V
o
= 1.80 V
V
o
= 2.50 V
V
o
= 3.30 V
V
o
= 5.00 V
V
I
ac
Input ripple
1)
20 Hz ... 5 MHz
V
I
= 12 V, I
o =
1.0 x I
o
max
1) Measured with 4 x 4.7 µF ceramic capacitors
Fundamental Circuit Diagram
+IN
+OUT
+SENSE
GND
GND
PWM
controller
Vadj
Error
amplifier
Ref
RC
RC
Block
GND
GND
PMC 8818T S Datasheet
EN/LZT 146 064 R2A © Ericsson Power Modules, March 2007
Absolute Maximum Ratings
Characteristics
T
ref
T
S
V
I
Operating Reference Temperature, see pg. 27
Storage temperature
Input voltage
min
-45
-55
-0.3
typ
max
+115
+125
+5.5
Unit
˚C
˚C
Vdc
Stress in excess of Absolute Maximum Ratings may cause permanent damage.
Absolute Maximum Ratings, sometimes referred to as no destruction limits, are
normally tested with one parameter at a time exceeding the limits of Output data
or Electrical Characteristics. If exposed to stress above these limits, function and
performance may degrade in an unspecified manner.
Input
T
ref
= -30 ... +90 ˚C, V
I
= 3.0...5.5 V unless otherwise specified
Typ values specified at: T
ref
= +25 ˚C, V
I
nom, I
o
max = 16 A
Characteristics
V
I
V
Ioff
V
Ion
C
I
P
Ii
P
RC
V
I
ac
Input voltage range
Turn-off input voltage
Conditions
min
3.0
typ
max
5.5
Unit
Vdc
Vdc
Ramp from higher voltage, V
out
= 1.0- 2.5 V, V
in
= 3.3 V
Ramp from higher voltage, V
out
= 3.3 V, V
in
= 5.0 V
Ramp from lower voltage, V
out
= 1.0- 2.5 V, V
in
= 3.3 V
Ramp from lower voltage, V
out
= 3.3 V, V
in
= 5.0 V
2.3
3.4
2.4
3.5
20
Turn-on input voltage
Input capacitance
Input idling power
Input stand-by power (RC active)
Input ripple
1)
Vdc
µF
680
7.5
mW
mW
mV
I
o
= 0 A, V
I
= 5.5 V
Non operation, V
I
= 5 V
20 Hz ... 5 MHz, I
o
max, V
I
= 5 V
400
1) Measured with 2 x 22 µF ceramic capacitors
Fundamental Circuit Diagram
+IN
+OUT
+SENSE
GND
GND
PWM
controller
Vadj
Error
amplifier
Ref
RC
RC
Block
GND
GND
PMC 8818T S Datasheet
EN/LZT 146 064 R2A © Ericsson Power Modules, March 2007
