100Watts Single Output
Q
ualtek
P
P C
Electronics Corporation
QPD-100 Series
Features:
Universal AC input/ Full range
Wide Operating Ambient Temperature (-20°C~70°C)
High Efficiency, and High Reliability
Output Protections: OLP/OVP/SCP
All using 105°C long life electrolytic capacitors.
100% full load burn-in test
Model
DC Output
Rated Current
Current Range
Ripple and
Noise
0~70°C
-20~0°C
QPD-100-5
5V
16A
0~16A
<80mV
<100mV
4.7V-5.6V
±2.0%
±0.5%
±1.0%
QPD-100-12
12V
8.5A
0~8.5A
<100mV
<120mV
11.0V-13.0V
±1.0%
±0.5%
±1.0%
QPD-100-15
15V
7A
0~7A
<100mV
<120mV
13.7V-16.3V
±1.0%
±0.5%
±1.0%
QPD-100-24
24V
4.5A
0~4.5A
<120mV
<120mV
22.4V-27.3V
±1.0%
±0.5%
±1.0%
QPD-100-48
48V
2.3A
0~2.3A
<200mV
<200mV
44.4V-52.2V
±1.0%
±0.5%
±1.0%
Output Characteristics
Voltage ADJ. Range
Voltage Accuracy
Line Regulation
Load Regulation
Set-up Time
Hold-up Time
Temperature Coefficient
Overshoot and Undershoot
<2.0s (115VAC input, full load); <1.0s (230VAC input, full load)
>10ms (115VAC input, full load); >20ms (230VAC input, full load)
±0.03%/°C
<5.0%
90VAC~264VAC, 127VDC~370VDC
47Hz-63Hz
80%
80%
<2.5A
20A@115VAC Cold start 40A@230VAC Cold start
<0.4mA@115VAC <0.75mA@230VAC
105%~150% of rated output current, hiccup mode, auto recovery
110%~150% of rated output voltage, shut down, re-power on to recover
Long-term mode, auto recovery
-20°C~70°C; 20%~90% RH Non-Condensing
-40°C~85°C: 10%-95% RH Non-Condensing
UL60950-1; EN60950-1: 2006
Primary-Secondary: 3.0KVAC;≤10mA. Primary-PG: 1.5KVAC;≤10mA. Secondary-PG: 0.5KVDC;≤10mA
≥100M ohms
Compliance to EN55022(CISPR22) Class B
Compliance to EN61000-3-2, 3
Compliance to EN61000-4-2, 3, 4, 5, 6, 8, 11; ENV50204, light industry level, criteria A
More than 200,000Hrs (25°C, Full load)
160x98x38mm
20PCS/CTN. G.W: 13.6kgs
Cooling by free air convection
80%
81%
83%
84%
85%
85%
83%
84%
115VAC Input
230VAC Input
Input Characteristics
Voltage Range
Frequency Range
Efficiency
(Typical)
AC Current (max)
Inrush Current (Typical)
Leakage Current
Protection
Over Load (OLP)
Over Voltage (OVP)
Short Circuit (SCP)
Operating Amb. Temp. & Hum
Storage Temp. & Hum
Safety Standards
Withstand Voltage
Isolation Resistance
EMI Conduction & Radiation
Harmonic Current
EMS Immunity
MTBF (MIL-HDBK-217F)
Dimension (LxWxH)
Packing
Cooling Method
Environmental Characteristics
General Characteristics
Rev.B
Page 1 of 2
