805-011 Ordering Information
Right Angle PCB Receptacle
connectors offer militar y grade
performance in a small, lightweight
package. These connectors are rated for
MIL-STD-810 Method 512 immersion.
High temperature thermoplastic
housing withstands soldering
temperatures. Stainless steel threaded
inserts simplify attachment to printed
circuit board.
How To Order
Sample Part Number
Series
Shell Style
805-011
= PCB Right Angle Receptacle
-07
= Jam Nut for Rear Panel Mounting (See Table II)
C
= Aluminum / Black Anodize (Non-Conductive); RoHS Compliant
M
= Aluminum / Electroless Nickel; RoHS Compliant
NF
= Aluminum / Cadmium with Olive Drab Chromate
ZNU
= Aluminum / Zinc-Nickel with Black Chromate
Z1
= Stainless Steel / Passivated; RoHS Compliant
Shell Size - Insert
Arrangement
Contact Type
Shell Key Positions
(See Table I)
8-1, 8-4, 8-6, 8-7, 9-1, 9-10, 10-2, 10-13, 11-4, 11-19, 11-200, 12-2, 12-5, 12-201
P
= Pin, PC Tail
A
= Normal
S
= Socket, PC Tail
C
= Pos. C
D
= Pos. D
E
= Pos. E
F
= Pos. F
Triple-Start ACME Thread
Right Angle Contacts
High Temperature
Housing
Threaded Inserts
Environmentally Sealed
805-011
-07
M
8-7
S
A
Shell Material and Finish
B
= Pos. B
Table I: Key Positions
Shell
Size
A°
B°
Jam Nut Panel Cutout
A Flat
In.
± .002
.545
.671
.671
.731
.794
mm.
± 0.05
13.84
17.04
17.04
18.57
20.17
In.
± .005
.572
.698
.698
.760
.822
ØB
mm.
± 0.13
14.53
17.73
17.73
19.30
20.88
A FLAT
øB
8
9
10
11
12
Key Position
Normal (A)
B
C
D
E
F
Key Rotation
A
150°
75°
95°
140°
75°
95°
B
210°
210°
230°
275°
275°
210°
Dimensions in Inches (millimeters) are subject to change without notice.
© 2014 Glenair, Inc.
Series 80 Mighty Mouse
U.S. CAGE Code 06324
Printed in U.S.A.
GLENAIR, INC.
•
1211 AIR WAY
•
GLENDALE, CA 91201-2497
•
818-247-6000
•
FAX 818-500-9912
www.glenair.com
H-29
E-Mail: sales@glenair.com
Series 805
Series 805 Mighty Mouse Triple-Start ACME Thread
Right Angle PCB Receptacle
H
