X1G005151030201 datasheet, PDF

Datasheet> All Categories > Passive components> oscillator> X1G005151030201

X1G005151030201: DescriptionClipped Sine Output Oscillator,; CategoryPassive components oscillator; File Size548KB，8 Pages; ManufacturerSeiko Epson Corporation

Download Datasheet Parametric Compare View All

X1G005151030201 Overview

Clipped Sine Output Oscillator,

X1G005151030201 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	TAPE
Ageing	0.5 PPM/FIRST YEAR
Maximum control voltage	1.5 V
Minimum control voltage	0.3 V
Frequency Adjustment - Mechanical	NO
Frequency offset/pull rate	12 ppm
frequency stability	0.5%
Installation features	SURFACE MOUNT
Nominal operating frequency	16.368 MHz
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Oscillator type	CLIPPED SINE
Output impedance	10000 Ω
Output level	0.8 V
physical size	2.5mm x 2.0mm x 0.8mm
Maximum supply voltage	3.63 V
Minimum supply voltage	1.7 V
surface mount	YES
Base Number Matches	1

Preview

Download Datasheet

View All

Temperature Compensated Crystal Oscillator (VC-TCXO)

Data sheet

MODEL

：

TG2520SBN 16.368000 MHz TCGNBM

Product. No.

：

X1G0051510302xx

Please refer to the 10.Packing information about xx (last 2 digits)

SEIKO EPSON CORPORATION

Pb free.

Complies with EU RoHS directive.

*About the products without the Pb-free mark.

Contains Pb in products exempted by EU RoHS directive.

(Contains Pb in sealing glass, high melting temperature type solder or other.)

INTRODUCTION

1. Any part of this material may not be reproduced or duplicated in any form or any means without the

written permission of Seiko Epson.

2. This sheet is not intended to guarantee or provide an approval of implementation of industrial patents.

X1G005151030201 Related Products

	X1G005151030201	X1G005151030227	X1G005151030214	X1G005151030211	X1G005151030200	X1G005151030212
Description	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,	Clipped Sine Output Oscillator,
Reach Compliance Code	unknown	unknown	unknown	unknown	unknown	unknown
Other features	TAPE	TR, 13 INCH	TR, 13 INCH	TR, 13 INCH	TR, 13 INCH	TR, 13 INCH
Ageing	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR	0.5 PPM/FIRST YEAR
Maximum control voltage	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V	1.5 V
Minimum control voltage	0.3 V	0.3 V	0.3 V	0.3 V	0.3 V	0.3 V
Frequency Adjustment - Mechanical	NO	NO	NO	NO	NO	NO
Frequency offset/pull rate	12 ppm	12 ppm	12 ppm	12 ppm	12 ppm	12 ppm
frequency stability	0.5%	0.5%	0.5%	0.5%	0.5%	0.5%
Installation features	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT	SURFACE MOUNT
Nominal operating frequency	16.368 MHz	16.368 MHz	16.368 MHz	16.368 MHz	16.368 MHz	16.368 MHz
Maximum operating temperature	85 °C	85 °C	85 °C	85 °C	85 °C	85 °C
Minimum operating temperature	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C	-40 °C
Oscillator type	CLIPPED SINE	CLIPPED SINE	CLIPPED SINE	CLIPPED SINE	CLIPPED SINE	CLIPPED SINE
Output impedance	10000 Ω	10000 Ω	10000 Ω	10000 Ω	10000 Ω	10000 Ω
Output level	0.8 V	0.8 V	0.8 V	0.8 V	0.8 V	0.8 V
physical size	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm	2.5mm x 2.0mm x 0.8mm
Maximum supply voltage	3.63 V	3.63 V	3.63 V	3.63 V	3.63 V	3.63 V
Minimum supply voltage	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V	1.7 V
surface mount	YES	YES	YES	YES	YES	YES
Base Number Matches	1	1	1	1	1	1
