0.5mm Pitch, 2.5mm Height, shielded FFC Connectors for High Speed Transmissions
FH41 Series
Supports the next generation chip
V-by-One
®
HS* by THine
Dec.1.2017 Copyright 2017 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
■Features
1. Accepts impedance matched shielded FFC
The FH41 Series is equipped with a ground terminal and
can be used with impedance matched shielded FFC.
Dimensions: 68 positions
2.5mm
38mm
2. Impedance matched terminal design
The signal terminal is designed for impedance control
and is capable of handling high speed transmissions.
3. Highly reliable and secure structure
The design of the FH41 series follows in the footsteps
of another popular Hirose connector, the FH28 series.
The FFC positioning mechanism and rugged structure
combine to prevent accidental unlocking and produce
a secure connection.
6.2mm
(Mounting area)
Fig.1
4. Simplified operations with a flip lock system
The flip lock design allows a smoother simpler FFC
operation. It requires less force to rotate the actuator
and delivers a tactile click to reinforce that the lock has
secured the connection.
Sig
0.5 nal co
mm nta
pitc cts
h
5. Suitable for automatic pick-n-place mounting
Offered in tape and reel packaging that is compatible
with automatic machine mounting. (2,500 pcs/reel)
6. Halogen free
All materials and substances used to produce this
product comply with Halogen-free standards.
*Standards by IEC 61249-2-21. Br : 900 ppm or lower,
Cl : 900 ppm or lower, Br+Cl : 1,500 ppm or lower
●
Uses the same FFC that the FH48 Series (vertical
connection) uses.
●Shielded
FFC
Signal connection area
Gr
2.5 ound
mm co
pitc ntac
h ts
Fig.2
FH41 and FH48 use
the same FFC layout.
FFC
Ground contact connection area
Fig.3
2016.5③
1
FH41 Series●0.5mm Pitch, 2.5mm Height, shielded FFC Connectors for High Speed Transmissions
■Product
Specifications
Rating
Rated current 0.5A (Note 1)
Rated voltage AC 50Vrms
Operating temperature range:
−40 to +105ç (Note 2)
Operating humidity range:
Relative humidity of 90% or lower
(no dew condensation)
Storage temperature range:
−10 to +50ç (Note 3)
Storage humidity range:
Relative humidity of 90% or lower
(no dew condensation)
Applicable FPC and FFC
t= 0.3 ±0.05, gold plating (GND plate: t= 0.5 ±0.05, tin plating)
terminal specifications
Items
Specifications
Measured at DC 100V.
AC 150Vrms for 1 minute
Measured at 1mA.
20 mating cycles
Conditions
1. Insulation resistance Minimum of 500Mø
2. Withstanding voltage No flashover or insulation damage
3. Contact
resistance
Maximum of 100mø
*Incl. FFC conductor resistance
Dec.1.2017 Copyright 2017 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
4. Repeated motions Contact resistance : Maximum of 100mø
Durability
No damaged, cracked or loose parts.
5. Vibration
resistance
6. Impact
resistance
No electrical discontinuity for more than 1µs
Frequency 10 to 55Hz with half amplitude 0.75mm in 3
Contactresistance : Maximum of 100mø
directions, 10 cycles each.
No damaged, cracked or loose parts.
No electrical discontinuity for more than 1µs
Acceleration : 981m/s
2
, duration time : 6ms, with half sine
Contact resistance : Maximum of 100mø
waves in 3 directions, three times each.
No damaged, cracked or loose parts.
Left for 96 hours at temperature 40ç, humidity 90 to 95%
Temperature : −40ç
→
+15ç to +35ç
→
+105ç
→
+15ç to +35ç
Time : 30
→
2 to 3
→
30
→
2 to 3 min.
5 cycles in the above conditions
Reflow : Recommended temperature profile
Manual soldering : 350 ±5ç for 5 sec.
Contact resistance : Maximum of 100mø
7. Humidity resistance
Insulation resistance : Minimum of 50Mø
in ordinary conditions
No damaged, cracked or loose parts.
8. Temperature
cycle
9. Solder heat
resistance
Contact resistance : Maximum of 100mø
Insulation resistance : Minimum of 50Mø
No damaged, cracked or loose parts.
No deformation of components or no
significant looseness of contacts, etc.
Note 1 : When energizing rated current to all contacts, use 70% of rated current.
Note 2 : Includes temperature rise caused by current flow.
Note 3 : The term "storage" here refers to products stored for a long period prior to board mounting and use. The operating
temperature and humidity range covers the non-energized condition of connectors after board mounting and the
temporary storage.
■Materials
/ Finish
Parts
Insulating parts
Terminal
Metal parts
Materials
LCP
Phosphor bronze
Phosphor bronze (plating material)
Color/Finish
Gray
Black
Gold plating
Pure tin reflow plating
———
Remarks
UL94V-0
■Product
number structure
Refer to the chart below when datermining the product specifications from the product number.
Please select from the product numbers listed in this catalog when placing orders.
FH 41 − 50S − 0.5 SH (05)
q
w
e
r
t
y
q
Series name : FH
w
Series number : 41
e
Number of contacts : 15 to 68
r
Contact pitch : 0.5mm
t
Terminal shape
SH…SMT horizontal implementation type
(05)…Gold plating (Except 50, 68 contacts)
(28)…Gold plating (50, 68 contacts)
y
Plating specifications :
2
FH41 Series●0.5mm Pitch, 2.5mm Height, shielded FFC Connectors for High Speed Transmissions
■Connector
dimension drawing
C
D
0.5
(0.12)
(5.05)
Dec.1.2017 Copyright 2017 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
No. of contacts
1
2.5
(G-1)×2.5 (=E)
(0.12)
Cavity No.
(5.45)
2.5
(0.15)
0.8
(F: FFC insert opening dimension)
H
6.2
Note 1 : The coplanarity of the metal fittings and the contacts are a maximum of 0.1mm.
Note 2 : Packaged on tape and reel only. Check packaging specification.
Note 3 : Recesses may be added to the part structure to improve the molding characteristics. Black marks
may appear in the mold resin, but they will not negatively affect the performance of these connectors.
Note 4 : The color of the plating may change after the reflow process, but it will not negatively affect the
performance of these connectors.
■Connector
dimension table
Part No.
FH41-15S-0.5SH(05)
FH41-20S-0.5SH(05)
FH41-28S-0.5SH(05)
FH41-30S-0.5SH(05)
FH41-31S-0.5SH(05)
FH41-40S-0.5SH(05)
FH41-50S-0.5SH(28)
FH41-68S-0.5SH(28)
HRS No.
580-2222-2 05
580-2221-0 05
580-2208-1 05
580-2218-5 05
580-2216-0 05
580-2205-3 05
580-2204-0 28
580-2202-5 28
No. of contacts Number of ground contacts : G
15
3
20
4
28
5
30
6
31
6
40
8
50
10
68
13
C
11.5
14
18
19
19.5
24
29
38
D
7
9.5
13.5
14.5
15
19.5
24.5
33.5
E
5
7.5
10
12.5
12.5
17.5
22.5
30
2
0.25
(4.7)
Unit : mm
F
8.07
10.57
14.57
15.57
16.07
20.57
25.57
34.57
H
9.45
11.95
15.95
16.95
17.45
21.95
26.95
35.95
Note 1 : This embossed packaged product is sold by full reel quantities of 2,500 pcs/reel. Please place orders in full reel quantities.
3
FH41 Series●0.5mm Pitch, 2.5mm Height, shielded FFC Connectors for High Speed Transmissions
BRecommended
PCB layout and metal mask dimension diagram
D
±0.05
6.35
±0.05
0.65
±0.05
6.6
±0.1
0.5
±0.05
1
±0.05
0.3
±0.03
(Land pattern)
0.25
±0.03
(Metal mask)
1.2
±0.05
(Land pattern)
1
±0.05
(Metal mask)
1.55
±0.05
2.5
±0.05
0.3±0.03(Land pattern)
0.2±0.03(Metal mask)
0.4
±0.03
(G-1)×2.5 (=E)
±0.05
Dec.1.2017 Copyright 2017 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
J
±0.05
Recommended metal mask thickness : t= 0.1
BRecommended
FFC dimension drawing
0.5
±0.1
R0
.2
2-
±0
R0
.1
.2
±
2-
0.1
K
±0.1
L
±0.07
D
±0.05
0.5
±0.05
0.3
±0.03
0.5
±0.1
1.9
±0.1
2.6
±0.1
3.8
±0.1
0.5
±0.05
(Ground plate thickness)
0.3
±0.05
(End conductor thickness)
17.7 MAX
5.5 MIN
2.6
±0.5
2.1
±0.5
0.1 MIN
Ground plate
1
X
0. 2
. 2 MA
MA
X
Note : 1
2-R 0
2-R
Shielded area
Please overlap shield plate on ground plate
BRecommended
land, metal mask and FFC dimension table
Part No.
FH41-15S-0.5SH(05)
FH41-20S-0.5SH(05)
FH41-28S-0.5SH(05)
FH41-30S-0.5SH(05)
FH41-31S-0.5SH(05)
FH41-40S-0.5SH(05)
FH41-50S-0.5SH(28)
FH41-68S-0.5SH(28)
HRS No.
580-2222-2 05
580-2221-0 05
580-2208-1 05
580-2218-5 05
580-2216-0 05
580-2205-3 05
580-2204-0 28
580-2202-5 28
No. of contacts
15
20
28
30
31
40
50
68
Number of ground contacts : G
3
4
5
6
6
8
10
13
J
9.5
12
16
17
17.5
22
27
36
K
9.2
11.7
15.7
16.7
17.2
21.7
26.7
35.7
5.5 MIN
Unit : mm
L
8
10.5
14.5
15.5
16
20.5
25.5
34.5
4
FH41 Series●0.5mm Pitch, 2.5mm Height, shielded FFC Connectors for High Speed Transmissions
BPackaging
Specifications
●Embossed
carrier tape dimension
(Tape width: Maximum of 24mm)
1.75
±0.1
(Tape width: Minimum of 32mm)
.5
+0
0 .1
Ø1
(2.9)
(0.3)
Ø1
4
±0.1
2
±0.1
12
±0.1
(2.9)
(0.3)
4
±0.1
2
±0.1
12
±0.1
Dec.1.2017 Copyright 2017 HIROSE ELECTRIC CO., LTD. All Rights Reserved.
(5.75)
(7.35)
C
L
(1.64 : Vacuum pick up surface for automatic mounting)
Unreeling direction
(5.75)
(7.35)
C
L
(1.64 : Vacuum pick up surface for automatic mounting)
Unreeling direction
●Reel
dimensions
(U : Outer width)
(Ø380)
(Ø80)
(V : Inner width)
Terminal section
Loaded product section
Leader section (Minimum of 400 mm)
Empty pockets
(At least 14 empty pockets)
Empty pockets Cover tape
(Minimum of 10 empty pockets)
Embossed carrier tape containing product
BPackaging
Specification Dimensions
Part No.
FH41-15S-0.5SH(05)
FH41-20S-0.5SH(05)
FH41-28S-0.5SH(05)
FH41-30S-0.5SH(05)
FH41-31S-0.5SH(05)
FH41-40S-0.5SH(05)
FH41-50S-0.5SH(28)
FH41-68S-0.5SH(28)
HRS No.
580-2222-2 05
580-2221-0 05
580-2208-1 05
580-2218-5 05
580-2216-0 05
580-2205-3 05
580-2204-0 28
580-2202-5 28
No. of contacts Number of ground contacts : G
15
3
20
4
28
5
30
6
31
6
40
8
50
10
68
13
M
24
32
44
56
P
-
-
28.4
40.4
52.4
Q
11.5
14.2
20.2
26.2
R
11.8
14.3
18.3
19.3
19.8
24.3
29.3
38.3
S
10.5
13.5
17
18
18.5
23
28
37
T
9.2
12.2
15.7
16.7
17.2
21.7
26.7
35.7
Q
±0.1
P
±0.1
M
±0.3
Q
±0.1
M
±0.3
(R)
(S)
(T)
(R)
(S)
(T)
1.75
±0.1
.5
+0
.1
0
(Ø1
3)
Unit : mm
U
29.4
37.4
49.4
61.4
V
25.4
33.4
45.4
57.4
5
