TECHNICAL DATA SHEET
1/2
ADAPTOR FEMALE - FEMALE SEALED
-
R222.705.400
Series :
SMP
All dimensions are in mm.
.
pn
.
ao
COMPONENTS
BODY
CENTER CONTACT
OUTER CONTACT
INSULATOR
GASKET
OTHERS PARTS
-
-
MATERIALS
BERYLLIUM COPPER
BERYLLIUM COPPER
-
PTFE
SILICONE RUBBER
-
-
-
PLATING (
µm
)
GOLD 1.3 OVER NICKEL2
GOLD 1.27 OVER NICKEL 1.27
-
-
-
-
Issue :
1126 B
In the effort to improve our products, we reserve the right to make changes judged to be
necessary.
TECHNICAL DATA SHEET
2/2
ADAPTOR FEMALE - FEMALE SEALED
-
PACKAGING
Standard
100
Unit
‘W’ option
Other
Contact us
R222.705.400
Series :
SMP
SPECIFICATION
ELECTRICAL CHARACTERISTICS
Impedance
Frequency
VSWR
50
Ω
0-40
GHz
1.10
DC to 23GHz
1.15
23 to 26.5GHz
1.70
26.5 to 40 GHz
0.10
NA
335
500
5000
√F(GHz)
dB Maxi
- F(GHz)) dB Maxi
ENVIRONMENTAL
Operating temperature
Hermetic seal
Panel leakage
IP54
-65/+165
° C
Atm.cm3/s
Insertion loss
RF leakage
-(
Voltage rating
Dielectric withstanding voltage
Insulation resistance
Veff Maxi
Veff mini
MΩ mini
OTHER CHARACTERISTICS
Assembly instruction
Others :
MECHANICAL CHARACTERISTICS
Center contact retention
Axial force – Mating end
Axial force – Opposite end
Torque
Recommended torque
Mating
Panel nut
6.7
N mini
6.7
N mini
NA
N.cm mini
Compliant with MIL-STD-348
Max phase variation between products
@ 12GHz: 4.5°
NA
N.cm
NA
N.cm
Mating life
Weight
100
Cycles mini
0,1820
g
Issue :
1126 B
In the effort to improve our products, we reserve the right to make changes judged to be
necessary.
