series 824
Mighty Mouse
locking push-pull connectors
how to order series 824 locking push-pull plug
Sample Part Number
product series
shell style
shell Material/Finish
shell size/contact
Arrangement
contact type
shell key position
824-001
824-001
Mighty Mouse Locking Push-Pull cable plug
with integrated shield termination platform
-06
- Plug
See Table II
See Table I
Connector supplied with contacts:
p
- Pin
s
- Socket
-06 M 8-1
p
A
table i: contact Arrangements
No. of Contacts
Contact
Arr.
5-3
6-1
6-23
6-4
6-6
#23
#20
#20HD
#16
#12
3
1
3
4
6
7
1
5
10
2
8
13
4
2
4
10
19
4
8
2
2
2
5
26
12
4
8
1
2
2
2
3
7
20
37
6
10
2
2
Connector supplied without contacts:
A
- Pin
B
- Socket
6-7
7-1
7-25
7-10
8-2
8-28
Omit for single polarizing key.
A
(normal),
B, c, D, e, F
polarizing options per Table III
how to order series 824 locking push-pull receptacle
Sample Part Number
product series
shell style
824-003
824-003
Mighty Mouse Locking Push-Pull cable
receptacle with integrated shield termination platform
-01
- In-Line
-07
- Rear-Panel Jam Nut Mount
-00
- Front-Panel Jam Nut Mount
See Table II
See Table I
Connector supplied with contacts:
p
- Pin
s
- Socket
-01 M 8-1
p
A
8-13
8-200
9-4
9-210
9-19
9-200
9-201
10-2
10-5
10-26
10-200
10-201
10-202
12-2
12-3
12-7
12-220
12-37
12-200
12-201
series 824
shell Material/Finish
shell size/contact
Arrangement
contact type
shell key position
Mighty Mouse
I
locking push-pull connectors
ntroducing the new Mighty Mouse Series 824 Locking Push-Pull Connector: all the familiar
size, weight and performance advantages of the industry-standard Mighty Mouse 804 push-
pull connector with a revolutionary low-profile locking coupling mechanism. Glenair’s primary
design goal in the development of the locking 824 was to bring mil-spec caliber connector
performance to locking push-pull applications. The Series 824 Locking Push-Pull provides
superior sealing, excellent EMI protection, low-profile ergonomic mating and demating, and
easy crimp contact termination. The locking push-pull mechanism delivers visual, tactile, and
audible mating confirmation under even the most extreme field conditions. Built for long-
term durability and reduced size and weight, the high-density Series 824 Locking Push-Pull
connector far surpasses commercial caliber push-pull connectors.
specifications
Current Rating
#23 5 AMPS, #16 13 A., #12 23 A.
Dielectric Withstanding Voltage #23 500 VAC RMS, #12 and #16 1800 VAC RMS
Insulation Resistance
5000 megohms minimum
Operating Temperature
Shock / Vibration
Shell-to-Shell Resistance,
Nickel Plated
Durability
Breakaway Force
-65° C to +150° C
100 g / 16 g
2 milliohms maximum
500 mating cycles
50 pounds minimum
Connector supplied without contacts:
A
- Pin
B
- Socket
Omit for single polarizing key.
A
(normal),
B, c, D, e, F
polarizing options per Table III
Fast mating, quick-release
coupling mechanism
31 insert arrangements
Integrated cable shield
termination platform
table iii: Alternate key positions
Position
A°
B°
A
150°
210°
B
C
D
E
45°
45°
140°
150°
210°
230°
315°
315°
table ii: Material and Finish
M
nF
Zr
Mt
Aluminum/Electroless Nickel
RoHS Compliant
Aluminum/Cadmium with
Olive Drab Chromate
Aluminum/Zinc-Nickel with
Non-Reflective Black Chromate
RoHS Compliant
Aluminum/Nickel-PTFE
RoHS Compliant
Stainless Steel/Passivated
RoHS Compliant
A°
B°
Z1
gold plated crimp
contacts for #12 to #30
AWg wire
For more information
contact Glenair at
818-247-6000
or
visit our website at
www.glenair.com
MAteriAl/Finish
Barrel: Copper Alloy
Shell/Release Sleeve: Aluminum Alloy or CRES
Insulators: Liquid Crystal Polymer
Interfacial Seal, O-Ring, Grommet: Fluorosilicone
Contacts: Copper Alloy/Gold over Nickel Plating
Spring: CRES/Gold Plated
For more information
contact Glenair at
818-247-6000
or
visit our website at
www.glenair.com
