This document was generated on 10/06/2017
PLEASE CHECK WWW.MOLEX.COM FOR LATEST PART INFORMATION
Part Number:
Status:
Overview:
Description:
0761505110
Active
Impact Backplane Connector and Cable Assembly System
Impact 100 Ohm 6 Pair Right Angle Daughtercard Receptacle, Right Guided, 10
Columns, 180 Circuits, Plated Through Hole Dimension 0.46mm, Polarizing Key
Position A, Lead-Free
Documents:
3D Model
Drawing (PDF)
Product Specification PS-76060-999-001 (PDF)
Application Specification AS-76060-990-001 (PDF)
Agency Certification
UL
General
Product Family
Series
Application
Application Tooling Documents
Component Type
Electrical Model
Overview
Product Name
UPC
Physical
Circuits (Loaded)
Circuits (maximum)
Color - Resin
Durability (mating cycles max)
First Mate / Last Break
Flammability
Guide to Mating Part
Keying to Mating Part
Material - Metal
Material - Plating Mating
Material - Plating Termination
Material - Resin
Net Weight
Number of Columns
Number of Pairs
Number of Rows
Orientation
PC Tail Length
PCB Locator
PCB Retention
PCB Thickness - Recommended
Packaging Type
Pitch - Mating Interface
Pitch - Termination Interface
Plating min - Mating
Polarized to PCB
Stackable
Temperature Range - Operating
Application Specification AS-76060-9999-001 (PDF)
Packaging Specification PK-70873-589 (PDF)
RoHS Certificate of Compliance (PDF)
Series image - Reference only
EU ELV
Not Reviewed
E29179
Backplane Connectors
76150
Conventional, Coplanar, Daughtercard
TM-622018799
PCB Receptacle
Yes
Impact Backplane Connector and Cable Assembly
System
Impact
883906514631
180
180
Black
200
No
94V-0
Yes
Yes
High Performance Alloy (HPA)
Gold
Tin
High Temperature Thermoplastic
27.992/g
10
6
18
Right Angle
1.20mm
No
Yes
1.00mm
Tray
1.90mm
1.90mm
0.762µm
Yes
No
-55°C to +85°C
EU RoHS
China RoHS
Not Reviewed
REACH SVHC
Not Reviewed
Halogen-Free
Status
Not Reviewed
Need more information on product
environmental compliance?
Email productcompliance@molex.com
Please visit the Contact Us section for any
non-product compliance questions.
China ROHS
ELV
RoHS Phthalates
Not Reviewed
Not Reviewed
Not Reviewed
Search Parts in this Series
76150 Series
Mates With
76145 Impact 100 Ohm Vertical Backplane
Header
Termination Interface: Style
Electrical
Current - Maximum per Contact
Data Rate
Impedance
Shield Type
Shielded
Voltage - Maximum
Material Info
Reference - Drawing Numbers
Application Specification
Electrical Model Document
Packaging Specification
Product Specification
S-Parameter Model
Sales Drawing
Symbol/Footprint Data
Through Hole - Compliant Pin
0.75A
25.0 Gbps
100Ω
N/A
No
30V AC (RMS)/DC
AS-76060-990-001, AS-76060-9999-001
EE-76150-001, EE-76560-0001
PK-70873-589
PS-76060-999-001
SP-76150-001, SP-76560-0001
SD-76150-004
SYM-76150-5110
