MULTILAYER CERAMIC CHIP CAPACITORS
C Series
Commercial Grade
High Temperature Application
Type:
C1005 [EIA CC0402]
C1608 [EIA CC0603]
C2012 [EIA CC0805]
C3216 [EIA CC1206]
C3225 [EIA CC1210]
C4532 [EIA CC1812]
C5750 [EIA CC2220]
Issue date:
Jun 2015
20150616 / mlcc_commercial_hightemp_en
MULTILAYER CERAMIC CHIP CAPACITORS
REMINDERS
Please read before using this product
SAFETY REMINDERS
REMINDERS
1.
2.
3.
If you intend to use a product listed in this catalog for a purpose that may cause loss of life or other damage,
you must contact our company’s sales window.
We may modify products or discontinue production of a product listed in this catalog without prior notification.
We provide “Delivery Specification” that explain precautions for the specifications and safety of each product
listed in this catalog. We strongly recommend that you exchange these delivery specifications with customers
that use one of these products.
If you plan to export a product listed in this catalog, keep in mind that it may be a restricted item according
to the “Foreign Exchange and Foreign Trade Control Law”. In such cases, it is necessary to acquire export
permission in harmony with this law.
Any reproduction or transferring of the contents of this catalog is prohibited without prior permission from our
company.
We are not responsible for problems that occur related to the intellectual property rights or other rights of our
company or a third party when you use a product listed in this catalog. We do not grant license of these rights.
This catalog only applies to products purchased through our company or one of our company’s official agencies.
This catalog does not apply to products that are purchased through other third parties.
4.
5.
6.
7.
Notice: Effective January 2013, TDK will use a new catalog number which adds product thickness and packaging
specification detail. This new catalog number should be referenced on all catalog orders going forward, and
is not applicable for OEM part number orders. Please be aware the last five digits of the catalog number will
differ from the item description (internal control number) on the product label. Contact your local TDK Sales
representative for more information.
(Example)
Catalog Issued date
Prior to January 2013
January 2013 and Later
Catalog Number
C1608C0G1E103J
C1608C0G1E103J080AA
Item Description (On Delivery Label)
C1608C0G1E103JT000N
C1608C0G1E103JT000N
Page 1
20150616 / mlcc_commercial_hightemp_en
MULTILAYER CERAMIC CHIP CAPACITORS
C Series
High Temperature Application
Type: C1005 [EIA CC0402], C1608 [EIA CC0603], C2012 [EIA CC0805],
C3216 [EIA CC1206], C3225 [EIA CC1210], C4532 [EIA CC1812], C5750 [EIA CC2220]
Features
• With a maximum temperature of 150°C and a capacitance
change within ±15%, the series is suited for devices that
operate in high-temperature environments.
• Excellent DC bias properties.
Parameters
Temperature
Characteristics
Operating Temperature
Dissipation Factor
Insulation Resistance
Voltage Proof
Specifications
-55 to 150°C
C/C: ±15% or 0 ± 30ppm
-55 to +150°C
5% maximum
10 G or 500 M • F
minimum
2.5 • Rated Voltage or 3 • Rated
Voltage for 1 to 5 seconds
Charge/Discharge 50 mA
Applications
• Automotive applications (engine rooms)
• Measurement instruments used at high
temperature environments
• LCD display
• Sensor Module
• Smoothing and decoupling applications for other
devices that operate at high temperature
Shape &
Dimensions
L
W
T
B
G
Body Length
Body Width
Body Height
Terminal Width
Terminal Spacing
Catalog Number
Construction
Series Name
Dimensions L x W (mm)
Code
C1005
C1608
C2012
C3216
C3225
C4532
C5750
Length
1.00 ± 0.05
1.60 ± 0.10
2.00 ± 0.20
3.20 ± 0.20
3.20 ± 0.40
4.50 ± 0.40
5.70 ± 0.40
C • 3225 • X8R • 1C • 106 • K • 250 • A • B
Width
0.50 ±
0.80 ±
1.25 ±
1.60 ±
2.50 ±
3.20 ±
5.00 ±
0.05
0.10
0.20
0.20
0.30
0.40
0.40
Terminal
0.10 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
0.20 min.
*Dimensional tolerances are typical values.
Temperature Characteristics
Temperature
Characteristics
NP0
X8R
Code
1C
1E
1H
Temperature Coefficient or
Capacitance Change
0 ± 30ppm/°C
± 15%
Voltage (DC)
16V
25V
50V
Code
2A
2E
2W
2J
Temperature
Range
-55 to +150°C
-55 to +150°C
Voltage (DC)
100V
250V
450V
630V
Rated Voltage (DC)
Nominal Capacitance (pF)
The capacitance is expressed in three digit codes and
in units of pico Farads (pF). The first and second digits
identify the first and second significant figures of the
capacitance. The third digit identifies the multiplier. R
designates a decimal point.
Ex. 0R2 = 0.2pF; 103 = 10,000pF; 105 = 1,000,000pF =
1,000nF
Capacitance Tolerance
Code
C
D
J
K
M
Thickness
2.30 mm
2.50 mm
2.80 mm
3.20 mm
Tolerance
± 0.25pF
± 0.50pF
± 5%
± 10%
± 20%
Nominal Thickness
Code
050
060
080
085
115
125
160
200
Thickness
0.50 mm
0.60 mm
0.80 mm
0.85 mm
1.15 mm
1.25 mm
1.60 mm
2.00 mm
Code
230
250
280
320
Packaging Style
Code
A
B
K
Style
178 mm Reel, 4 mm Pitch
178 mm Reel, 2 mm Pitch
178 mm Reel, 8 mm Pitch
Special Reserved Code
Code
A, B
Description
TDK Internal Code
Page 2
Please
be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20150616 / mlcc_commercial_hightemp_en
MULTILAYER CERAMIC CHIP CAPACITORS
Capacitance
Range Chart
Capacitance Range Chart
Temperature Characteristics: NP0 (0 ± 30ppm/ºC), X8R (± 15%)
Rated Voltage: 100V (2A), 50V (1H), 25V (1E), 16V (1C)
Capacitance
(pF)
1
1.5
2
2.2
3
3.3
4
4.7
5
6
6.8
7
8
9
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1,000
1,500
2,200
3,300
4,700
6,800
10,000
15,000
22,000
33,000
47,000
NP0
Code
010
1R5
020
2R2
030
3R3
040
4R7
050
060
6R8
070
080
090
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
152
222
332
472
682
103
153
223
333
473
Tolerance
C: ± 0.25pF
D: ± 0.50pF
J: ± 5%
K: ± 10%
M: ± 20%
X8R
1E
(25V)
1C
(16V)
EIA CC0402 [C1005]
2A
1H
2A
1H
(100V) (50V) (100V) (50V)
Standard Thickness
0.50 mm
Page 3
Please
be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20150616 / mlcc_commercial_hightemp_en
MULTILAYER CERAMIC CHIP CAPACITORS
Capacitance
Range Chart
Capacitance Range Chart
Temperature Characteristics: NP0 (0 ± 30ppm/ºC), X8R (±15%)
Rated Voltage: 250V (2E), 100V (2A), 50V (1H), 25V (1E), 16V (1C)
Capacitance
(pF)
1
2
2
2
3
3
4
5
5
6
7
7
8
9
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
390
470
560
680
820
1,000
1,200
1,500
1,800
2,200
2,700
3,300
3,900
4,700
5,600
6,800
8,200
10,000
NP0
Code
010
1R5
020
2R2
030
3R3
040
4R7
050
060
6R8
070
080
090
100
120
150
180
220
270
330
390
470
560
680
820
101
121
151
181
221
271
331
391
471
561
681
821
102
122
152
182
222
272
332
392
472
562
682
822
103
Tolerance
C: ± 0.25pF
D: ± 0.50pF
J: ± 5%
2E
2A
1H
(250V) (100V) (50V)
Capacitance
(pF)
1,000
1,500
2,200
3,300
4,700
6,800
10,000
15,000
22,000
33,000
47,000
68,000
100,000
150,000
220,000
330,000
470,000
X8R
Code
102
152
222
332
472
682
103
153
223
333
473
683
104
154
224
334
474
Tolerance
K: ± 10%
M: ± 20%
2A
1H
(100V) (50V)
1E
(25V)
1C
(16V)
EIA CC0603 [C1608]
Standard Thickness
0.80 mm
Page 4
Please
be sure to request delivery specifications that provide further details on the features and specifications of the products for proper and safe use.
Please note that the contents may change without any prior notice due to reasons such as upgrading.
20150616 / mlcc_commercial_hightemp_en
