Features
■
Available in E12 series
■
Low profile - 4.7 mm unit height
■
High current
■
RoHS compliant*
Applications
■
Input/output of DC/DC converters
■
Power supplies for:
•
Portable communication equipment
•
Camcorders
•
LCD TVs
•
Car radios
*R
oH
S
SRR0805 Series - Shielded Power Inductor
Electrical Specifications
Inductance 1kHz
Bourns Part No.
(µH)
SRR0805 - 2R2M
SRR0805 - 3R9M
SRR0805 - 5R6M
SRR0805 - 8R2M
SRR0805 - 100M
SRR0805 - 120M
SRR0805 - 150M
SRR0805 - 180Y
SRR0805 - 220Y
SRR0805 - 270Y
SRR0805 - 330Y
SRR0805 - 390Y
SRR0805 - 470Y
SRR0805 - 560K
SRR0805 - 680K
SRR0805 - 820K
SRR0805 - 101K
SRR0805 - 121K
SRR0805 - 151K
SRR0805 - 181K
SRR0805 - 221K
SRR0805 - 271K
SRR0805 - 331K
SRR0805 - 471K
SRR0805 - 561K
SRR0805 - 681K
SRR0805 - 821K
SRR0805 - 102K
2.2
3.9
5.6
8.2
10
12
15
18
22
27
33
39
47
56
68
82
100
120
150
180
220
270
330
470
560
680
820
1000
Tol. %
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
±
20
20
20
20
20
20
20
15
15
15
15
15
15
10
10
10
10
10
10
10
10
10
10
10
10
10
10
10
Q
Ref.
18
20
20
19
40
40
40
40
38
35
40
35
32
30
28
28
45
42
39
41
38
37
36
34
32
32
35
35
Test
Frequency
(MHz)
7.96M
7.96M
7.96M
7.96M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
2.52M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.796M
0.252M
SRF
Min.
(MHz)
75.0
50.0
40.0
32.0
28.0
24.0
22.0
19.0
19.0
15.5
13.5
12.0
10.5
9.5
9.0
8.5
7.5
7.0
6.5
4.8
4.5
4.2
3.8
3.5
3.0
2.8
2.5
2.2
RDC
Max.
(Ω)
0.040
0.055
0.065
0.080
0.100
0.120
0.140
0.160
0.180
0.200
0.240
0.260
0.280
0.380
0.440
0.550
0.600
0.750
0.90
1.05
1.18
1.40
1.80
2.25
3.00
3.40
4.00
5.00
I rms
Max.
(A)
2.50
2.10
1.95
1.75
1.50
1.40
1.30
1.20
1.10
1.00
0.92
0.84
0.75
0.68
0.60
0.54
0.50
0.45
0.40
0.35
0.30
0.27
0.24
0.20
0.18
0.17
0.16
0.15
I sat
Typ.
(A)
4.90
3.70
3.20
2.50
2.20
2.10
1.80
1.70
1.50
1.40
1.20
1.10
1.00
0.95
0.90
0.74
0.70
0.66
0.64
0.62
0.55
0.45
0.38
0.35
0.34
0.32
0.29
0.24
General Specifications
Test Voltage........................................1 V
Reflow soldering.....250 °C; 10 sec max.
(In compliance with JEDEC,
J-STD-020C, Table 4-2)
Operating Temperature ..-40 °C to +125 °C
(Temperature rise included)
Storage Temperature..-40 °C to +125 °C
Resistance to Soldering Heat
............................260 °C, 10 sec. max.
Materials
Core ...................................Ferrite DR&RI
Wire .............................Enameled copper
Base ......................................LCP E4008
Terminal.....................................Cu/Ni/Sn
Rated Current
...................Ind. drop 10 % typ. at Isat
Temperature Rise
......................40 °C max. at rated Irms
Packaging...................1000 pcs. per reel
Product Dimensions
101
8.0
±
0.2
(.315
±
.008)
10.5
±
0.3
(.413
±
.012)
4.7
MAX.
(.185)
Soldering Profile
275
<1> Max. of 10 seconds at 250 °C
<1> 250 °C
6.0
(.236)
TYP.
2.1
TYP.
(.082)
225
217 °C
190 °C
175
60-150
seconds
Ramp down
6 °/second maximum
2.0
TYP.
(.079)
DIMENSIONS:
Temperature (°C)
125
120 - 150 seconds
10 seconds min.
MM
(INCHES)
Recommended Layout
5.7
(.224)
Ramp up
3 °/second maximum
75
2.2
(.086)
0
0
50
100
150
Time
(seconds)
200
250
300
2.5
(.099)
*RoHS Directive 2002/95/EC Jan 27, 2003 including Annex.
Specifications are subject to change without notice.
Customers should verify actual device performance in their specific applications.
