Model: FXO-HC73 SERIES
HCMOS 7 x 5mm 3.3V Oscillator
Features
X
TREMELY
Low Jitter
Low Cost
X
PRESS
Delivery
Frequency Resolution to six decimal places
Stabilities to ± 20 PPM
-20 to +70°C or -40 to +85°C operating temperatures
Tri-State Enable / Disable Feature
Industry Standard Package, Footprint & Pin-Out
Fully RoHS compliant
Gold over Nickel Termination Finish
Serial ID with Comprehensive Traceability
V
DD
Enable / Disable
Freq: 0.75 MHz to 250MHz
Rev. 11/28/2007
Applications
•
•
•
•
•
•
•
•
•
X
PRESS
O
ASICs
GND
FOX
OUTPUT
ANY application requiring an oscillator
SONET
Ethernet
Storage Area Network
Broadband Access
Microprocessors / DSP / FPGA
Industrial Controllers
Test and Measurement Equipment
Fiber Channel
For more information -- Click on the drawing
Description
The Fox X
PRESS
O Crystal Oscillator is a
breakthrough in configurable Frequency Control
Solutions. X
PRESS
O utilizes a family of
proprietary ASICs, designed and developed by
Fox, with a key focus on noise reduction
technologies.
The 3
rd
order Delta Sigma Modulator reduces
noise to the levels that are comparable to
traditional Bulk Quartz and SAW oscillators.
The ASICs family has ability to select the output
type, input voltages, and temperature
performance features.
With the X
PRESS
lead-time, low cost, low noise,
wide frequency range, excellent ambient
performance, XpressO is an excellent choice
over the conventional technologies.
Finished X
PRESS
O parts are 100% final tested.
Contents
Model Selection & Part Number Guide
2
Electrical Characteristic
2
Absolute Maximums
3
Output Wave Characteristics
3
Phase Noise
4
Jitter
4
Pin Assignment
5
Recommended Circuit
5
Reflow
5
Mechanical Drawing and Pad Layout
6
Tape and Reel Specification
7
Label
7
Traceability – LOT Number & Serial Identification 8
RoHS Material Declaration
9
SGS Report
10 & 11
Mechanical Test
12
Burn-In Test
12
MTTF / FITS calculations
13
14
Other X
PRESS
O Links
Fox Contact Information
14
page
FOXElectronics
5570 Enterprise Parkway Fort Myers, Florida 33905 USA +1.239.693.0099 FAX +1.239.693.1554 http://www.foxonline.com
EMEA
Tel/Fax: +44 .1767.312632 |
Asia
Hong Kong Tel: +852.2854.4285 Fax +852.2854.4282
Taiwan
Tel: +886.2.22073427 Fax +886.2.22073486 |
Japan
Tel: +81.3.3374.2079 Fax: +81.3.3374.5221
© 2008 FOX ELECTRONICS | ISO9001:2000 Certified
Page 1 of 14
This part is no longer available from Fox, please contact IDT for this product.
FXO-HC73
Series
Model Selection Guide & Fox Part Number
