HIN208CBZ-T datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Drivers and interfaces> HIN208CBZ-T

HIN208CBZ-T: Description+5V Powered RS-232 Transmitters/Receivers with 0.1µF External Capacitors; SOIC24; Temp Range: See Datasheet; CategoryAnalog mixed-signal IC Drivers and interfaces; File Size484KB，19 Pages; ManufacturerIntersil ( Renesas ); Websitehttp://www.intersil.com/cda/home/; Environmental Compliance

Download Datasheet Parametric Compare View All

HIN208CBZ-T Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	HIN208CBZ-T	-	-	View	Buy Now

HIN208CBZ-T Overview

+5V Powered RS-232 Transmitters/Receivers with 0.1µF External Capacitors; SOIC24; Temp Range: See Datasheet

HIN208CBZ-T Parametric

Parameter Name	Attribute value
Brand Name	Intersil
Is it Rohs certified?	conform to
Objectid	2061389402
Parts packaging code	SOIC
package instruction	SOP, SOP24,.4
Contacts	24
Reach Compliance Code	compliant
ECCN code	EAR99
Differential output	NO
Number of drives	4
High level input current maximum value	0.0002 A
Input properties	SCHMITT TRIGGER
Interface integrated circuit type	LINE TRANSCEIVER
Interface standards	EIA-232-E; V.28
JESD-30 code	R-PDSO-G24
JESD-609 code	e3
length	15.4 mm
Humidity sensitivity level	3
Number of functions	4
Number of terminals	24
Maximum operating temperature	70 °C
Minimum operating temperature
Minimum output swing	10 V
Maximum output low current	0.0016 A
Package body material	PLASTIC/EPOXY
encapsulated code	SOP
Encapsulate equivalent code	SOP24,.4
Package shape	RECTANGULAR
Package form	SMALL OUTLINE
Peak Reflow Temperature (Celsius)	260
power supply	5 V
Certification status	Not Qualified
Maximum receive delay	10000 ns
Number of receiver bits	4
Maximum seat height	2.65 mm
Maximum slew rate	20 mA
Maximum supply voltage	5.5 V
Minimum supply voltage	4.5 V
Nominal supply voltage	5 V
surface mount	YES
technology	CMOS
Temperature level	COMMERCIAL
Terminal surface	MATTE TIN
Terminal form	GULL WING
Terminal pitch	1.27 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	30
maximum transmission delay	10000 ns
width	7.5 mm

Preview

Download Datasheet

View All

HIN202, HIN206, HIN207,

HIN208, HIN211, HIN213

Data Sheet

July 27, 2005

FN3980.18

+5V Powered RS-232

Transmitters/Receivers with 0.1Microfarad

External Capacitors

The HIN202, HIN206, HIN207, HIN208, HIN211, HIN213

family of RS-232 transmitters/receivers interface circuits

meet all ElA RS-232E and V.28 specifications, and are

particularly suited for those applications where

±12V

is not

available. They require a single +5V power supply and

feature onboard charge pump voltage converters which

generate +10V and -10V supplies from the 5V supply. The

family of devices offers a wide variety of RS-232

transmitter/receiver combinations to accommodate various

applications (see Selection Table).

The HIN206, HIN211 and HIN213 feature a low power

shutdown mode to conserve energy in battery powered

applications. In addition, the HIN213 provides two active

receivers in shutdown mode allowing for easy “wakeup”

capability.

The drivers feature true TTL/CMOS input compatibility, slew

rate-limited output, and 300Ω power-off source impedance.

The receivers can handle up to

±30V

input, and have a 3kΩ

to 7kΩ input impedance. The receivers also feature

hysteresis to greatly improve noise rejection.

Features

• Pb-Free Plus Anneal Available (RoHS Compliant)

(See Ordering Info)

• Meets All RS-232E and V.28 Specifications

• Requires Only 0.1µF or Greater External Capacitors

• High Data Rate. . . . . . . . . . . . . . . . . . . . . . . . . . .120kbit/s

• Two Receivers Active in Shutdown Mode (HIN213)

• Requires Only Single +5V Power Supply

• Onboard Voltage Doubler/Inverter

• Low Power Consumption (Typ) . . . . . . . . . . . . . . . . . 5mA

• Low Power Shutdown Function (Typ) . . . . . . . . . . . . .1µA

• Three-State TTL/CMOS Receiver Outputs

• Multiple Drivers

±10V

Output Swing for +5V lnput

- 300Ω Power-Off Source Impedance

- Output Current Limiting

- TTL/CMOS Compatible

- 30V/µs Maximum Slew Rate

• Multiple Receivers

±30V

Input Voltage Range

- 3kΩ to 7kΩ Input Impedance

- 0.5V Hysteresis to Improve Noise Rejection

Applications

• Any System Requiring RS-232 Communications Port

- Computer - Portable, Mainframe, Laptop

- Peripheral - Printers and Terminals

- Instrumentation

- Modems

Selection Table

PART

NUMBER

HIN202

HIN206

HIN207

HIN208

HIN211

HIN213

POWER SUPPLY

VOLTAGE

+5V

NUMBER OF

RS-232

DRIVERS

NUMBER OF

RS-232

RECEIVERS

NUMBER OF

0.1µF

EXTERNAL

CAPACITORS

4 Capacitors

LOW POWER

SHUTDOWN/TTL

THREE-STATE

No/No

Yes/Yes

No/No

Yes/Yes

NUMBER OF

RECEIVERS

ACTIVE IN

SHUTDOWN

CAUTION: These devices are sensitive to electrostatic discharge; follow proper IC Handling Procedures.

1-888-INTERSIL or

1-888-468-3774

Intersil (and design) is a registered trademark of Intersil Americas Inc.

All other trademarks mentioned are the property of their respective owners.
