STNRG288ATR datasheet, PDF - EEWORLD Datasheet

Datasheet> All Categories > Analog mixed-signal IC> The signal circuit> STNRG288ATR

STNRG288ATR: CategoryAnalog mixed-signal IC The signal circuit; File Size3MB，131 Pages; ManufacturerSTMicroelectronics; Websitehttp://www.st.com/

Download Datasheet Parametric View All

STNRG288ATR Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	STNRG288ATR	-	-	View	Buy Now

STNRG288ATR Parametric

Parameter Name	Attribute value
Brand Name	STMicroelectronics
Maker	STMicroelectronics
package instruction	TSSOP, TSSOP28,.25
Reach Compliance Code	compliant
ECCN code	3A991.A.2
Factory Lead Time	12 weeks
Analog Integrated Circuits - Other Types	ANALOG CIRCUIT
JESD-30 code	R-PDSO-G28
Number of terminals	28
Maximum operating temperature	105 °C
Minimum operating temperature	-40 °C
Package body material	PLASTIC/EPOXY
encapsulated code	TSSOP
Encapsulate equivalent code	TSSOP28,.25
Package shape	RECTANGULAR
Package form	SMALL OUTLINE, THIN PROFILE, SHRINK PITCH
Peak Reflow Temperature (Celsius)	NOT SPECIFIED
power supply	3.3/5 V
Certification status	Not Qualified
Maximum supply current (Isup)	12.74 mA
surface mount	YES
Temperature level	INDUSTRIAL
Terminal form	GULL WING
Terminal pitch	0.635 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED

Preview

Download Datasheet

View All

STNRGxxxA

Digital controller for power conversion applications

with up to 6 programmable PWM generators, 96 MHz PLL

Datasheet

production data

– Data memory: 1 Kbyte true data E

PROM;

data retention:15 years at 85 °C after 100

kcycles at 85 °C

– RAM: 6 Kbytes



Clock management

– Internal 96 MHz PLL

– Low power oscillator circuit for external

crystal resonator or direct clock input

– Internal, user-trimmable 16 MHz RC and

low power 153.6 kHz RC oscillators

– Clock security system with clock monitor



Basic peripherals

– System, auxiliary and basic timers

– IWDG/WWDG watchdog, AWU, ITC



Reset and supply management

– Multiple low power modes (wait, slow, auto-

wakeup, Halt) with user definable clock

gating

– Low consumption power-on and power-

down reset



I/O

– Multifunction bidirectional GPIO with highly

robust design, immune against current

injection

– Fast digital input DIGIN, with configurable

pull-up



Communication interfaces

– UART asynchronous with SW flow control

and bootloader support

– I

C master/slave fast-slow speed rate



Operating temperature: -40 °C up to 105 °C.

Table 1. Device summary

Part number

STNRG388A

STNRG328A

STNRG288A

Package

TSSOP38

VFQFPN32

TSSOP28

Features



Up to 6 programmable PWM generators

(SMED - “State Machine Event Driven”)

– 10 ns event detection and reaction

– Max.1.3 ns PWM resolution

– Single, coupled and two coupled

operational modes

– Up to 3 internal/external events per SMED



4 analog comparators

– 4 internal 4-bit references

– Up to 4 external references

– Less than 50 ns propagation time

– Continuous comparison cycle

– Configurable hysteresis voltage levels



ADCs (up to 8 channels)

– 10-bit precision, with operational amplifier

to extend resolution to 12-bit equivalent

– Sequencer functionality

– Input impedance: 1 M

– Configurable gain value: x1 and x4



Integrated microcontroller

– Advanced STM8

core with Harvard

architecture and 3-stage pipeline

– Max. f

CPU

: 16 MHz



Memories

– Flash and E

PROM with read while write

(RWW) and error correction code (ECC)

– Program memory: 32 Kbytes Flash; data

retention 15 years at 85 °C after 10 kcycles

at 25 °C

October 2016

This is information on a product in full production.

DocID027799 Rev 2

1/131

www.st.com
