MAX454EJD datasheet, PDF - EEWORLD Datasheet

EEWORLDEEWORLD

Datasheet

Datasheet> All Categories > Analog mixed-signal IC> Amplifier circuit> MAX454EJD

Preview

MAX454EJD: DescriptionVideo Amplifiers; CategoryAnalog mixed-signal IC Amplifier circuit; File Size301KB，8 Pages; ManufacturerMaxim; Websitehttps://www.maximintegrated.com/en.html

Download Datasheet Parametric Compare View All

MAX454EJD Online Shopping

Suppliers	Part Number	Price	MOQ	In stock
	MAX454EJD	-	-	View	Buy Now

MAX454EJD Overview

Video Amplifiers

MAX454EJD Parametric

Parameter Name	Attribute value
Is it lead-free?	Contains lead
Is it Rohs certified?	incompatible
Maker	Maxim
Parts packaging code	DIP
package instruction	CERDIP-14
Contacts	14
Reach Compliance Code	not_compliant
ECCN code	EAR99
Factory Lead Time	1 week
Amplifier type	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.03 µA
Nominal Common Mode Rejection Ratio	80 dB
Maximum input offset voltage	5000 µV
JESD-30 code	R-GDIP-T14
JESD-609 code	e0
length	19.43 mm
Humidity sensitivity level	1
Nominal Negative Supply Voltage (Vsup)	-5 V
Number of functions	1
Number of terminals	14
Maximum operating temperature	85 °C
Minimum operating temperature	-40 °C
Package body material	CERAMIC, GLASS-SEALED
encapsulated code	DIP
Package shape	RECTANGULAR
Package form	IN-LINE
Peak Reflow Temperature (Celsius)	245
Certification status	Not Qualified
Maximum seat height	5.842 mm
Nominal slew rate	300 V/us
Nominal supply voltage (Vsup)	5 V
surface mount	NO
technology	CMOS
Temperature level	INDUSTRIAL
Terminal surface	Tin/Lead (Sn/Pb)
Terminal form	THROUGH-HOLE
Terminal pitch	2.54 mm
Terminal location	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED
Nominal Uniform Gain Bandwidth	50000 kHz
width	7.62 mm

Preview

Download Datasheet

View All

MAX454EJD Related Products

	MAX454EJD	MAX453EPA	MAX454EPD-	MAX452ESA-T	MAX452MJA
Description	Video Amplifiers		Video Amplifiers 50MHz Video Amp u0026 MUX Amp		Video Amplifiers
Is it lead-free?	Contains lead	Contains lead	-	Contains lead	Contains lead
Is it Rohs certified?	incompatible	incompatible	-	incompatible	incompatible
Maker	Maxim	Maxim	-	Maxim	Maxim
Parts packaging code	DIP	DIP	-	SOIC	DIP
package instruction	CERDIP-14	PLASTIC, DIP-8	-	0.150 INCH, SOIC-8	CERDIP-8
Contacts	14	8	-	8	8
Reach Compliance Code	not_compliant	not_compliant	-	not_compliant	not_compliant
ECCN code	EAR99	EAR99	-	EAR99	EAR99
Amplifier type	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER	-	OPERATIONAL AMPLIFIER	OPERATIONAL AMPLIFIER
Maximum average bias current (IIB)	0.03 µA	0.03 µA	-	0.03 µA	0.5 µA
Nominal Common Mode Rejection Ratio	80 dB	80 dB	-	80 dB	80 dB
Maximum input offset voltage	5000 µV	5000 µV	-	5000 µV	5000 µV
JESD-30 code	R-GDIP-T14	R-PDIP-T8	-	R-PDSO-G8	R-GDIP-T8
JESD-609 code	e0	e0	-	e0	e0
length	19.43 mm	9.375 mm	-	4.9 mm	-
Humidity sensitivity level	1	1	-	1	1
Nominal Negative Supply Voltage (Vsup)	-5 V	-5 V	-	-5 V	-5 V
Number of functions	1	1	-	1	1
Number of terminals	14	8	-	8	8
Maximum operating temperature	85 °C	85 °C	-	85 °C	125 °C
Minimum operating temperature	-40 °C	-40 °C	-	-40 °C	-55 °C
Package body material	CERAMIC, GLASS-SEALED	PLASTIC/EPOXY	-	PLASTIC/EPOXY	CERAMIC, GLASS-SEALED
encapsulated code	DIP	DIP	-	SOP	DIP
Package shape	RECTANGULAR	RECTANGULAR	-	RECTANGULAR	RECTANGULAR
Package form	IN-LINE	IN-LINE	-	SMALL OUTLINE	IN-LINE
Peak Reflow Temperature (Celsius)	245	240	-	NOT SPECIFIED	240
Certification status	Not Qualified	Not Qualified	-	Not Qualified	Not Qualified
Maximum seat height	5.842 mm	4.572 mm	-	1.75 mm	5.08 mm
Nominal slew rate	300 V/us	300 V/us	-	300 V/us	300 V/us
Nominal supply voltage (Vsup)	5 V	5 V	-	5 V	5 V
surface mount	NO	NO	-	YES	NO
technology	CMOS	CMOS	-	CMOS	CMOS
Temperature level	INDUSTRIAL	INDUSTRIAL	-	INDUSTRIAL	MILITARY
Terminal surface	Tin/Lead (Sn/Pb)	Tin/Lead (Sn85Pb15)	-	Tin/Lead (Sn85Pb15)	Tin/Lead (Sn85Pb15)
Terminal form	THROUGH-HOLE	THROUGH-HOLE	-	GULL WING	THROUGH-HOLE
Terminal pitch	2.54 mm	2.54 mm	-	1.27 mm	2.54 mm
Terminal location	DUAL	DUAL	-	DUAL	DUAL
Maximum time at peak reflow temperature	NOT SPECIFIED	20	-	NOT SPECIFIED	20
Nominal Uniform Gain Bandwidth	50000 kHz	50000 kHz	-	50000 kHz	50000 kHz
width	7.62 mm	7.62 mm	-	3.9 mm	7.62 mm
