BBY55...
Silicon Tuning Diodes
•
Excellent linearity
•
High Q hyperabrupt tuning diode
•
Low series resistance
•
Designed for low tuning voltage operation
for VCO's in mobile communications equipment
•
Very low capacitance spread
•
Pb-free (RoHS compliant) package
BBY55-02V
BBY55-02W
BBY55-03W
Type
BBY55-02V
BBY55-02W
BBY55-03W
Package
SC79
SCD80
SOD323
Configuration
single
single
single
L
S
(nH)
0.6
0.6
1.8
Marking
7
77
white 7
Maximum Ratings
at
T
A
= 25°C, unless otherwise specified
Parameter
Diode reverse voltage
Forward current
Operating temperature range
Storage temperature
Symbol
V
R
I
F
T
op
T
stg
Value
16
20
-55 ... 150
-55 ... 150
Unit
V
mA
°C
1
2011-06-15
BBY55...
Electrical Characteristics
at
T
A
= 25°C, unless otherwise specified
Parameter
DC Characteristics
Reverse current
V
R
= 15 V
V
R
= 15 V,
T
A
= 85 °C
AC Characteristics
Diode capacitance
V
R
= 1 V,
f
= 1 MHz
V
R
= 2 V,
f
= 1 MHz
V
R
= 3 V,
f
= 1 MHz
V
R
= 4 V,
f
= 1 MHz
V
R
= 10 V,
f
= 1 MHz
Capacitance ratio
V
R
= 2 V,
V
R
= 10 V,
f
= 1 MHz
Series resistance
V
R
= 5 V,
f
= 470 MHz
r
S
-
0.15
0.4
Ω
C
T2
/C
T10
C
T
17.5
14
11.6
10
5.5
2
18.6
15
12.6
11
6
2.5
19.6
16
13.6
12
6.5
3
pF
Symbol
min.
I
R
-
-
Values
typ.
max.
Unit
nA
-
-
3
100
2
2011-06-15
Package SCD80
BBY55...
Package Outline
0.2
0.8
±0.1
10˚MAX.
M
A
+0.05
0.13
-0.03
A
7˚
±1.5˚
1.3
±0.1
2
1.7
±0.1
0.7
±0.1
Foot Print
1.45
0.35
Marking Layout (Example)
2005, June
Date code
0.35
BAR63-02W
Type code
Cathode marking
Laser marking
Standard Packing
Reel ø180 mm = 3.000 Pieces/Reel
Reel ø180 mm = 8.000 Pieces/Reel (2 mm Pitch)
Reel ø330 mm = 10.000 Pieces/Reel
Standard
4
Reel with 2 mm Pitch
2
0.2
1.45
2.5
8
0.2
±0.05
Cathode
marking
1
0.3
±0.05
Cathode
marking
0.4
0.9
Cathode
marking
0.7
5
2011-06-15
