• Distributes one clock input to one bank of five and one bankd
of four outputs
• Separate output enable for each output bank
• Output Skew < 250ps
• Low jitter <200 ps cycle-to-cycle
• IDT2309-1 for Standard Drive
• IDT2309-1H for High Drive
• No external RC network required
• Operates at 3.3V V
DD
• Available in SOIC and TSSOP packages
DESCRIPTION:
The IDT2309 is a high-speed phase-lock loop (PLL) clock buffer,
designed to address high-speed clock distribution applications. The zero
delay is achieved by aligning the phase between the incoming clock and
the output clock, operable within the range of 10 to 133MHz.
The IDT2309 is a 16-pin version of the IDT2305. The IDT2309 accepts
one reference input, and drives two banks of four low skew clocks. The
-1H version of this device operates at up to 133MHz frequency and has
higher drive than the -1 device. All parts have on-chip PLLs which lock
to an input clock on the REF pin. The PLL feedback is on-chip and is
obtained from the CLKOUT pad. In the absence of an input clock, the
IDT2309 enters power down, and the outputs are tri-stated. In this mode,
the device will draw less than 25µA.
The IDT2309 is characterized for both Industrial and Commercial
operation.
FUNCTIONAL BLOCK DIAGRAM
16
CLKOUT
1
REF
PLL
2
CLKA1
3
CLKA2
14
CLKA3
15
CLKA4
S2
S1
8
9
Control
Logic
6
CLKB1
7
CLKB2
10
CLKB3
11
CLKB4
The IDT logo is a registered trademark of Integrated Device Technology, Inc.
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
1
c
2012 Integrated Device Technology, Inc.
AUGUST 2012
DSC 5175/7
IDT2309
3.3V ZERO DELAY CLOCK BUFFER
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
PIN CONFIGURATION
REF
CLKA1
CLKA2
V
DD
GND
CLKB1
CLKB2
S2
1
2
3
4
5
6
7
8
16
15
14
13
12
11
10
9
SOIC/ TSSOP
TOP VIEW
ABSOLUTE MAXIMUM RATINGS
(1)
Symbol
Rating
Supply Voltage Range
Input Voltage Range (REF)
Input Voltage Range
(except REF)
I
IK
(V
I
< 0)
I
O
(V
O
= 0 to V
DD
)
V
DD
or GND
T
A
= 55°C
(in still air)
(3)
T
STG
Operating
Temperature
Operating
Temperature
Storage Temperature Range
Commercial Temperature
Range
Industrial Temperature
Range
-40 to +85
°C
–65 to +150
0 to +70
°C
°C
Input Clamp Current
Continuous Output Current
Continuous Current
Maximum Power Dissipation
Max.
–0.5 to +4.6
–0.5 to +5.5
–0.5 to
V
DD
+0.5
–50
±50
±100
0.7
mA
mA
mA
W
Unit
V
V
V
CLKOUT
CLKA4
CLKA3
V
DD
GND
CLKB4
CLKB3
S1
V
DD
V
I (2)
V
I
APPLICATIONS:
•
•
•
•
•
SDRAM
Telecom
Datacom
PC Motherboards/Workstations
Critical Path Delay Designs
NOTES:
1. Stresses greater than those listed under ABSOLUTE MAXIMUM RATINGS may cause
permanent damage to the device. This is a stress rating only and functional operation
of the device at these or any other conditions above those indicated in the operational
sections of this specification is not implied. Exposure to absolute maximum rating
conditions for extended periods may affect reliability.
2. The input and output negative-voltage ratings may be exceeded if the input and output
clamp-current ratings are observed.
3. The maximum package power dissipation is calculated using a junction temperature
of 150°C and a board trace length of 750 mils.
PIN DESCRIPTION
Pin Name
REF
CLKA1
(1)
CLKA2
V
DD
GND
CLKB1
(1)
CLKB2
(1)
S2
(2)
S1
(2)
CLKB3
(1)
CLKB4
(1)
(1)
Pin Number
1
2
3
4, 13
5, 12
6
7
8
9
10
11
14
15
16
Type
IN
Out
Out
PWR
GND
Out
Out
IN
IN
Out
Out
Out
Out
Out
Functional Description
Input reference clock, 5 Volt tolerant input
Output clock for bank A
Output clock for bank A
3.3V Supply
Ground
Output clock for bank B
Output clock for bank B
Select input Bit 2
Select input Bit 1
Output clock for bank B
Output clock for bank B
Output clock for bank A
Output clock for bank A
Output clock, internal feedback on this pin
CLKA3
(1)
CLKA4
(1)
CLKOUT
(1)
NOTES:
1. Weak pull down on all outputs.
2. Weak pull ups on these inputs.
2
IDT2309
3.3V ZERO DELAY CLOCK BUFFER
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
FUNCTION TABLE
(1)
S2
L
L
H
H
S1
L
H
L
H
CLKA
Tri-State
Driven
Driven
Driven
CLKB
Tri-State
Tri-State
Driven
Driven
CLKOUT
(2)
Driven
Driven
Driven
Driven
Output Source
PLL
PLL
REF
PLL
PLL Shut Down
N
N
Y
N
NOTES:
1. H = HIGH Voltage Level.
L = LOW Voltage Level
2. This output is driven and has an internal feedback for the PLL. The load on this ouput can be adjusted to change the skew between the REF and the output.
DC ELECTRICAL CHARACTERISTICS - COMMERCIAL
Symbol
V
IL
V
IH
I
IL
I
IH
V
OL
V
OH
I
DD_PD
I
DD
Parameter
Input LOW Voltage Level
Input HIGH Voltage Level
Input LOW Current
Input HIGH Current
Output LOW Voltage
Output HIGH Voltage
Power Down Current
Supply Current
V
IN
= 0V
V
IN
= V
DD
Standard Drive
High Drive
Standard Drive
High Drive
REF = 0MHz (S2 = S1 = H)
Unloaded Outputs at 66.66MHz, SEL inputs at V
DD
or GND
I
OL
= 8mA
I
OL
= 12mA (-1H)
I
OH
= -8mA
I
OH
= -12mA (-1H)
—
—
12
32
µA
mA
2.4
—
V
Conditions
Min.
—
2
—
—
—
Max.
0.8
—
50
100
0.4
Unit
V
V
µA
µA
V
OPERATING CONDITIONS - COMMERCIAL
Symbol
V
DD
T
A
C
L
C
IN
Supply Voltage
Operating Temperature (Ambient Temperature)
Load Capacitance < 100MHz
Load Capacitance 100MHz - 133MHz
Input Capacitance
(1,2)
Parameter
Min.
3
0
—
—
—
Max.
3.6
70
30
10
7
Unit
V
°
C
pF
pF
SWITCHING CHARACTERISTICS (2309-1) - COMMERCIAL
Symbol
t
1
Parameter
Output Frequency
Duty Cycle = t
2
÷
t
1
t
3
t
4
t
5
t
6A
t
6B
t
7
t
J
t
LOCK
Rise Time
Fall Time
Output to Output Skew
10pF Load
30pF Load
Conditions
Min.
10
10
40
—
—
—
—
1
—
—
—
Typ.
—
—
50
—
—
—
0
5
0
—
—
Max.
133
100
60
2.5
2.5
250
±350
8.7
700
200
1
Unit
MHz
%
ns
ns
ps
ps
ns
ps
ps
ms
Measured at 1.4V, F
OUT
= 66.66MHz
Measured between 0.8V and 2V
Measured between 0.8V and 2V
All outputs equally loaded
Delay, REF Rising Edge to CLKOUT Rising Edge
(2)
Measured at V
DD
/2
Delay, REF Rising Edge to CLKOUT Rising Edge
(2)
Measured at V
DD
/2 in PLL bypass mode (IDT2309 only)
Device-to-Device Skew
Cycle-to-Cycle Jitter
PLL Lock Time
Measured at V
DD
/2 on the CLKOUT pins of devices
Measured at 66.66MHz, loaded outputs
Stable power supply, valid clock presented on REF pin
NOTES:
1. REF Input has a threshold voltage of V
DD
/2.
2. All parameters specified with loaded outputs.
3
IDT2309
3.3V ZERO DELAY CLOCK BUFFER
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
(1,2)
SWITCHING CHARACTERISTICS (2309-1H) - COMMERCIAL
Symbol
t
1
Parameter
Output Frequency
Duty Cycle = t
2
÷
t
1
Duty Cycle = t
2
÷
t
1
t
3
t
4
t
5
t
6A
t
6B
t
7
t
8
t
J
t
LOCK
Rise Time
Fall Time
Output to Output Skew
Delay, REF Rising Edge to CLKOUT Rising Edge
Delay, REF Rising Edge to CLKOUT Rising Edge
Device-to-Device Skew
Output Slew Rate
Cycle-to-Cycle Jitter
PLL Lock Time
10pF Load
30pF Load
Measured at 1.4V, F
OUT
= 66.66MHz
Measured at 1.4V, F
OUT
<50MHz
Measured between 0.8V and 2V
Measured between 0.8V and 2V
All outputs equally loaded
Measured at V
DD
/2
Conditions
Min.
10
10
40
45
—
—
—
—
1
—
1
—
—
Typ.
—
—
50
50
—
—
—
0
5
0
—
—
—
Max.
133
100
60
55
1.5
1.5
250
±350
8.7
700
—
200
1
Unit
MHz
%
%
ns
ns
ps
ps
ns
ps
V/ns
ps
ms
Measured at V
DD
/2 in PLL bypass mode (IDT2309 only)
Measured at V
DD
/2 on the CLKOUT pins of devices
Measured between 0.8V and 2V using Test Circuit 2
Measured at 66.66MHz, loaded outputs
Stable power supply, valid clock presented on REF pin
NOTES:
1. REF Input has a threshold voltage of V
DD
/2.
2. All parameters specified with loaded outputs.
DC ELECTRICAL CHARACTERISTICS - INDUSTRIAL
Symbol
V
IL
V
IH
I
IL
I
IH
V
OL
V
OH
I
DD_PD
I
DD
Parameter
Input LOW Voltage Level
Input HIGH Voltage Level
Input LOW Current
Input HIGH Current
Output LOW Voltage
Output HIGH Voltage
Power Down Current
Supply Current
V
IN
= 0V
V
IN
= V
DD
Standard Drive
High Drive
Standard Drive
High Drive
REF = 0MHz (S2 = S1 = H)
Unloaded Outputs at 66.66MHz, SEL inputs at V
DD
or GND
I
OL
= 8mA
I
OL
= 12mA (-1H)
I
OH
= -8mA
I
OH
= -12mA (-1H)
—
—
25
35
µA
mA
2.4
—
V
Conditions
Min.
—
2
—
—
—
Max.
0.8
—
50
100
0.4
Unit
V
V
µA
µA
V
OPERATING CONDITIONS - INDUSTRIAL
Symbol
V
DD
T
A
C
L
C
IN
Supply Voltage
Operating Temperature (Ambient Temperature)
Load Capacitance < 100MHz
Load Capacitance 100MHz - 133MHz
Input Capacitance
Parameter
Min.
3
-40
—
—
—
Max.
3.6
+85
30
10
7
pF
Unit
V
°
C
pF
4
IDT2309
3.3V ZERO DELAY CLOCK BUFFER
COMMERCIAL AND INDUSTRIAL TEMPERATURE RANGES
(1,2)
SWITCHING CHARACTERISTICS (2309-1) - INDUSTRIAL
Symbol
t
1
Parameter
Output Frequency
Duty Cycle = t
2
÷
t
1
t
3
t
4
t
5
t
6A
t
6B
t
7
t
J
t
LOCK
Rise Time
Fall Time
Output to Output Skew
Delay, REF Rising Edge to CLKOUT Rising Edge
Delay, REF Rising Edge to CLKOUT Rising Edge
Device-to-Device Skew
Cycle-to-Cycle Jitter
PLL Lock Time
10pF Load
30pF Load
Conditions
Min.
10
10
40
—
—
—
—
1
—
—
—
Typ.
—
—
50
—
—
—
0
5
0
—
—
Max.
133
100
60
2.5
2.5
250
±350
8.7
700
200
1
Unit
MHz
%
ns
ns
ps
ps
ns
ps
ps
ms
Measured at 1.4V, F
OUT
= 66.66MHz
Measured between 0.8V and 2V
Measured between 0.8V and 2V
All outputs equally loaded
Measured at V
DD
/2
Measured at V
DD
/2 in PLL bypass mode (IDT2309 only)
Measured at V
DD
/2 on the CLKOUT pins of devices
Measured at 66.66MHz, loaded outputs
Stable power supply, valid clock presented on REF pin
NOTES:
1. REF Input has a threshold voltage of V
DD
/2.
2. All parameters specified with loaded outputs.
SWITCHING CHARACTERISTICS (2309-1H) - INDUSTRIAL
Symbol
t
1
Parameter
Output Frequency
Duty Cycle = t
2
÷
t
1
Duty Cycle = t
2
÷
t
1
t
3
t
4
t
5
t
6A
t
6B
t
7
t
8
t
J
t
LOCK
Rise Time
Fall Time
Output to Output Skew
Delay, REF Rising Edge to CLKOUT Rising Edge
Delay, REF Rising Edge to CLKOUT Rising Edge
Device-to-Device Skew
Output Slew Rate
Cycle-to-Cycle Jitter
PLL Lock Time
10pF Load
30pF Load
Conditions
(1,2)
Min.
10
10
40
45
—
—
—
—
1
—
1
—
—
Typ.
—
—
50
50
—
—
—
0
5
0
—
—
—
Max.
133
100
60
55
1.5
1.5
250
±350
8.7
700
—
200
1
Unit
MHz
%
%
ns
ns
ps
ps
ns
ps
V/ns
ps
ms
Measured at 1.4V, F
OUT
= 66.66MHz
Measured at 1.4V, F
OUT
<50MHz
Measured between 0.8V and 2V
Measured between 0.8V and 2V
All outputs equally loaded
Measured at V
DD
/2
Measured at V
DD
/2 in PLL bypass mode (IDT2309 only)
Measured at V
DD
/2 on the CLKOUT pins of devices
Measured between 0.8V and 2V using Test Circuit 2
Measured at 66.66MHz, loaded outputs
Stable power supply, valid clock presented on REF pin
Use L293B to drive a motor. Requirements: The motor can rotate forward and reverse, and has speed. All are automatically controlled. There is no need to write the motor speed program in the program. J...
As the title says: PB->Platform->Settings->Enable full Kernel Mode (no [b]IMGNOTALLKMODE[/b]=1) I have always selected this option in previous projects and never thought about what it is for. I starte...
Hello everyone. I am now setting up a Wince system on a virtual machine. After setting up the virtual machine, use USBoot to format the U disk as a boot disk in HDD (ZIP has also been tried) mode, put...
The first thing to realize when learning design is that design is not art. I didn't make this distinction at the beginning, and I suffered a lot in my first design class. Design is communication and t...
When programming, I often use some internal functions such as [font=Verdana, Geneva, Arial, Helvetica, sans-serif][size=2][color=#000000]_delay_circles() and low power settings. But I am curious about...
Do you know what "soft article" means? What? I don't know. Hurry up and search Baidu, don't be OUT [[i] This post was last edited by longxtianya on 2011-11-6 20:19 [/i]]...
The rapid development of the Internet has realized high-speed information transmission and resource sharing, greatly facilitating people's lives. Embedded systems are widely used in various electr...[Details]
introduction
With the continuous optimization of surface mount technology (SMT) and the rapid development of chip component manufacturing technology, the application of chip mounters in the el...[Details]
1. Introduction
Automobile pollution is one of the most important issues that people are most concerned about and need to solve urgently. As an important method for detecting automobile exhau...[Details]
There are three types of mobile TV: one is based on analog TV broadcasting network, another is based on mobile communication network, and the other is based on digital broadcasting network. The f...[Details]
introduction
Solar cells and LED lighting are typical applications of new energy and energy-saving and efficient technologies. Solar LED lighting uses solar cells to convert solar energy...[Details]
Smart lighting control systems provide high controllability for various buildings and further enhance the level of green energy. They are the core products of energy conservation and digital techn...[Details]
With the continuous consumption of earth's energy and the scarcity of resources, the harm of greenhouse effect to human beings, and the serious pollution of the atmosphere to the earth, the intern...[Details]
The traditional display screen using 51 single-chip microcomputer to control LED dot matrix has relatively simple functions. If it is to achieve diversified functions, it often takes a lot of time ...[Details]
With the advocacy and implementation of the government's Safe City Plan, the security market has increasingly higher requirements for the clarity of surveillance images. Imagine that after a case o...[Details]
Toyohashi University of Technology demonstrated electric field coupled wireless power supply technology using life-size car tires and roads at the wireless technology exhibition "Wireless Technolog...[Details]
FPGAs are used in 81% of electronic systems, including many commercial and defense products, and most FPGAs use BGA packaging. The BGA packaging is characterized by small solder balls and small sol...[Details]
Capacitors
are basic components in various electronic devices and are widely used for bypassing, coupling,
filtering
, tuning, etc. in electronic circuits. However, to use capacitors,...[Details]
1. When the slip speed regulating motor is undergoing frequency conversion and energy saving transformation, the original excitation box (referred to as the speed regulating box) and the original s...[Details]
The serial interface real-time clock chip DS1302 launched by Dallas Company in the United States can trickle charge the backup battery of the clock chip. Due to the main features of the chip such a...[Details]
1 Overview
In the field of traditional lighting, the concepts and definitions of lamps and lamps are clear. Lamps and lamps have their own applicable product standards, supporting technical st...[Details]
Embedded System
京公网安备 11010802033920号
EEWORLD
