ATT-446F-16-SMA-02 datasheet, PDF

Datasheet> All Categories > Wireless rf/communication> Radio frequency and microwave> ATT-446F-16-SMA-02

ATT-446F-16-SMA-02: DescriptionFixed Attenuator, 0MHz Min, 8000MHz Max, STAINLESS STEEL; CategoryWireless rf/communication Radio frequency and microwave; File Size337KB，5 Pages; ManufacturerVertiv

Download Datasheet Parametric View All

ATT-446F-16-SMA-02 Overview

Fixed Attenuator, 0MHz Min, 8000MHz Max, STAINLESS STEEL

ATT-446F-16-SMA-02 Parametric

Parameter Name	Attribute value
Reach Compliance Code	unknown
Other features	SMA-F
Nominal attenuation	16 dB
structure	COAXIAL
Maximum input power (CW)	33.01 dBm
Maximum operating frequency	8000 MHz
Minimum operating frequency
Maximum operating temperature	125 °C
Minimum operating temperature	-65 °C
RF/Microwave Device Types	FIXED ATTENUATOR
Maximum voltage standing wave ratio	1.45
Base Number Matches	1

Preview

Download Datasheet

View All

Attenuators

DC - 18.0 GHz

Male/Female

ATT-0444-XX-SMA-02

SMA Subminiature "MINIPAD"

Round Body - Low Cost - Inexpensive Types

444 Series

Female/Female

ATT-444F-XX-SMA-02

Model Numbers

Male/Male

ATT-444M-XX-SMA-02

XX = Attenuation Value: Select 01-30dB in 1dB increments

LOW COST

DC - 12.4 GHz

Male/Female

ATT-0445-XX-SMA-02

445 Series

Female /Female

Model Numbers

Male/Male

SPECIFICATIONS - LOW COST

Attenuation Accuracy

DC - 12.4 GHz

1-4 dB

+ 0.75 dB

5-8 dB

+ 0.75 dB

9-12 dB

+ 1.00 dB

13-20 dB

+ 1.50 dB

21-30 dB

+ 2.00 dB

DC - 4.0

4.0 - 12.4

12.4 - 18.0

1.25 max

1.45 max

1.65 max

12.4 - 18 GHz

+ 0.75 dB

+ 1.00 dB

+ 1.25 dB

+ 1.50 dB

+ 2.00 dB

ATT-445F-XX-SMA-02 ATT-445M-XX-SMA-02

XX = Attenuation Value: Select 01-30dB in 1dB increments

LOW COST

VSWR

: Frequency (GHz) VSWR

DC - 8.0 GHz

Male/Female

ATT-0446-XX-SMA-02

446 Series

Female/Female

Model Numbers

Male/Male

ATT-446F-XX-SMA-02 ATT-446M-XX-SMA-02

Attenuation Value

1-12 dB

13-30 dB

Length A

0.86

1.02

XX = Attenuation Value: Select 01-30dB in 1dB increments

LOW COST

DC - 4.0 GHz

Male/Female

ATT-0447-XX-SMA-02

447 Series

Female/Female

Model Numbers

Male/Male

Attenuation Value

1-12 dB

13-30 dB

Length A

0.90

1.03

ATT-447F-XX-SMA-02 ATT-447M-XX-SMA-02

XX = Attenuation Value: Select 01-30dB in 1dB increments

LOW COST

DC - 2.0 GHz

Male/Female

ATT-0448-XX-SMA-02

448 Series

Female/Female

Model Numbers

Male/Male

Attenuation Value

Length A

0.98

1.12

ATT-448F-XX-SMA-02 ATT-448M-XX-SMA-02

1-12 dB

13-30 dB

XX = Attenuation Value: Select 01-30dB in 1dB increments

LOW COST

Note: Low Cost Models are available in Hex Body - Designate by subsituting "HEX" for "000" in Model No.
